SGP SERIES PRESSURE WASHER
14
ALL MODELS
EXPLODED VIEW PARTS LIST
ITEM PART NO. DESCRIPTION
1 95-07290029 Tank Head Assembly,
16 Dia. x 8" Stack
2 10-02025A Label, Hot/Caliente w/Arrows
Warning
3 90-50045 Clip, Retaining, U-Type
4 95-07290053 Retainer, Burner Insulation
5 95-071218 Coil, Dura, 14.5" Dia., Sch. 80 1
6 95-07200129 Wrap, Outer Coil
7 2-0008 Nipple, 1/2" x M x M, Hex
8 95-07101225 Block, Discharge,
Brass 3/8" x 1/2"
9 2-0031 Elbow, 3/8" Street
10 2-2007 Nipple, 3/8" x 3/8" NPT ST Male 1
11 2-3408 Disk, Rupture Assy, 8000 PSI
12 2-90041 Clamp, Screw, #16
13 4-02130050 Hose, 7/8" Push-On,
Conduit
14 90-19710 Screw, 1/4" x 3/4" HH NC
15 7-01482 Insulation, Tank Bottom,
1 Blanket
16 95-07102227 Assy Frame
17 11-013 Label, Shark Logo Die-Cut
18 4-0307 Wheel & Tire, 6" Steel Rim
19 90-20041 Collar, 5/8" Bore Shaft
20 90-4005 Washer, 5/8", Flat, SAE
21 5-01021 Engine, Honda, GX270QAR2,
9 HP, 18 AMP (3030)
5-01072 Engine, Honda, GX340QNR2,
11 HP E/S, 18 AMP (3530E)
5-01070 Engine, Honda, GX340QAH2,
11 HP, 18 AMP (3530)
5-010720 Engine, Honda, GX390KQNR2,
13 HP E/S, 18 Amp (4035E)
22 5-2318 Pump, General, EZ-3035G
(303031)
5-2313 Pump, General,
EZ-3040G/WW961
(353031, 353031E)
5-23161 Pump, General, EZ-4035G34
(403531E)
5-1635 Pump, Legacy WMG-3030
(303037)
QTY ITEM PART NO.
22 5-1643
1
5-1636
2
3 23 4-02047725
1
24 2-30082
25 6-021720
1
1
26 2-0053
1
1
2-00601
1
27 5-3022
1
2.5 ft.
5-3151
9
1
5-3152
1
28 2-1024
2
29 2-10942
4
4
30 2-1088
4
31 2-9000
1
32 4-02100000
1
33 2-0115
1
2-011500
1
34 2-0115090
35 2-01167
1
36 2-01053
1
37 2-01052
1
38 95-07290007
39 2-0103
1
OPERATOR'S MANUAL
DESCRIPTION
Pump, Legacy TMG-4040
(403537E)
Pump, Legacy WMG-3535
(353037, 353037E, 403537E) 1
Hose, 3/8" x 25", 2 Wire,
Pressure Loop
Pump Protector, 1/2" PTP
Switch, Pressure N/O,
1/4" NPT SS
Elbow, 1/2" JIC, 3/8", 90°
(303031, 353031, 353031E,
403531E)
Elbow, 1/2" JIC x 3/8" FEM, 90°
(303037, 353037, 353037E,
403537E)
Unloader, PA 8 GPM @3650 PSI,
VB75L (303031, 353031,
353031E, 403531)
Unloader, APR.S 3000,
5.3 @3000 (303037, 353037,
353037E)
Unloader, APR 35, 8 @ 4000
(403537E)
Elbow, 1/2" Street, Brass
Swivel, 1/2" MP x 3/4" GHF
w/Strainer
Hose Barb, 1/4" Barb x 1/8" ML
Pipe, 90°
Clamp, Screw, #4
Hose, 1/4", Push-On, Fuel Line
(6 inches)
Box, Battery, M-100
(3530E, 4035E)
L Plate, Battery Box, Large,
PolyPro (3530E, 4035E)
Tank, Fuel, 6 Gal.
Cap, Fuel Tank, Plastic H60-AV 1
Mount, Rubber Vibration, 40 Duro
(Blue Dot)
Mount, Rubber Vibration,
30 Duro
Tab, Outer Wrap
Grommet, Rubber,
Nozzle Holder
