8.4. Condensed Water Drainage.
This air conditioner employs a "Slinger-Up System" which is
designed to splash the condensed water on the condenser coil
for maximum cooling efficiency, thus producing a splashing
sound. If the splashing sound annoys you, you can provide an
outside drainage by using the following procedure which may,
however, cause a small loss of performance.
1. Slide out the Chassis from the Cabinet.
2. Remove the rubber plug from the Base Pan.
3. Install the Drain Pan at the right corner of the Cabinet with
2 screws.
4. Connect the drain hose to the outlet of Drain Pan bottom.
5. Slide the Chassis back into the Cabinet.
Note: Drain hose or tubing can be purchased locally to satisfy
your particular needs.

9 Care and Maintenance

Caution: Always turn off the air conditioner and the main power supply before unplugging the power cord to clean the
unit.
9.1. Cleaning the Unit.
Clean the Cabinet, Front Grille with a mild soap or detergent
and lukewarm water.
9.2. Cleaning the Front Intake
Grille.
Gently wash with water and a sponge. (Do not use a scrubbing
brush or other hard cleaning aids).
Note: Do not clean with benzene, thinner, scouring powder or corrosive chemicals. Do not dry the Front Intake Grille or
the Air Filter in direct sunlight. Exposure to direct sunlight may discolor or deform the panel.
9.3. Cleaning the Air Filter.
1. Push and release the bottom of the Front Intake Grille.
2. Lift up the Front Intake Grille at 45° until it is supported by
the stopper.
3. Tilt up and pull out the Air Filter by the holder.
4. Vacuum the front of the filter and then wash the back of it
with water. If it is badly soiled, wash with a mild household
detergent.
