Summary of Contents for Bluefish444 Epoch Horizon
- Page 1 Create Range Windows User Manual Bluefish444 Windows User Manual for Epoch | Horizon Epoch | Core Epoch | Ultra Epoch | 2K Horizon Epoch | 2K Core Epoch | 2K Ultra November 20, 2014...
-
Page 2: Limited Warranty
Bluefish444 parts or supplies, d) to service a product that has been modified or integrated with other products when the effect of such a... - Page 3 Introduction Every so often, the application of advanced technology, modern industrial design and manufacturing processes yields a break-through that delivers real advantages over its predecessors. Introducing Bluefish444's Epoch range of uncompressed 2K/HD/SD SDI capture cards. Broadcast Engineering Redefined Let’s face it, “broadcast quality” 10 years ago is much like comparing VHS is to Blu-ray today! Everyone’s quick to spruik their product as being “broadcast quality”...
- Page 4 Create Range Windows User Manual Epoch Product Matrix Epoch Epoch Epoch Epoch 2K | Epoch Epoch Horizon Horizon Core Ultra 2K | Core 2K | Ultra Streams Video SDI Inputs Outputs 4:4:4:4 Input 4:4:4:4 Output 4:2:2:4 Input 4:2:2:4 Output Hardware Jetstream Jetstream Jetstream...
- Page 5 Create Range Windows User Manual Epoch|2K Ultra Key Features Supported Video Modes 720x486i @ 59.94 Hz NTSC 720x576i @ 50.00 Hz PAL 1280x720p @ 23.976Hz, 24Hz, 50Hz, 59.94Hz, 60Hz 1920x1080i @ 50Hz, 59.94Hz, 60Hz 1920x1080PsF @ 23.976Hz, 24Hz ...
- Page 6 Create Range Windows User Manual Input Hardware Features 4 General Purpose Input Pins LTC Input port Audio sample rate converters Genlock Bi, Tri and Cross Lock = Bi for HD, Tri for SD Output Hardware Features ...
- Page 7 Compatible with popular retail applications: Adobe Creative Suite™ Apple Final Cut Studio ™ AVID Media Composer ™ Bluefish444 Symmetry™ Assimilate Scratch™ Eyeon Digital Fusion™ Drastic Technologies Quick Clip Pro™ Drastic Technologies Media NXS™...
-
Page 8: Hardware Details
Symmetry Pre Create Files option from the General Settings. Please ensure your storage solution is certified to support sequential file format in HD and 2K resolutions. For further information and an updated list of tested storage solutions go to the Bluefish444 website at: http://www.bluefish444.com/support/compatibility/hardware/storage.asp... - Page 9 Create Range Windows User Manual Recommended System Hardware The requirements below are given as a guide, performance vary for each system configuration. It is recommended to use certified and tested hardware configuration which available at: http://www.bluefish444.com/support/compatibility/hardware/ Card Create range Slot Type...
-
Page 10: Storage Requirements
Windows, Linux and Apple Mac OS systems. We do not recommend a storage solution that is using the motherboard onboard SATA/SAS controller (such as ATTO or LSI Logic RAID controller), unless the device is a Bluefish444 certified solution. -
Page 11: Cable Connections
Create Range Windows User Manual Cable Connections Optional HDMI/DVI Preview Dual & Single Link 4:4:4 HD SD I/O Cameras MMCX to BNC Cable Beta cam SP SDI ‘A’ OUTPUT ’ SDI ‘B OUTPUT SDI ‘A’ SDI Broadcast INPUT Analog /SDI I/O Monitor SDI ‘B’... -
Page 12: Installation
Ensure your hands are clean and free of dirt and fluid. Make sure you are earthed and discharge any static build up before handling the Bluefish444 by touching the metal frame of the PC case. Do not touch the components on the PCB and do not touch the PCI slot mating edge. -
Page 13: New Installations
(Win7) 3 Select Bluefish444 installer, choose uninstall 6. Configure 3 party applications Bluefish444 provide a quick start guide for many of the supported 3 party applications. Please refer to the 3 party instructions to configure your software for Video I/O. -
Page 14: Feature Application
Create Range Windows User Manual Feature Application Bluefish444 Feature Application Bluefish444 Feature Application (or “Feature App“) is Bluefish444 control interface that runs independently to any applications using the card. It provides hardware monitoring and diagnostic tool such as: temperature, video... - Page 15 Create Range Windows User Manual Video Output Control This section gives you direct control of the output signal of your Bluefish444 card. Altering these settings will allow you to switch between outputting two video streams on both Outputs (SDI A & SDI B)
- Page 16 Where and when was it purchased? What host system/workstation do you use? What Operating System(s) do you use? Which version of Bluefish444 Installer was used? What Bluefish driver version do you use? Which slot does the card install to? Hardware used ...
-
Page 17: Support Resources
Software compatibility guide: Current list of released retail software that is compatible with the Bluefish444 product range. Refer to this site often as new supported products a frequently released: http://www.bluefish444.com/support/compatibility/software/ For phone support you must register your product online at:... -
Page 18: Support Contacts
Create Range Windows User Manual Support Contacts Australia - BlueFish444 (Head Office) China - UBS Consulting 17b Market Street, 601, Block 4, Wanda Square. South Melbourne 93 Jianguo Road Victoria, 3205 100022 Beijing P.R, China Australia Telephone: +86 (10) 5820 6929,... - Page 19 Create Range Windows User Manual...
