2.1 Indoor Unit
RAV-164B-PE
RAV-264B-PE
RAV-364B-PE
RAV-464B-PE
Unit dimension: A
Hanging bolt pitch: B
Model A
RAV-164B-PE 700
RAV-264B-PE 1000
RAV-364B-PE 1350
RAV-464B-PE 1350

2. CONSTRUCTION VIEWS

Rear return air
inlet knockouts
Air outlet
N-¿200
70
J=MxK H
60 80
Drain pipe connection
port (Inner diameter: 32.5)
B F G H
750 12.7 6.4 252
1050 15.9 9.5 252
1400 19.0 9.5 252
1400 19.0 9.5 252
320
Electrical box
Thermal insulator
75
Hanging bolt
Hanging bolt pitch: 565
4-M10
Provided at site
Refrigerant
piping joint
(Gas ¿F)
Refrigerant
piping joint
(Liquid ¿G)
(Port diameter: nominal
for PVC pipes) ¿35
Wiring connection port
Ensure that there is sufficient space around the
indoor unit for installation and servicing
J K M N
280 280 1 2
580 290 2 3
930 310 3 4
930 310 3 4
(Unit : mm)
15
Unit dimension: 800
6-¿4 Mounting screw
210
hole ¿160
720
630
340 80
60
80
320
270
Lower return
Air inlet
Indoor unit
300-400
Provide an inspection
hole in this position
¿125 Knockout
hole (rear)
(Fresh air inlet)
Inspection
hole
450
