Summary of Contents for Dragonfly DFM-NTT
- Page 1 OWNER’S MANUAL >>DFM-NTT SCREENS MOTORIZED FILM SCREEN...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus in or near rain or moisture 1. Read and follow all instructions and warnings in this manual. Keep for future reference. 2. Do not use this apparatus near water. 3. - Page 3 Locking Piece Screen Fabric Lower Groove Tension Rod Locking Screw ACCESSORIES INCLUDED FOR THE DRAGONFLY™ MOTORIZED FILM SCREEN: (E) Ceiling Hanger (2) (B) 5x40mm Mounting Screws (8) (A) Floating Mount Bracket (2) (C) Concrete Anchors (8) (F) M5x10 Ceiling Hanging Screws (4)
- Page 4 Installing the bracket on the wall or ceiling: 1. According to the surface of installation, choose the appropriate screws needed for mounting (Use Mounting Screws for wood surfaces, use Mounting Screws and Concrete Anchors for concrete surfaces) 2. Mount the brackets onto the surface, ensuring they are level. Ceiling Joist Installation Drywall/ Stud Installation (Tip: draw an erasable...
- Page 5 5. To lock the screen in place, close and tighten the Locking Screw on the mounting brackets. This will keep the screen locked firmly in place. Installing the hanging bracket: 1. Choose tapping screws with hangers, or other screws with hangers (not included) according to your ceiling material. 2.
- Page 6 EXTERNAL CONTROL FUNCTION 12V Trigger Input This motorized screen has 4 types on control options: External IR Input infrared (IR) remote control, manual control, triggered control, and a wall switch. Wall Switch In To access the external control interface, press down and open the the end cap door.
- Page 7 ADJUSTING YOUR DRAGONFLY MOTORIZED FILM SCREEN The stopping point for both the upward and downward motion of your Dragonfly motorized film screen can be adjusted easily with the included plastic Allen key. The screen has 15 3/4” of black material above the screen surface, allowing flexibility for most installations.
- Page 8 2-Year Limited warranty Dragonfly Motorized and Tab-Tension Motorized Film Screens have a 2-Year Limited Warranty. This warranty includes parts and labor repairs on all components found to be defective in material or workmanship under normal conditions of use. This warranty shall not apply to products which have been abused, modified or disassembled. Products to be...
