Toshiba 14JL7E Service Manual page 39

Location Parts No. Description
No.
D999 #2 23357253 DIODE, ZENER, DZ3.6 BS A @U901A
#2 23357253 DIODE, ZENER, DZ3.6 BS A @U903
#5 23357253 DIODE, ZENER, DZ3.6 BS A @U901A
#5 23357253 DIODE, ZENER, DZ3.6 BS A @U903
DA01 23357447 DIODE, SWITCH SILICON KDS160-RTK/USC
DB01 23358596 LED, LED GREEN BL-HGK34C-TRB
DB02 23358595 LED, LED RED BL-HUB34C-TRB
DB03 23357248 DIODE, DZ2.7 BS B
DV01 23316588 DIODE, ZENER, MA8091-M
DV02 23316588 DIODE, ZENER, MA8091-M
DV03 23316588 DIODE, ZENER, MA8091-M
DV04 23316588 DIODE, ZENER, MA8091-M
KB01 23085095 IC, REMOTE PHOTO RECIEVER LTOP-4838-B4
U402 23085080 IC, CMOS SUPER FLASH SST25VF010-204CSAE
U702 23009913 IC, SERIAL EEPROM 16K SOP8 BR24L16F-WE2
U703 23205272 TRANSISTOR, P CHANNEL FET TPC6104(TE85L)
U802 23009976 IC, REGULATOR +3.3V 1% SSOP5 BH33FB1WG-TR
U803 23009528 IC, 1.8V REG BA18BC0FP-E2
U804 23085081 IC, IC REGULATOR LM1117MPX-3.3 / NO
U805 23085043 IC, REGULATOR +1.8V 1% SSOP5 BH18FB1WG-TR
MISCELLANEOUS
A515 23717206 SCREW, FLAT HEAD PHILLIPS M3X4 S1404E014
A517 23717206 SCREW, FLAT HEAD PHILLIPS M3X4 S1404E014
A519 #5 23717206 SCREW, FLAT HEAD PHILLIPS M3X4 S1404E014
B211B #2 23717206 SCREW, FLAT HEAD PHILLIPS M3X4 S1404E014
#5 23717206 SCREW, FLAT HEAD PHILLIPS M3X4 S1404E014
F701 #1 70144829 FUSE, 3.15A 125V SSTC3.15A R12A4
#3 70144829 FUSE, 3.15A 125V SSTC3.15A R12A4
#4 70144829 FUSE, 3.15A 125V SSTC3.15A R12A4
#6 70144829 FUSE, 3.15A 125V SSTC3.15A R12A4
F800 23144458 FUSE, 5.0A 250V
F800A 23165469 FUSE HOLDER, FUSE HOLDER 5.2 DFH-001
F800B 23165469 FUSE HOLDER, FUSE HOLDER 5.2 DFH-001
FB401 23103288 FILTER, CHIP BEAD 4.0A 100OHM TEM2162AD
FB402 23103288 FILTER, CHIP BEAD 4.0A 100OHM TEM2162AD
FB403 23103288 FILTER, CHIP BEAD 4.0A 100OHM TEM2162AD
FB404 23103288 FILTER, CHIP BEAD 4.0A 100OHM TEM2162AD
FB805 23103288 FILTER, CHIP BEAD 4.0A 100OHM TEM2162AD
FB806 23103288 FILTER, CHIP BEAD 4.0A 100OHM TEM2162AD
FB807 23103288 FILTER, CHIP BEAD 4.0A 100OHM TEM2162AD
FB808 23103288 FILTER, CHIP BEAD 4.0A 100OHM TEM2162AD
M007Z #3 23927249 PACKING BLOCK, PACKING MTL 14JL 14JL7R
M101 23389233 CABLE, FFC WIRE 20WAY L70 (B) 1.25MM
M103 #1 23389234 CABLE, FFC WIRE 7WAY L90 (B) 1MM
#2 23389234 CABLE, FFC WIRE 7WAY L90 (B) 1MM
#3 23389234 CABLE, FFC WIRE 7WAY L90 (B) 7 1MM
#4 23389230 CABLE, FFC WIRE 7WAY L160 (B) 1MM
#5 23389230 CABLE, FFC WIRE 7WAY L160 (B) 1MM
#6 23389230 CABLE, FFC WIRE 7WAY L160 (B) 1MM
M104 #1 23507365 WIRE HARNESS, CON 7P-7P L160
#2 23507365 WIRE HARNESS, CON 7P-7P L160
#3 23507365 WIRE HARNESS, CON 7P-7P L160
M106 #4 23507363 WIRE HARNESS, CON 12P-12P L350
#5 23507363 WIRE HARNESS, CON 12P-12P L350
#6 23507363 WIRE HARNESS, CON 12P-12P L350
M107 23507366 WIRE HARNESS, CON 20P L200(A)
M108 #1 23389235 CABLE, FFC WIRE 6WAY L110 (B) 1.25MM
#2 23389235 CABLE, FFC WIRE 6WAY L110 (B) 1.25MM
#3 23389235 CABLE, FFC WIRE 6WAY L110 (B) 1.25MM
#4 23389231 CABLE, FFC WIRE 6WAY L330 (B) 1.25MM
#5 23389231 CABLE, FFC WIRE 6WAY L330 (B) 1.25MM
#6 23389231 CABLE, FFC WIRE 6WAY L330 (B) 1.25MM
M611 #1 23389236 CABLE, FFC WIRE 5WAY L120 (B) 1.25MM
#2 23389236 CABLE, FFC WIRE 5WAY L120 (B) 1.25MM
#3 23389236 CABLE, FFC WIRE 5WAY L120 (B) 1.25MM
#4 23389232 CABLE, FFC WIRE 5WAY L170 (B) 1.25MM
#5 23389232 CABLE, FFC WIRE 5WAY L170 (B) 1.25MM
#6 23389232 CABLE, FFC WIRE 5WAY L170 (B) 1.25MM
N780 #1 23555178 LABEL, SHIMUKE ASIA(AS)
#3 23555178 LABEL, SHIMUKE ASIA(AS)
#4 23555178 LABEL, SHIMUKE ASIA(AS)
#6 23555178 LABEL, SHIMUKE ASIA(AS)
N920 #1 23969946 TAPE
#3 23969946 TAPE
#4 23969946 TAPE
Location Parts No. Description
No.
#6 23969946 TAPE
P103A 23713606 CONNECTOR, CFP2507-0101
P103B 23713606 CONNECTOR, CFP2507-0101
P108A 23713266 CONNECTOR, 6FE-ST-VK-N
P108B 23713233 CONNECTOR, 6FE-BT-VK-N JST
P611A 23713265 CONNECTOR, 5FE-ST-VK-N
P611B 23713232 CONNECTOR, 5FE-BT-VK-N JST
P661 23023254 JACK, EARPHONE JACK HTJ-035-18ABP
P800 #1 23122474 P0WER UNIT, AC-DC 250V 19V 3.4 NU65
#2 23122474 P0WER UNIT, AC-DC 250V 19V 3.4 NU65
#3 23122474 P0WER UNIT, AC-DC 250V 19V 3.4 NU65
#4 23122479 P0WER UNIT, AC-DC 250V 19V 4.2 NU80-11190-300X
#5 23122479 P0WER UNIT, AC-DC 250V 19V 4.2 NU80-11190-300X
#6 23122479 P0WER UNIT, AC-DC 250V 19V 4.2 NU80-11190-300X
P801 23023261 JACK, DC JACK HTJ-020-05AZ1
P900 #1 23372273 POWER CORD, SET 2.5A CEE CAT-201_EF-68
#2 23372278 POWER CORD, SET BSI 5A VM05050-VM05530
#3 23372273 POWER CORD, SET 2.5A CEE CAT-201_EF-68
#4 23372273 POWER CORD, SET 2.5A CEE CAT-201_EF-68
#5 23372278 POWER CORD, SET BSI 5A VM05050-VM05530
#6 23372273 POWER CORD, SET 2.5A CEE CAT-201_EF-68
PV02 23023255 JACK, SVHS JACK LCD MDC-013V1-A LF
PV03 23023263 JACK, 3P JACK MTJ-032-39ABB-234
PV04 23023257 JACK, 3P JACK MTJ-032-39ABB-752
PV05 23023258 JACK, 3P JACK MTJ-032-39BBA-432
PV06 23023267 JACK, AUDIO JACK 2P MTJ-032-50AB-23 NI
PV07 23023255 JACK, SVHS JACK LCD MDC-013V1-A LF
Q610B 70391355 SCREW, BIND HEAD TAP-TITE B, BITTB 3X8 SZN
SA01 23344499 SWITCH, TACT SWITCH TSKB-2JP
SA02 23344499 SWITCH, TACT SWITCH TSKB-2JP
SA03 23344499 SWITCH, TACT SWITCH TSKB-2JP
SA04 23344499 SWITCH, TACT SWITCH TSKB-2JP
SA05 23344499 SWITCH, TACT SWITCH TSKB-2JP
SA06 23344499 SWITCH, TACT SWITCH TSKB-2JP
V001 #1 23301617 LCD PANEL, T140VN01
#2 23301617 LCD PANEL, T140VN01
#3 23301617 LCD PANEL, T140VN01
#4 23301618 LCD PANEL, T201VN01 V1
#5 23301618 LCD PANEL, T201VN01 V1
#6 23301618 LCD PANEL, T201VN01 V1
XA03 23153759 CRYSTAL RESONATOR, 10MHZ
ZP01 23144718 FUSE, PROTECT 2000 11CT, 14VL43
ZP02 23144719 FUSE, PROTECT 5000 11CT, 14VL43
ZP03 23144718 FUSE, PROTECT 2000 11CT, 14VL43
ZP04 23144718 FUSE, PROTECT 2000 11CT, 14VL43
ZP06 23144718 FUSE, PROTECT 2000 11CT, 14VL43
PC BOARD ASSEMBLIES
* U901A #1 23762181 PC BOARD ASSY, UNIT ANALOGMAIN PD1803 -1
* #2 23762181 PC BOARD ASSY, UNIT ANALOGMAIN PD1803 -1
* #3 23762182 PC BOARD ASSY, UNIT ANALOGMAIN PD1803A -1
*
#4 23762442 PC BOARD ASSY, UNIT ANALOGMAIN PD1860 -1 AMAIN
* #5 23762442 PC BOARD ASSY, UNIT ANALOGMAIN PD1860 -1 AMAIN
* #6 23762468 PC BOARD ASSY, UNIT ANALOGMAIN PD1860A -1 AMAIN
* U901B #1 23762404 PC BOARD ASSY, UNIT KEY BD PD1803 -2
* #2 23762404 PC BOARD ASSY, UNIT KEY BD PD1803 -2
* #3 23762404 PC BOARD ASSY, UNIT KEY BD PD1803 -2
* #4 23762443 PC BOARD ASSY, UNIT KEY BD PD1860 -2 KEY BD
* #5 23762443 PC BOARD ASSY, UNIT KEY BD PD1860 -2 KEY BD
*
#6 23762443 PC BOARD ASSY, UNIT KEY BD PD1860 -2 KEY BD
* U901D #1 23762406 PC BOARD ASSY, UNIT PHONE JACK PD1803 -4
* #2 23762406 PC BOARD ASSY, UNIT PHONE JACK PD1803 -4
* #3 23762522 PC BOARD ASSY, UNIT PHONE JACK PD1803A-4
* #4 23762445 PC BOARD ASSY, UNIT PHONE JACK PD1860 -4 PHONE JK
*
#5 23762445 PC BOARD ASSY, UNIT PHONE JACK PD1860 -4 PHONE JK
* #6 23762521 PC BOARD ASSY, UNIT PHONE JACK PD1860A-4
* U902 23762407 PC BOARD ASSY, UNIT DIGITALMAIN PD1840
* U903 23762788 PC BOARD ASSY, UNIT IR BOARD PD1958 IR BOARD
TUNER
H001 23321477 TUNER, EC981W1, HYP.MULT FS 38.0M TIM
ACCESSORIES
A701 #1 23067784 CARTON, BOX
#2 23067806 CARTON, BOX
#3 23067785 CARTON, BOX
– 39 –
