Summary of Contents for NiteRider Classic Plus
- Page 1 Dual Beam Halogen NiMH C l a s s i c P l u s U S E R G U I D E...
- Page 2 To get the most from your NiteRider light, we urge you to familiarize yourself with the following safety and operation instructions.
- Page 3 R I D I N G A T N I G H T While the Classic Plus will improve your control and enjoyment of night riding, please remember that cycling at night is an inherently dangerous activity. In addition to using...
- Page 4 800.466.8366, ext. 4. You may also e-mail us at support@niterider.com. W A R R A N T Y NiteRider stands behind its products with the following warranties: • Lifetime warranty on all mechanical components • 1 year on cables and connectors, electronic components, and printed circuit boards •...
-
Page 5: Table Of Contents
T A B L E O F C O N T E N T S Parts List and Identification ..... . 4 Quick Start . -
Page 6: Parts List And Identification
P A R T S L I S T A N D I D E N T I F I C A T I O N Please verify the contents of your Classic Plus system: A. 12/20/32 Watt halogen headlamp B. -
Page 7: Quick Start
Q U I C K S T A R T 1. Fully charge the battery before the first use. See “Using the 2.5-hour Fast Charger” on page 10. 2. To mount the headlamp and battery, see “Mounting the Headlamp” on page 6 and “Mounting the Battery” on page 8. -
Page 8: Mounting The Headlamp
M O U N T I N G T H E H E A D L A M P Universal Handlebar Mount The Universal Handlebar Mount (UHM) is designed to fit on virtually any handlebar. Included with the mount is a 2.5-mm Allen wrench, a pair of black rubber bumpers already in place, and a thin rubber shim to customize the fit on large handlebars up to 32 mm in diameter. -
Page 9: Inserting The Headlamp
To pivot the headlamp, loosen the 2.5 x 12 mm screw located under the slider clip and swing arm and rotate the headlamp to the desired position. Make this adjustment before tightening the 2.5 x 30 mm screw. Inserting the Headlamp into the UHM Insert the headlamp mount into the UHM slider clip from the rear of the slider clip forward. -
Page 10: Mounting The Battery
M O U N T I N G T H E B A T T E R Y The NiMH battery is mounted to the bike frame. 1. Thread the wide Velcro strap through the slots on the top of the battery clip. -
Page 11: Operation
Warning: To protect the battery from over-discharging, turn off the lamp before it reaches complete darkness. Warning: Headlamps require adequate airflow during operation (as in riding conditions). NiteRider discourages use of the light in stationary conditions as excessive heat retention can damage the lamp. -
Page 12: Battery Charging And Care
B A T T E R Y C H A R G I N G A N D C A R E Rechargeable batteries can last years with proper care. Most importantly, fully charge your battery: • before the first use •... -
Page 13: Smart Battery Protection
“bench testing” (operating the light in static conditions) as the excessive heat generated can damage the headlamp. Smart Battery Protection Classic Plus’ “smart” battery incorporates thermal protection circuitry that turns the battery off when it overheats from charging, external heat, or a short circuit. When the thermal protection circuit is activated, the system will lock and the fuel gauge will become dark. -
Page 14: Run Times
R U N T I M E S Setting Run Time (hours) 12 watt (spot) 3:10 20 watt (flood) 2:00 32 watt (spot and flood) 1:20 Run times are approximations and will vary. - Page 16 NiteRider, Inc. 8205 Ronson Road, Suite E San Diego, CA 92111 USA 800.466.8366 www.niterider.com 1 5 0 - 2 1 2 1 2...
