RoboGuard uRx User Manual

OPERATORS MANUAL
(Universal Receiver uRx)
Introduction
Congratulations on your purchase of a Roboguard
Universal Receiver.
Installation and wiring
The installer's manual is available for people
wishing to do a self-installation. Be careful as
unqualified people can damage the device at
installation and this damage is not covered by our
warranty.
General Operation
The Universal Receiver (uRx) is used to remotely
trigger the operation of electronic devices from
Roboguard signals. The uRx can be "taught" to
respond to any particular roboguard radio
message. Once the uRx has learned a roboguard
code, every time it receives that radio message, it
will respond by triggering the connected device.
This connected device may be an alarm system, a
camera system, a siren, an SMS module, in fact
any device capable of being triggered by an
electronic signal.
In the example above a uRx can be programmed
to respond to a radio message from a Roboguard
handheld remote. This handheld remote can then
be used as a panic button and the uRx can be used
to operate an SMS module to send an sms call for
help in response to the panic signal. Another
popular use will be to open a garage door.
Your installer must connect the uRx to a power
source and to the device that you wish to trigger.
The installer must also configure the options on
the uRx to correctly trigger the connected device
and must marry the transmitter to the uRx
through a learning process.
The uRx will flash its status LED at different flash
rates depending on the configured options as set
up by your installer.
Maintenance
There are no user maintainable parts or
considerations.
Support
Properly installed Roboguards do not false alarm.
Ensure that your system is properly installed and
configured.
Please visit www.roboguard.co.za/forum
support.
Warranty
All Roboguards systems carry a 2 year factory
warranty, a lifetime warranty against UV damage
and the guards themselves carry a lifetime
warranty against lightning damage.
Technical Details
Dimensions: 104 X 64 X 27
Mass: 100 g
Current Consumption: +_ 25 mA
Required receiver UHF 433.92 MHz
Required Power Supply 12V DC
Colour: White
Packing Contents
uRx module uRx manual
Trap International CC
PO BOX 38113
Point, 4069
Durban
South Africa
