User's

Instructions

Alpha SolarSmart 90 and 150

Pre-Heat Drain Back Solar System and Wall Mounted

Unvented Hot Water Solar Cylinder

for use with an Alpha Combination Boiler

For Technical help or for Service call ...

ALPHA HELPLINE Tel: 0844 8718764

website: www.alpha-innovation.co.uk

Nepicar House, London Road,

Wrotham Heath, Sevenoaks,

Kent TN15 7RS

Building Regulations Approved

Certificate No. ETC11206

THE NATIONAL FEDERATION OF

SOLAR Key Mark Certificated

ROOFING CONTRACTORS LIMITED

Leave these instructions with the User

Table of Contents

Need help?

Do you have a question about the SolarSmart 90 and is the answer not in the manual?

Page 1 Alpha SolarSmart 90 and 150 Pre-Heat Drain Back Solar System and Wall Mounted Unvented Hot Water Solar Cylinder for use with an Alpha Combination Boiler For Technical help or for Service call ... ALPHA HELPLINE Tel: 0844 8718764 website: www.alpha-innovation.co.uk...
Page 2 DESCRIPTION The Alpha SolarSmart system is a pre-heat drain back solar collector system which includes an unvented cylinder to store water heated by the solar collector (either a 90 litre wall mounted or 150 litre floor standing cylinder). The system must be used in conjunction with an Alpha combination boiler fitted with the Alpha Solar valve which is supplied with the system.
Page 3: System Operation
(No.9) Fig. 2 - Alpha combination boiler controls POSITIONING OF THE COLLECTOR The solar energy supplied by a system varies with the orientation and tilt of the collector, which will usually be determined by the existing roof.
Page 4 If you contact the Alpha Helpline (Tel: 0844 8718764) for advice, you will be asked for the serial number of your solar cylinder. The serial number of the cylinder is located on top of the front housing underneath the top cover.
