Linx HumRC User Manual

Basic evaluation kit

Advertisement

Quick Links

HumRC
Series
TM
Basic Evaluation Kit
User's Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the HumRC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Linx HumRC

  • Page 1 HumRC Series Basic Evaluation Kit User's Guide...
  • Page 2 ANSI and NFPA standards. It is solely the responsibility Remote Control Demo Board Schematic of any Linx customer who uses one or more of these products to incorporate appropriate redundancies and safety standards for the Life and Property Safety Situation application.
  • Page 3 The boards serve several important functions: • Rapid Module Evaluation: The boards allow the performance of the Linx HumRC™ Series modules to be evaluated quickly in a user’s environment. The development boards can be used to evaluate the range performance of the modules.
  • Page 4: Ordering Information

    Series Carrier Board with Certified module, UFL Con- EVM-900-RC-UFL nector HumRC Series Carrier Board with Certified module, Castellation EVM-900-RC-CAS Connection Figure 3: HumRC Series Transceiver Carrier Board MDEV-DEMO-RC-A Development System Remote Control Demo Board, Type A HumRC Series Transceiver Carrier Board Objects MDEV-DEMO-RC-B Development System Remote Control Demo Board, Type B 1.
  • Page 5: Initial Setup

    Board A has the buttons on the right column and board B has them on the left column. These accept the Carrier Boards and are used to demonstrate the remote control functionality of the HumRC Series. They can also be used for range testing.
  • Page 6 If the range you are able to addresses. The MODE_IND has a quick flash while searching (100ms on, achieve is significantly less than specified by Linx for the products you are 900ms off) and a longer flash once Pairing is complete (400ms on, 100ms testing, then there is likely a problem with either the board or the ambient off).
  • Page 7 MCLR MCLR SER_I/O 100uF 0.47uF ED_SEL ED_SEL CMD_DATA_OUT PIC A/B CMD_DATA_IN MODE_IND IDENTITY CRT_LRN PIC16F1824 Figure 7: HumRC Series Transceiver Carrier Board Module Schematic Figure 9: Remote Control Demo Board Power Supply Area Schematic MISC CIRCUITS – – – –...
  • Page 8 MICROCONTROLLER AREA REMOTE CONTROL AREA A Board B Board A Board RESTORE 0 ohm R30 0 ohm ICSPDAT 0 ohm R31 0 ohm ICSPCLK MCLR MCLR SER_I/O 0 ohm R39 0 ohm PIC A/B PIC A/B CMD_DATA_OUT PIC A/B CMD_DATA_IN MODE_IND POWER SUPPLY AREA ED_SEL...
  • Page 9 Under no circumstances shall any user be conveyed any license or right to the use or ownership of such items. ©2015 Linx Technologies. All rights reserved. The stylized Linx logo, Wireless Made Simple, WiSE, CipherLinx and the stylized CL logo are trademarks of Linx Technologies.
