Instruction
manual
sicuro™ ISOFIX
Convertible Car Seat
To reduce the risk of serious injury or death, read this owner's
manual prior to installing and using this car seat.
Suitable for child from 9kg (around 12 months) to 36 kg (12 years).
Conforms to European ECE R44/04 in Group I, II & III as approved by
UNIVERSAL
GROUP I 9-18KG
designed & printed in NZ
Keep for future reference.
Land Transport NZ.
SEMI-UNIVERSAL
GROUP II 15-25KG
GROUP III 22-36KG
Advertisement
Table of Contents
Related Manuals for Edwards & Co sicuro ISOFIX
Summary of Contents for Edwards & Co sicuro ISOFIX
- Page 1 Instruction manual sicuro™ ISOFIX Convertible Car Seat Keep for future reference. To reduce the risk of serious injury or death, read this owner’s manual prior to installing and using this car seat. Suitable for child from 9kg (around 12 months) to 36 kg (12 years). Conforms to European ECE R44/04 in Group I, II &...
- Page 2 Introduction Hi there Firstly, thanks for choosing Edwards & Co - it truly means a lot to us that you have chosen one of our car seats to keep your family safe. A number of international surveys have consistently shown that a high proportion of child restraints are incorrectly installed and used.
-
Page 3: Table Of Contents
Contents GENERAL WARNINGS INSTALLATION INFORMATION WHERE TO INSTALL THE CAR SEAT FEATURES OF YOUR CAR SEAT SECURING THE SEAT TO YOUR CAR GROUP I (9-18KG) INSTALLATION SECURING THE HARNESS ADJUSTING THE HEIGHT OF THE HEAD REST & SHOULDER BELT GROUP II & III (15-36KG) BOOSTER SEAT INSTALLATION REMOVING THE HARNESS SYSTEM INSTALLING THE HARNESS SYSTEM... -
Page 4: General Warnings
GENERAL WARNINGS SERIOUS INJURY or DEATH, read this owner’s To reduce the risk of manual and your vehicle owner’s manual before installing and using this car seat. By properly using this car seat and following these instructions (and the instructions that accompany your vehicle), you will greatly reduce the risk of serious injury or death to your child from a collision. - Page 5 GENERAL WARNINGS • MUST NOT The belts be twisted under any circumstances. • DISCARD EVEN the seat if it is involved in a serious collision if no damage is visible. • This car seat should not be purchased or sold as a second hand item unless you are sure about it’s history.
-
Page 6: Installation Information
INSTALLATION INFORMATION • This car seat must always be installed to your car using it’s ISOFIX anchors combined with the top tether strap. • In Group I (9-18kg) your child must be secured using the seat’s harness system, and the the seat frame must be installed to your vehicle’s ISOFIX anchors combined with top tether. -
Page 7: Where To Install The Car Seat
Where to install the car seat IMPORTANT - this car seat is only suitable for approved vehicles fitted with a 3 point seat static or retractable seat belt. IMPORTANT - always install this car seat into a forward-facing passenger seat as indicated above. A forward-facing passenger seat faces towards the direction of the car’s movement. -
Page 8: Features Of Your Car Seat
Features of your car seat 1 - Lifting Handle 7 - Belt Guide Hole 2.1 - Group III Belt Guide Slot 8 - Lap Belt Guide 2.2 - Group II Belt Guide Slot 9 - Belt Yoke 3 - Headrest 10 - Base 4 - Peg 11 - Side Protection System... - Page 9 Features of your car seat (cont’d) 15 - Head Pillow 21 - Buckle Pad 16 - Cushion 22 - Sitting Pillow 17 - Shoulder Belt Pad 23 - Adjuster Cover 18 - Shoulder Belt 24 - Adjuster Belt 19 - Central Buckle 25 - Positioning Handle 20 - Crotch Strap designed in NZ...
-
Page 10: Securing The Seat To Your Car
Securing the seat to your car Place the car seat on the vehicle passenger seat. 2. Extend the ISOFIX anchors by rotating the ISOFIX adjuster button in an anti-clock wise direction and simultaneously pulling the ISOFIX anchor arm outwards (towards the seat) as far as it goes (1). - Page 11 Securing the seat to your car (cont.) 6. Hook the tether strap to your vehicle’s tether anchor point. Then tighten the strap as tight as possible (3). IMPORTANT - this seat must always be installed with ISOFIX and tether strap. This covers Group I, II and III. IMPORTANT - refer to your vehicle’s handbook before using this ISOFIX seat.
-
Page 12: Group I (9-18Kg) Installation
Securing your child to the harness GROUP I (9-18kg) Loosen the shoulder belts by pressing the release button found near the crotch (F8), and pulling the shoulder belts towards you (F9). IMPORTANT - be careful not to pull the shoulder belt pads when adjusting the shoulder belt. - Page 13 Securing your child to the harness cont. GROUP I (9-18kg) 5. Match buckle tongue sections together and insert them into the buckle (F13). 6. Tighten the shoulder belts by pulling the adjuster belt (F14). The belts should be tightly secured (so that you can only fit one or two fingers between your child’s shoulders and the belt).
-
Page 14: Adjusting The Height Of The Head Rest & Shoulder Belt
Adjusting the height of the head rest and shoulder belt GROUP I (9-18kg) The shoulder belt height can be raised or lowered by adjusting the head rest. To adjust the head rest, use one hand and squeeze the lever behind the head rest (F15)(15) whilst holding the seat with your other hand for support (FI5)(16), then raise or lower it and release the lever until you hear a CLICK! There are four headrest positions. -
Page 15: Group Ii & Iii (15-36Kg) Booster Seat
Using the restraint as a booster seat GROUP II (15-25KG) AND GROUP III (22-36KG) This installation method applies for a child within Group II( 15-25kg) and Group III (22-36kg). In this setting your child is restrained to the car seat using your vehicles 3-point seat belt. IMPORTANT - this car seat should be secured to your vehicle’s passenger seat using the ISOFIX anchors plus top tether. -
Page 16: Removing The Harness System
Removing the harness system Loosen the shoulder belts by pressing the release button of the adjuster (found near the crotch) and pulling the shoulder belts IMPORTANT - towards you as far as possible. avoid pulling the belt pads when doing so. For more information on adjusting the harness to the section “Securing your child to the harness”. - Page 17 Removing the harness system (cont..) 6. Remove the lower lap belt anchor clips (J) from the anchor housing inside the seat shell (1) & (2), by threading them through the seat shell (K) and back around behind the seat through slot (L). 2.
-
Page 18: Installing The Harness System
Installing the harness system Place the cover on the shell and fit is around the frame. Leave the bottom part of the cover loose. Installing the lap belts 2. Pull the lap belt anchor clip (F26)(C) through the belt clip slot (F26)(1) or (2). - Page 19 Installing the harness system (cont.) Installing the Shoulder Belts and Head Rest 4. Thread both the shoulder pad belts through the shell UNDER the metal bar and link them together on the yoke (F28)(J). 5. Thread the shoulder belts through the shoulder belt pads, head pillow, the cover and the shell;...
-
Page 20: Maintenance And Cleaning
Maintenance and cleaning Cleaning the fabric cover • Hand wash in warm water only. • NEVER tumble dry. Important information • NEVER lubricate or oil any part of the seat. • Only use mild detergents. • Only ever wipe clean the seat shell, harness and EPS foam lining. -
Page 21: Warranty Information
Warranty information All Edwards & Co products are guaranteed for two years from the date of purchase against defects in material and workmanship. If we determine that the product has a manufacturing fault, we will repair or replace it free of charge to you. The decision to repair or replace is solely at the discretion of Edwards &... - Page 22 www.edwardsandcobaby.com...
