Summary of Contents for Wood Stone Fire Deck WS-FD-6045
- Page 1 Installation and Operation Manual Fire Deck series Fire Deck Stone Hearth Oven WS-FD-6045 Gas and Gas / Wood-Fired Models wood stone corporation tf. 800.988.8103 woodstone-corp.com 1801 w. bakerview rd. t. 360.650.1111 Revised October 2013 bellingham, wa 98226 usa f. 360.650.1166...
-
Page 2: Table Of Contents
Diagram � � � � � � � � � � � � � � � �30 limiteD Warranty � � � � � � � � � � � � � � � � �31 wood stone corporation tf. 800.988.8103 1801 w. -
Page 3: Fire Deck 6045
FIRE DECK 6045 FD-6045 Fire Deck Oven installation and Operation manual INSTALLATION AND OPERATION MANUAL FOR THE WOOD STONE FIRE DECK STONE HEARTH COOKING EQUIPMENT WS-FD-6045-(RFG)-(L, R)-(IR)-(W)-(NG, LP) MODELS GAS AND GAS / WOOD-FIRED MODELS ADDITIONAL COPIES AvAILABLE UPON REQUEST... -
Page 4: Cautions & Warnings
CAUTIONS & WARNINGS FD-6045 Fire Deck Oven installation and Operation manual WOOD STONE WS-FD-6045 FIRE DECK INSTALLATION AND OPERATING INSTRUCTIONS RETAIN THIS MANUAL FOR FUTURE REFERENCE additional copies of this manual at woodstone-corp�com� For prompt responses to service/maintenance questions, call us at @ 1-800-988-8103�... - Page 5 SAvE THE INSTRUCTIONS Wood Stone Fire Deck ovens have been tested and approved by Intertek Testing Services, and are ETL Listed to ANSI Z83.11b - 2009, CSA 1.8b - 2009, UL Subject 2162, Issue No.2, ULC Subject 1482-M1990, and to NSF/ANSI Standard 4 - 2009b.
-
Page 6: Fd-6045 Specifications
GAS INLET: 3/4" NPT OLE PROPERTY OF WOOD STONE CORPORATION SOLE PROPERTY OF WOOD STONE CORPORATION OUT THE WRITTEN PERMISSION OF WOOD STONE IS An ongoing program of product improvement may require us to change 160,000 BTU, NG Y REPRODUCTION OR USE IN PART OR AS A WHOLE ANY REPRODUCTION OR USE IN PART OR AS A WHOLE GAS INLET: 3/4"... -
Page 7: Unloading And Moving
LIFTING THE OvEN - 6000 LBS. FORKLIFT REQUIRED always use the forklift pockets; lifting the oven any other way will result in damage� the Wood Stone Fire Deck weighs approximately 3,200 lbs� and is top-heavy� use extreme caution and make sure that the forks extend all the way through the pockets provided�... - Page 8 800.988.8103 1801 w. bakerview rd. t. 360.650.1111 bellingham, wa 98226 usa f.
-
Page 9: Placing And Installation
800.988.8103 1801 w. bakerview rd. -
Page 10: Installation Clearances
1. the Wood Stone Fire Deck oven must have a minimum 1-inch clearance to combustibles from all sides, and 24-inch clearance to combustibles from the top� if building materials will contact the oven, they must be completely non- combustible�... -
Page 11: Facade Guidelines
Service Access Panel / Storage Box DO NOT BLOCK DO NOT BLOCK Provides the only access for service to the gas and electrical components. wood stone corporation tf. 800.988.8103 1801 w. bakerview rd. t. 360.650.1111 bellingham, wa 98226 usa f. 360.650.1166 An ongoing program of product improvement may require us to change info@woodstone-corp.com or visit woodstone-corp.com... -
Page 12: Facade Ready Ovens
(supplied by others). approved materials used to cover the cement board can be neatly terminated at these points. 1-inch stainless steel perimeter lip wood stone corporation tf. 800.988.8103 1801 w. bakerview rd. t. 360.650.1111 bellingham, wa 98226 usa f. 360.650.1166 An ongoing program of product improvement may require us to change info@woodstone-corp.com or visit woodstone-corp.com... -
Page 13: Oven Venting
Operation manual The Wood Stone Fire Deck must be vented using a Type 1 exhaust hood, or one constructed and installed in accordance with NFPA 96 and all relevant local and national codes. Wood Stone offers exhaust hoods especially designed for the Fire Deck by Gaylord Industries (see HOOD SPECIFICATIONS section). -
Page 14: Hood Specifications
HOOD SPECIFICATIONS FD-6045 Fire Deck Oven installation and Operation manual Wood Stone Hoods by Gaylord Specifications Required CFM: 730 CFM Static Pressure: 0.80" W.C. Duct Collar: 7.5''x 7.5'' I.D. wood stone corporation tf. 800.988.8103 1801 w. bakerview rd. t. 360.650.1111 bellingham, wa 98226 usa f. -
Page 15: Gas Specifications
5" Optional Decorative +15,000 Flame burner* 8" *The Optional Decorative Flame Burner adds 15,000 BTU/hr to total rated input. wood stone corporation tf. 800.988.8103 1801 w. bakerview rd. t. 360.650.1111 bellingham, wa 98226 usa f. 360.650.1166 An ongoing program of product improvement may require us to change info@woodstone-corp.com or visit woodstone-corp.com... - Page 16 Wood Stone recommends that the Fire Deck be equipped with a manual, individual shutoff valve, located between the oven and the main gas supply, and that this shutoff valve (supplied by others) be left readily accessible� Wood Stone also recommends that inspection and maintenance of the burners and gas piping connections of this appliance be performed at regularly scheduled intervals and only by professional gas appliance service agencies�...
-
Page 17: Electrical Specifications
Recessed Conduit entry for junction box electrical supply 3/4-inch FNPT gas connection wood stone corporation tf. 800.988.8103 1801 w. bakerview rd. t. 360.650.1111 bellingham, wa 98226 usa f. 360.650.1166 An ongoing program of product improvement may require us to change info@woodstone-corp.com or visit woodstone-corp.com... -
Page 18: Controller
WAIT 5 MINUTES BEFORE RELIGHTING ATTENDRE 5 MINUTES AVANT DE RÉALLUMER scales in display screens 1-800-988-8103 www.woodstone-corp.com wood stone corporation tf. 800.988.8103 1801 w. bakerview rd. t. 360.650.1111 bellingham, wa 98226 usa f. 360.650.1166 An ongoing program of product improvement may require us to change info@woodstone-corp.com or visit woodstone-corp.com... -
Page 19: Initial Startup
NOTE: Small “crazing” cracks will occur with normal heating and cooling� they will not effect the performance or durability of the oven� if cracks of 1/8 inch or more in width develop, contact Wood Stone for evaluation� wood stone corporation tf. -
Page 20: Daily Oven Operation
CLEANING THE OvEN Wood Stone recommends the use of long-handled brushes for sweeping up surface debris that will accumulate on the floor of the oven during use� use a natural fiber brush, always brushing away from the radiant burner well� For deeper cleaning, use a brass bristled brush�... -
Page 21: Flame Height Control
Return to Holding Flame height after removing pizza/product from the oven. NOTE: visually measure each suggested flame height using the Wood Stone utility peel, which is 8" tall when standing on edge in front of the flame� then relate height to the corresponding number on the Flame Height index Scale�... -
Page 22: Use Of Wood In The Oven
FIRE DECK MODELS LISTED FOR WOOD BURNING WILL HAvE A “-W” IN THE MODEL NUMBER. When burning wood in a Wood Stone Fire Deck, the fire should be located on the side of the oven chamber opposite the radiant gas burner� Wood may be burned at a rate not to exceed 15 lbs� per hour� two models, WS-FD-6045-ir-W and WS-FD-6045-W, have no radiant burners—wood may be burned on both sides of the oven chamber simultaneously at... -
Page 23: Daily Maintenance
OvEN INTERIOR Wood Stone recommends the use of a long-handled, brass bristled brush for sweeping aside excess food particles that will accumulate on the floor of the oven during use� the oven floor can be cleaned with a damp rag�... -
Page 24: Periodic Thermal Cleaning
THERMAL CLEANING Gas-fired Oven: if a Wood Stone gas-fired oven is operated at low temperatures (below 450 °F), it is possible that grease from food could condense on the walls and ceiling of the oven� to remove the grease that has accumulated on the walls and ceiling of the oven, simply turn the radiant flame to its highest setting�... -
Page 25: Fuelwood Facts
Wet wood is the most common operational difficulty associated with wood-fired cooking equipment� Wood Stone’s optional mini-ligno e Wood moisture meter can save you from paying for water when you thought you were paying for wood (see the tools &... -
Page 26: Decorative Flame Burner
TB4-8 white TB3-4 brown SV-DF gas valve wood stone corporation tf. 800.988.8103 1801 w. bakerview rd. t. 360.650.1111 bellingham, wa 98226 usa f. 360.650.1166 An ongoing program of product improvement may require us to change info@woodstone-corp.com or visit woodstone-corp.com... -
Page 27: Electrical Diagrams
ELECTRICAL DIAGRAMS FD-6045 Fire Deck Oven installation and Operation manual RFG-IR-MODELS wood stone corporation tf. 800.988.8103 1801 w. bakerview rd. t. 360.650.1111 bellingham, wa 98226 usa f. 360.650.1166 An ongoing program of product improvement may require us to change info@woodstone-corp.com or visit woodstone-corp.com... - Page 28 ELECTRICAL DIAGRAMS FD-6045 Fire Deck Oven installation and Operation manual W-IR-MODELS wood stone corporation tf. 800.988.8103 1801 w. bakerview rd. t. 360.650.1111 bellingham, wa 98226 usa f. 360.650.1166 An ongoing program of product improvement may require us to change info@woodstone-corp.com or visit woodstone-corp.com...
- Page 29 ELECTRICAL DIAGRAMS FD-6045 Fire Deck Oven installation and Operation manual 240 vAC RFG-IR MODELS wood stone corporation tf. 800.988.8103 1801 w. bakerview rd. t. 360.650.1111 bellingham, wa 98226 usa f. 360.650.1166 An ongoing program of product improvement may require us to change info@woodstone-corp.com or visit woodstone-corp.com...
-
Page 30: Interlock Diagram
For additional interlock options, see the Wood Stone interlock Options supplement in the manuals section on the website, woodstone-corp.com, or contact Wood Stone for additional information�... -
Page 31: Limited Warranty
LIMITATIONS OF LIABILITY in the event of warranty claim or otherwise, the sole obligation of Wood Stone shall be the repair and/or replacement, at the option of Wood Stone, of the appliance or component or part thereof� Such repair or replacement shall be at the expense of Wood Stone with the exception of travel over 100 miles or two hours, overtime, and holiday charges which shall be at the expense of the purchaser�...
