Airwell PNX 012 Service Manual
  1. Manuals
  2. Brands
  3. Airwell Manuals
  4. Air Conditioner
  5. PNX 012
  6. Service manual

Airwell PNX 012 Service Manual

Multi split cinco dci
Hide thumbs Also See for PNX 012:
Table of Contents

Advertisement

Quick Links

Multi Split Cinco DCI

Indoor Units

Outdoor Units

Model
Type
Model
PNX 009
PNX 012
PNX 018
PNX 021
PNX 024
HFD 007
HFD 009
HFD 012
HFD 018
HAD 007
HAD 009
HAD 012
HAD 018
HAD 021
HAD 024
XLF 009
XLF 012
CK 009
CK 012
CK 018
CK 021
CK 024
PXD 009
PXD 012
PXD 018
PXD 021
PXD 024
DLF 009
DLF 012
CINCO 100 DCI
DLF 018
DLF 021
YAZ5036-H11
DLF 024
DLS 018
DLS 021
DLS 024
REFRIGERANT

HEAT PUMP

R410A
MAY – 2010
SM CINCO 1-A.1 GB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PNX 012 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Airwell PNX 012

Summary of Contents for Airwell PNX 012

  • Page 1: Indoor Units

    Multi Split Cinco DCI Indoor Units Outdoor Units Model Type Image Model PNX 009 PNX 012 PNX 018 PNX 021 PNX 024 HFD 007 HFD 009 HFD 012 HFD 018 HAD 007 HAD 009 HAD 012 HAD 018 HAD 021...
