Specifications Of Electrical Parts - Toshiba RAV-164B-PE Service Manual

RAV-164B-PE
4.1
No PARTS NAME
1 Indoor Unit fan motor
2 Running capacitor for
indoor fan motor
3 Transformer (Indoor Unit)
4 Sensor for room temperature
5 Sensor for heat
exchanger temperature
RAV-264B-PE
4.2
No PARTS NAME
1 Indoor Unit fan motor
2 Running capacitor for
indoor fan motor
3 Transformer (Indoor Unit)
4 Sensor for room temperature
5 Sensor for heat
exchanger temperature
4.3 RAV-364B-PE
No PARTS NAME
1 Indoor Unit fan motor
2 Running capacitor for
indoor fan motor
3 Transformer (Indoor Unit)
4 Sensor for room temperature
5 Sensor for heat
exchanger temperature
RAV464B-PE
4.4
No PARTS NAME
1 Indoor Unit fan motor
2 Running capacitor for
indoor fan motor
3 Transformer (Indoor Unit)
4 Sensor for room temperature
5 Sensor for heat
exchanger temperature

4. SPECIFICATIONS OF ELECTRICAL PARTS

TYPE
SMF-230-60-4A
EEP2G405HQA114
ST-9586
TYPE
STF-200-100-4B
EAG40M505UF
ST-9586
TYPE
STF-200-120-4B
EAG40M505UF
ST-9586
TYPE
STF-200-140-4F
EAG40M106UF
ST-9586
SPECIFICATIONS
Output (rated) 60W, 4 pole, 230V, 1 Phase, 50Hz
AC 400V, 4µF
AC 187-264V
Maximum input ûC
38mA
k½
Maximum input
15.5mA
SPECIFICATIONS
Output (rated) 100W, 4 pole, 200V, 1 Phase, 50Hz
AC 400V, 5µF
AC 187-264V
ûC
Maximum input
38mA
k½
Maximum input
15.5mA
SPECIFICATIONS
Output (rated) 120W, 4 pole, 200V, 1 Phase, 50Hz
AC 400V, 5µF
AC 187-264V
ûC
Maximum input
38mA
k½
Maximum input
15.5mA
SPECIFICATIONS
Output (rated) 140W, 4 pole, 200V, 1 Phase, 50Hz
AC 400V, 10µF
AC 187-264V
ûC
Maximum input
38mA
k½
Maximum input
15.5mA
31
15 20 25 30 40
16.1 12.6 10.0 8.0 5.2
ûC -12 10
k½ 67.5 21.3
15 20 25 30 40
16.1 12.6 10.0 8.0 5.2
ûC -12 10
k½ 67.5 21.3
15 20 25 30 40
16.1 12.6 10.0 8.0 5.2
ûC -12 10
k½ 67.5 21.3
15 20 25 30 40
16.1 12.6 10.0 8.0 5.2
ûC -12 10
k½ 67.5 21.3
