- Page 2 IMPORTANT SAFTEY INSTRUCTIONS Please read the following very carefully before operating this unit Read ALL instructions carefully before using this unit. Keep these instructions for future reference. Heed all warnings and follow all instructions. Do not use this unit near water, in the rain, or where there is moisture. If this warning is ignored a serious electrical shock or death may occur.
- Page 3 OR HAZED, DO NOT REMOVE THE POWER AMPLIFIER MODULE, INPUT PANEL OR AC INPUT PANEL. NO UER SERVICABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED ISP TECHNOLOGIES SERVICE PERSONNELL. The lightning bolt triangle is used to alert the user to the risk of electric shock.
- Page 4 A scale of a standard sound level meter at slow response. INTRODUCTION Thank you for purchasing ISP Technologies XMAX active subwoofer system. The XMAX is a high output active subwoofer system for high SPL sound reinforcement applications. The XMAX was designed with a 1000 watt 18 inch woofer. The XMAX incorporates a High Current D-CAT...
- Page 5 A pole mount socket is provided on the top of the XMAX for mounting one of ISP Technologies Active Series Tripower or VMAX series speakers. A standard 1-3/8 inch pole is required for mounting the Tripower speakers.
-
Page 6: Rear Panel Description
REAR PANEL DESCRIPTION 1. LEFT HIGH PASS BALANCED OUTPUT- This XLR male connector provides a balanced high pass output from the left channel input. The high pass frequency is set at 100 Hz with a 24 dB per octave roll off. 2. -
Page 7: Fuse Replacement
FUSE REPLACEMENT 1. Use a small screwdriver as shown to slide the fuse cover out from the power inlet module. The fuse can be found inside the fuse cover module after it is pulled out. NOTE: A SMALL COMPARTMENT IS ALSO PROVIDED WITHIN THE FUSE COVER MODULE FOR STORING A SPARE FUSE. -
Page 8: Connection Diagram
CONNECTION DIAGRAM... - Page 9 BALANCED CONNECTION DESCRIPTION The ISP Sub Series has balanced XLR and inputs and outputs configured to AES standards (Audio Engineering Society). These connections are connected in a loop through configuration from the inputs to the full range outputs and will accept a balanced line-level input. The standard phase configuration is that pin 2 is (+), pin 3 is (-), and pin 1 is shielded ground on the XLR.
-
Page 10: Specifications
Floor mount Floor mount Thermal Protection Output Drivers have internal protection, self-resetting. Heatsink temperature monitored and input is muted if safe temperature is exceeded self-resetting. Transformer has internal thermal fuse, self-resetting. Note: D-CAT and XMAX are trademarks of ISP Technologies Inc. -
Page 11: Thermal Conditions
THERMAL CONDITIONS The ISP Sub Series is capable of producing 1000 watts at full power. This generates heat that must be dissipated in order to maintain reliability and insure the amplifier components stay within their operating temperature specs. To accomplish this the amplifier is mounted onto a heatsink that is exposed in the front port of the cabinet. -
Page 12: Warranty And Service
Any damage resulting from the misuse or the failure to follow the precautions and instructions will void the warranty. In the event that the unit needs to be repaired, please return the unit to ISP Technologies directly. Simply repack the unit, send a copy of the original receipt, a note stating the problem,...
