Summary of Contents for Bosscom WirelessPowerlink
- Page 1 IRELESS OWERLINK ANUAL...
-
Page 2: Table Of Contents
Contents General ....................3 Wireless Powerlink ................ 3 Package Contents ................4 Disposal of Old electrical Devices ..........6 Installation ..................7 ”Pairing Function” ................. 7 Connecting the Devices ..............9 Assembly Instructions / Placement ..........11 System description ................12... -
Page 3: General
With years of expertise, we want to bring the benefits of the latest technology into your living room. Wireless Powerlink The WirelessPowerlink System was specifically developed for your ® Bang & Olufsen system and provides signal transmission from the system to the speakers, wherever a wired connection is not possible or simply too expensive. -
Page 4: Package Contents
Package Contents Powercord (for receivers) Receiver (2pcs) Paring kit Transmitter Powercord (for transmitter) Safety Instructions To ensure best performance, please read these instructions carefully. Keep them in a safe place for future reference. Install the equipment in a well-ventilated, cool, dry, clean environment - away from direct sunlight, heat sources, vibration, dust, moisture and/or cold. - Page 5 transformers to avoid humming sounds. Do not expose the equipment to sudden temperature changes from cold to hot, and do not place it in places with high humidity (e.g. in a room with a humidifier) to prevent the formation of condensation inside the devices, which could cause electric shock, fire, damage to the devices and/or accidents with injuries.
-
Page 6: Disposal Of Old Electrical Devices
In case of malfunction, carry out the pairing function again (see page 5). Should the malfunction persist, contact your local specialty retailer, or submit an email to support@bosscom.com. Before moving this device, unplug the power cord from the wall outlet. -
Page 7: Installation
electronic devices, please contact your local city or municipal administration, your waste disposal service or the dealer of the product. [Information on disposal in countries outside the European Union] This symbol is only valid within the European Union. If you wish to discard such devices, please contact your local authorities or dealer to inquire about the proper disposal method. - Page 8 Using the provided paring kit, press and hold the key on the bottom of the transmitter and the first receiver for about 5 seconds, until the green signal LED (in the middle hole) of the transmitter begins to flash quickly. Releasing the buttons starts the pairing function...
-
Page 9: Connecting The Devices
Connecting the Devices 4. Connect the transmitter on the PL IN socket to the Powerlink output of ® your Bang & Olufsen device, with the supplied Powerlink cable. Then connect it to the power supply (power cord also included). Transmitter... - Page 10 5. Use a Powerlink cable to connect the receiver to the PL OUT socket and the permanently connected power cord to connect it ® with your Bang & Olufsen speakers (Powerlink cable included with your speakers). Then connect the receiver to the power supply (Power cord also included with your speakers).
-
Page 11: Assembly Instructions / Placement
Assembly Instructions / Placement The logo on the side of the receiver and the transmitter should always be visible, to achieve the best possible transmission quality. Also make sure that the devices are not placed in the immediate vicinity of antenna cables - this can cause static noise. CORRECT: Lying flat on the side with the type plate –... -
Page 12: System Description
If the device is going to be attached to the wall with tape (e.g. Velcro), the side with the logo must also be visible. In no case should the device be placed as illustrated below. WRONG: Lying flag on the side with the logo facing down In this case the metal... - Page 13 Wireless Powerlink For Surround Systems Here, the front speakers remain connected to your system via wires. Wherever a wired connection to the rear speakers is not possible or simply too expensive, you can expand your wired stereo system to a full surround system with Wireless Powerlink.
- Page 14 Wherever a wired connection to the rear speakers is not possible or simply too expensive, you can extend your wired stereo system to a full surround system with WirelessPowerlink. And if you have an outdoor party, you can simply place the speakers on the patio and connect them to an outlet - the music will accompany you outside.
- Page 15 Wireless Powerlink for you sub- woofer With WirelessPowerlink as an extension you can also expand your ® wired stereo system with a sub-woofer such as the BeoLab 2 very easily and thus increase your listening enjoyment...
-
Page 16: Technical Data
Technical Data More info or to buy, www.powmascables.com...
