Quest Series
Quick Start Guide
Features
1
4
2
3
1.
Power button
2.
Power LED light indicator
3.
Ambient light sensor
4.
TFT LCD
5
14
6
7
15
16
8
9
13
12
10
11
5. Smart card reader (optional; will be installed
to system prior to shipping)
6. Scanner (optional; will be installed to system
prior to shipping)
7. Programmable button(default scan button)
8. Protection bumper
9. MSR
10. Hand strap
11. Speaker
12. Power charging slot
13. Battery cover
14. Camera
15. NFC logo
16. Pen screw
Getting Started
.
1
Power-On / Power-Off
Push the power button to turn on the
system and hold 4 seconds to turn off
the system.
Note: For best touch performance, remove the
protective plastic overlay from the LCD screen
by peeling it away from one of the corners. Be
sure to use a soft pointing device or finger tip
to avoid scratching the screen during
normal use.
2.
Replacing the Battery
Loosen the pen screw
counter-clockwise on the
battery cover.
Insert the battery
Remove the battery
Caution: Do not remove the battery while the system
beeps.
