Table Of Contents - Toshiba RAV-164B-PE Service Manual

1. SPECIFICATIONS
2. CONSTRUCTIONS VIEWS
3. WIRING DIAGRAMS
4. SPECIFICATIONS OF ELECTRICAL PARTS
5. REFRIGERANT PIPING DIAGRAMS
6. PERFORMANCE CHARACTERISTICS
7. EXPLODED VIEWS AND PARTS LISTS
The units referred to within this Manual conform with the protection requirements of Directives 89/336/EEC
Electromagnetic Compatibility and 73/23/EEC Low Voltage.
Operating conditions of units are as follows:
OUTDOOR
TEMPERATURE
ROOM
TEMPERATURE
ROOM
HUMIDITY
Cooling Capacity is based on the following temperature conditions:
Note 1:
Indoor air inlet temperature 27ûC DB, 19ûC WB.
Outdoor air inlet temperature 35ûC DB.
For details on Control Circuits, refer to Service Manual A90-9925.
Note 2:
Metric/Imperial pipe conversion:
Note 3:
Diameter (mm)
Nominal Diameter (inch)
CONTENTS
SUMMARY
-2 to 43ûC
18 to 32ûC
LESS THAN 80%
6.4 9.5
1/4 3/8
2
12.7 15.9 19
1/2 5/8 3/4
3
15
23
31
41
46
49
22
7/8
