Summary of Contents for The Original Pink Box PB408SV
- Page 1 120 VOLT WET / DRY WET / DRY WET / DRY OPERATOR’S MANUAL 4 Gallon / 15.14 Liter Part No. PB408SV FOR YOUR SAFETY – Read and understand this manual before use. – – Keep this manual for future reference. –...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION PAGE Warranty....................................2 Safety Instructions and Warnings ..........................3 Double Insulation Instructions ............................ 4 Extension Cord................................... 4 Unpacking and Checking Carton Contents ......................5 General Assembly Instructions ............................ 6 Dry Vacuuming Operation............................. 7 Liquid Vacuuming Operation............................8 Blowing Operation ................................ -
Page 3: Safety Instructions And Warnings
SAFETY INSTRUCTIONS & WARNINGS IMPORTANT SAFETY INSTRUCTIONS Read and understand all instructions before using this vacuum. Read and understand this owner’s manual and all labels on the Wet/Dry Vacuum cleaner before operating. Safety is a combination of common sense, staying alert and knowing how your vacuum works. Use this Wet/Dry Vac only as described in this manual. -
Page 4: Double Insulation Instructions
DOUBLE INSULATION INSTRUCTIONS This Wet/Dry Vac is double-insulated, eliminating the need for a separate grounding system. Use only identical replacements parts. Read the instructions for Servicing Double-Insulated Wet/Dry Vacs before servicing. Use this Wet/Dry Vac as described in this manual. Observe the following warnings that appear on the motor housing of your Wet/Dry Vac. -
Page 5: Unpacking And Checking Carton Contents
UNPACKING & CHECKING CARTON CONTENTS Remove entire contents of carton. Check each item against the carton contents. Carton Contents List Key Description 1PC Vac Assembly 1PC Hose 1PC Utility nozzle 1PC Crevice Tool 1PC Cartridge Filter 1PC Filter Retainer 1PC Dust Bag 1PC Foam Sleeve Filter 1PC Air/Noise Diffuser NOTE: The hose and accessories for this... -
Page 6: General Assembly Instructions
GENERAL ASSEMBLY INSTRUCTIONS WARNING: DO NOT PLUG IN POWER CORD TO POWER OUTLET, MAKE SURE PLUG IS DISCONNECTED BEFORE ASSEMBLING THE WET/DRY VAC. UNPACKING YOUR WET/DRY VACUUM & GENERAL ASSEMBLY 1. Verify that the power cord is disconnected from the outlet. (fig. 1) 2. -
Page 7: Dry Vacuuming Operation
(DRY ) VACUUM OPERATION WARNING: BE SURE TO READ, UNDERSTAND, AND APPLY INFORMATION, ENTITLED ‘SAFETY INSTRUCTIONS & WARNINGS’. DO NOT VACUUM IN AREAS WITH FLAMMABLE GASES, VAPORS, OR EXPLOSIVE DUSTS IN THE AIR. FLAMMABLE GASES OR VAPORS INCLUDE BUT ARE NOT LIMITED TO;... -
Page 8: Liquid Vacuuming Operation
(LIQUID ) VACUUM OPERATION WARNING: BE SURE TO READ, UNDERSTAND, AND APPLY INFORMATION, ENTITLED ‘SAFETY INSTRUCTIONS & WARNINGS’. DO NOT VACUUM IN AREAS WITH FLAMMABLE GASES, VAPORS, OR EXPLOSIVE DUSTS IN THE AIR. FLAMMABLE GASES OR VAPORS INCLUDE BUT ARE NOT LIMITED TO;... -
Page 9: Blowing Operation
BLOWING OPERATION This Wet/Dry Vac has blowing capabilities only when the hose is inserted into the blowing port. To use the blower feature follow the instructions listed. WARNING: ALWAYS WEAR SAFETY GOGGLES COMPLYING WITH ANSI Z87.1 (OR IN CANADA, CSAZ94.3) BEFORE USING BLOWER. WARNING: KEEP BYSTANDERS CLEAR FROM BLOWING DEBRIS. -
Page 10: Installing & Cleaning Cartridge Filter
MAINTENANCE cont. NOTICE! The filters included are made of high quality material designed to stop small dust particles. The cartridge filter should be used for dry pick-up only. A dry cartridge filter is necessary to pick up dust. If the cartridge filter is wet, it will clog quickly and be very difficult to clean. Handle the filter carefully when removing it for cleaning and replacing it. -
Page 11: Troubleshooting
TROUBLESHOOTING WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK - UNPLUG BEFORE TROUBLESHOOTING. Symptom Possible Causes Corrective Actions Vacuum will not 1. No power supply. 1. Check power supply – cord, operate. breakers, fuses. 2. Faulty power cord. 2. Unplug and check the power cord. -
Page 12: Exploded View And Parts List
EXPLODED VIEW AND PARTS LIST...
