Dispersion Graphs - K-array Redline KR100S User Manual

Speaker power handling
Max power
Impedance
Frequency range
SPL 1W / 1mt
Maximum SPL
Frequency
Low frequency
High frequency
Connectors
Connectors
Connectors
Subwoofer power
Satellite power output
Operating range
Minimum operation voltage
Maximum operation voltage
Max continuos and
burst current
Dimensions
REV03
KR100S
Acoustics
500(sub) + 250(sat) W
1000(sub) + 600(sat) W
4Ω(sub) + 8Ω(sat)
40Hz - 19 KHz +/- 3dB (preset relating)
98.5 dB (sub) 98 dB (sat)
124dB continuous - 130 dB peak
Coverage
Horizontal
Vertical
Crossover
Type DSP controlled
Transducers
1 x 12" Neodymium speakers with 3" voice coil
16 x 2" Neodymium speakers with 0,75" voice coil
Audio Input
male + female parallel 3-pin balanced XLR
Wiring Pin1 = ground - Pin2 = hot - Pin3 = cold
Power Audio Output
Connector 4-pin Female Speakon
Wiring Pin1+= CH1+ Pin1= CH1- Pin2+= N.C. Pin2= N.C.
Remote control Input
1 x female 8 poles RJ45
Power Input
2 x PowerCon IN/OUT
Type 1 modules class D - DSP controlled
750 Watt
750 Watt
Protection Dynamic limiter, over current, over temp, short circuits
AC power
210 - 240 Vac 50Hz (Default)
100 - 120 Vac 60Hz (Selectable)
I. nom 3.6 A / 115 Vac - 2.2 A / 230 Vac
95 Vac - 195 Vac
125 Vac - 205 Vac
Default 6A(>10 sec) - 12A (<1 sec)
Selectable 10A(>10 sec) - 20A (<1sec)
Physical
KL12ma: 32.5 x 33.5 x 43.5 cm (12.91" x 13.19" x 17.13")
KR100: 5.7 x 120.5 x 7.4 cm (2.17" x 47.44" x 2.91")
Weight KL12ma: 15 Kg (33.07 lbs) KR100: 4.4 Kg (9.7 lbs)
(AES)
1
2
100°
7°
150 Hz
@4Ω
3
@4Ω
3

DISPERSION GRAPHS

8 KHz
4 KHz
90°
1 KHz
120°
500 Hz
250 Hz
150°
back 180°
-150°
-120°
-90°
8 KHz
4 KHz
1 KHz
90°
500 Hz
120°
250 Hz
150°
180°
back
-150°
-120°
-90°
vertical
Notes for data
1. Maximum RMS applicable power for a musical signal, the
reference signal is the one proposed by EIAJ standard.
2. Measured @4 mt then scaled @1 mt
the nominal load impedance.
New materials and design are introduced into existing products
without previous notice. Present systems may differ in some
respects from those presented in this brochure.
60°
30°
0°
front
-30°
-60°
horizontal
60°
30°
0°
front
-30°
-60°
