ELECTRONIC VIEW FINDER

Setting User Controls

Custom Button Functions

Setting : Menu - Setting2 - Key Allocation
The left side of the EVF body contains the buttons PK, F1, F2, F3. The factory default for
these buttons are peaking (PK), Pixel to Pixel (F1), False Color 1 (F2), and Clip Guide (F3).
Each button can be customized to a particular feature by selecting CUSTOM SETUP on
the main menu.
Initial functions

Firmware Upgrade

Setting : Menu - System - Firmware
1. Firmware is upgradable by special cable.
2. Connect EVF and computer by cable.
3. Select On of Firmware Upgrade. The screen is changed to waiting message.
4. EVF starts firmware upgrade.
Peaking
PK
Pixel to Pixel
F1
Output
False Color 1
F2
Clip Guide
F3
Control1 Control2 Setting1 Setting2 System Exit
Color Adjust ▶
Screen Adjust ▶
Key Allocation ▶ PK Peaking
OSD ▶ F1 Pixel to Pixel
Audio Control ▶ F2 False Color 1
Exit F3 Clip Guide
Exit
PK-Back/Exit PK Key Allocation
Setting key Allocation
Control1 Control2 Setting1 Setting2 System Exit
Parameter Save
Paremeter Restore
Firmware Upgrade
Exit Cancle
PK-Back/Exit F/W Upgrade Set Ver V61
Firmware Upgrade
4C
EVF
21
EVF4C
