Page 1: User Manual
User manual NIBE™ F2300 Air/water heat pump UHB GB 1508-1 231142... -
Page 3: Table Of Contents
1 Important information Installation data Safety information Safety precautions Serial number Contact information F2300 - An excellent choice 2 The heat pump – the heart of the house Heat pump function Contact with F2300 Maintenance of F2300 3 Disturbances in comfort... -
Page 4: Important Information
Product F2300 Serial number Installation date Installer Serial number must always be given Certification that the installation is carried out according to instructions in NIBE's installer manual and applicable regulations. Date __________________ Signed _________________________ Chapter 1 | Important information NIBE™ F2300... - Page 5 Balance temperature 0 °C Time delay addition 120min relay Stop temperature -20 °C Min. interval 60/55 between defrosting Start defrosting -3 °C Stop defrosting +20 °C Activation collar heater Activation de-icing Defrosting type Chapter 1 | Important information NIBE™ F2300...
-
Page 6: Safety Information
Rights to make any design or technical modifications are reserved. ©NIBE 2014. NOTE F2300 must be installed via an isolator switch with a minimum breaking gap of 3 mm. NOTE If the supply cable is damaged, only NIBE, its service representative or similar authorised person may re- place it to prevent any danger and damage. -
Page 7: Safety Precautions
This symbol indicates tips on how to facilitate using the product. Marking The CE marking means that NIBE ensures that the product meets all regu- lations that are placed on it based on relevant EU directives. The CE mark is obligatory for most products sold in the EU, regardless where they are made. - Page 8 Do not touch any buttons with wet hands. This can cause electric shocks. Do not shut off the power supply immediately after operation has start. Wait at least 5 minutes, otherwise there is a risk of water leakage or breakdown. Chapter 1 | Important information NIBE™ F2300...
- Page 9 Do not control the system with the main switch. This can cause fire or water leakage. In addition, the fan can start unexpectedly, which can cause personal injury. Chapter 1 | Important information NIBE™ F2300...
-
Page 10: Serial Number
The serial number can be found at the top left of the rear cover and on the foot of the product. Serial number Caution Always give the product's serial number when reporting a fault. Chapter 1 | Important information NIBE™ F2300... -
Page 11: Contact Information
NIBE Energy Systems France Sarl, Zone industrielle RD 28, Rue du Pou du Ciel, 01600 Reyrieux Tel : 04 74 00 92 92 Fax : 04 74 00 42 00 E-mail: info@nibe.fr www.nibe.fr NIBE Energy Systems Ltd, 3C Broom Business Park, Bridge Way, Chesterfield S41 9QG Tel: 0845 095 1200 Fax: 0845 095 1201 E-mail: info@nibe.co.uk... - Page 12 NIBE AB Sweden, Box 14, Hannabadsvägen 5, SE-285 21 Markaryd Tel: +46-(0)433-73 000 Fax: +46-(0)433-73 190 E-mail: info@nibe.se www.nibe.se For countries not mention in this list, please contact Nibe Sweden or check www.nibe.eu for more information. Chapter 1 | Important information...
-
Page 13: F2300 - An Excellent Choice
■ Intelligent control Integrated intelligent control for optimum control of the heat pump. At a start signal from an NIBE indoor module or thermostat F2300 is started. ■ F2300 has an automatic 2-step capacity regulator for the fan. Long service life ■... -
Page 14: The Heat Pump - The Heart Of The House
-3 °C 2 °C -3 °C 0 °C Heat source Värmekälla The temperatures are only examples and may vary between different installations and time of year. Chapter 2 | The heat pump – the heart of the house NIBE™ F2300... - Page 15 The temperatures are only examples and may vary between different installations and time of year. Chapter 2 | The heat pump – the heart of the house NIBE™ F2300...
-
Page 16: Contact With F2300
Contact with F2300 F2300 has an integrated control system that checks and monitors the heat pump operation. At installation the installer makes the necessary settings of the control system so that the heat pump will work optimally in your system. -
Page 17: Regular Checks
When your heat pump is located outdoors some external maintenance is required. NOTE Insufficient oversight can cause serious damage to F2300 which is not covered by the guarantee. Checking grilles Check that the inlet grille is not clogged by leaves, snow or anything else regularly throughout the year. -
Page 18: In Event Of Long Power Cuts
Care must be exercised so that the heat pump is not scratched when cleaning. Avoid spraying water into the grilles or the sides so that water penetrates into F2300. Prevent F2300 coming into contact with alkaline cleaning agents. Condensation drain pan and condensation water pipe The trough and drain pipe may require cleaning from leaves or similar during the year. -
Page 19: Power Consumption
DVD (Operation: 2 h/week) TV games console (Operation: 6 h/week) Radio/stereo (Operation: 3 h/day) Computer incl. screen (Operation: 3 h/day, standby 21 h/day) Bulb (Operation 8 h/day) Chapter 2 | The heat pump – the heart of the house NIBE™ F2300... - Page 20 After 1-2 years the heating curve should be adjusted again, as well as the heating curve offset and the building's thermostat valves, because the heating system, as a rule, requires a lower temperature once the drying process is complete. Chapter 2 | The heat pump – the heart of the house NIBE™ F2300...
-
Page 21: Disturbances In Comfort
The following tips can be used to rectify comfort disruption: Basic actions Start by checking the following possible fault sources: That the heat pump is running or that the supply cable to F2300 is con- ■ nected. Group and main fuses of the accommodation. -
Page 22: Low Room Temperature
■ External switch for changing the room heating activated. ■ Check any external switches. ■ Incorrect settings in NIBE SMO or NIBE indoor module ■ See the manual for the indoor module. ■ High room temperature External switch for changing the room heating activated. -
Page 23: Technical Data
4 Technical data Detailed technical specifications for this product can be found in the in- stallation manual (www.nibe.eu). Chapter 4 | Technical data NIBE™ F2300... -
Page 24: Glossary
Charge coil A charge coil heats the domestic hot water (tap water) in the heater with heating water from F2300. Charge pump See "Circulation pump". Circulation pump Pump that circulates liquid in a pipe system. -
Page 25: Domestic Hot Water
Evaporator Heat exchanger where the refrigerant evaporates by retrieving heat energy from the air which then cools. Chapter 5 | Glossary NIBE™ F2300... -
Page 26: Expansion Valve
Radiator Another word for heating element. They must be filled with water in order to be used with F2300. Refrigerant Substance that circulates around a closed circuit in the heat pump and that, through pressure changes, evaporates and condenses. During evap- oration, the refrigerant absorbs heating energy and during condensing, gives off heating energy. -
Page 27: Safety Valve
Supply temperature The temperature of the heated water sent by the heat pump to the heating system. Water heater Container where domestic water is heated. Is located somewhere outside the heat pump. Chapter 5 | Glossary NIBE™ F2300... -
Page 28: Index
In event of long power cuts, 16 Regular checks, 15 Disturbances in comfort Saving tips, 16 Troubleshooting, 19 Power consumption, 17 F2300 – An excellent choice, 11 Regular checks, 15 Glossary, 22 Safety precautions, 5 Heat pump function, 13 Saving tips, 16... - Page 32 NIBE AB Sweden Hannabadsvägen 5 Box 14 SE-285 21 Markaryd info@nibe.se www.nibe.eu 231142...
