Location Of Controls - Toshiba 14JL7E Service Manual

VOLUME –/+*
Volume down/up
Menu item adjustment
Input source
selection
(Antenna input)
(Audio output)
(2) IN
(S-video/Video/
Audio input)
Back

LOCATION OF CONTROLS

Left side Front
Headphone jack (
For private listening, connect
headphones.
The sound from the speakers
will be cut off automatically.
To adjust the volume, press
the VOLUME –/+
Cables
Cable holder
Used to bundle the connected cables from the TV.
To use the smaller holder, open the catch, arrange
the cables across it and press to close.
– 10 –
CHANNEL
Channel selection
Menu item selection
Right side
3.5mm)
/
Power on/standby button
* Dual function buttons.
DC IN 19V
(Power input)
(1) (S-video/Video/
Audio/Component
video input)
Remote sensor
Power on indicator (green)
Power standby
indicator (red)
