Technical Specifications

Technical Specifications
WARNING
Minelab reserves the right to respond to ongoing technical progress by introducing changes in design, equipment
and technical features at any time.
GPZ 7000 Technical Specifications
Transmission
Coil
Audio Output
Liquid Crystal Display (LCD)
GPS Engine
FindPoints
WayPoints
GeoHunts
Length
Detector Weight
Operating Temperature Range
Operating Humidity Range
Storage Temperature Range
Storage Humidity Range
Operating Time (72Wh Battery)
Waterproof Rating - Coil
Waterproof Rating - Detector
Battery Technical Specifications
Type
Output Voltage
Capacity
Run Time
Weight
Battery Operating Temperature
Battery Storage Temperature
BC 10 Battery Charger Technical Specifications
BC 10 Operating Temperature
BC 10 Storage Temperature
BC 10 Input Voltage
BC 10 USB Output Current
Zero Voltage Transmission (ZVT)
GPZ 14 - 13" x 14" Super-D
6.3 mm (¼") Non-waterproof headphone socket, Wi-Stream wireless audio (UR 30 100Ω KOSS headphones supplied)
Full colour, 320 x 240 pixels, 72 mm x 54 mm (2.83" x 2.12")
u-blox Neo-7
Up to 100 (FP001 - FP100)
Up to 100 (WP001 - WP100)
Up to 10 (GH01 - GH10)
Collapsed: 1170 mm (46.1") Laid flat, packed position: 1304 mm (51.3")
Extended: 1526 mm (60.1") Laid flat, packed position: 1651 mm (65.0")
3.32 kg (7.32 lb) (Including GPZ 14 coil, skidplate and 72Wh battery)
0°C to 50°C (32°F to 122°F)
Up to 95% non-condensing
–20°C to 70°C (–4°F to 158°F)
Up to 98% Relative Humidity
8 hours (GPS, backlight and wireless enabled)
1 m (3')
Not Waterproof (Weatherproof only)
Li-Ion Rechargeable Battery Pack
Li-Ion: 7.2V DC
Li-Ion: 72 Wh
8 hours
Li-Ion pack: 370 g (0.82 lb)
0°C to 50°C (32°F to 122°F)
−5°C to 70°C (23°F to 158°F)
0°C to 45°C (32°F to 113°F)
−30°C to 80°C (−22°F to 176°F)
12 to 30 VDC
500 mA
