- Page 1 Packaged Air Conditioners air cooled: X AR / X ARV water cooled: X AO Centrales Autonomes de Climatisation à condensation par air: X AR / X ARV à condensation par eau: X AO Zentralklimageräte luftkühlung: X AR / X ARV wasserkühlung: X AO...
- Page 3 INSTALLATION INSTRUCTION NOTICE D’INSTALLATION INSTALLATIONSHANDBUCH ISTRUZIONI INSTALLAZIONE INSTRUCCIONES DE INSTALACIÓN...
-
Page 4: Table Of Contents
CONTENTS GENERAL RECOMMENDATIONS .......................3 SAFETY DIRECTIONS ................................3 WARNING ....................................3 EqUIpmENT SAFETY DATA ............................... 4 INSPECTION AND STORAGE ........................5 WARRANTY ...............................5 CONTENTS OF PACKAGE ..........................6 DIMENSIONS ............................6 NET WEIGHT ................................... 6 TECHNICAL SPECIFICATIONS ........................7 pOWER SUppLY ..................................7 INTERCONNECTION WITH OUTDOOR UNIT (AIR COOLED UNIT) ................... 7 DESCRIPTION ............................8 INSTALLATION ............................8 INSTALLATION OF THE INDOOR UNIT ............................. -
Page 5: General Recommendations
POWER SUPPLY MUST BE SWITCHED OFF BEFORE STARTING WORK IN THE ELECTRIC CONTROL BOX GENERAL RECOMMENDATIONS please read the following safety precautions very carefully before installing the unit. SAFETY DIRECTIONS Follow the safety rules in forces when you are working on your appliance. The installation, commissioning and maintenance of these units should be performed by qualified personnel having a good knowledge of standards and local regulations, as well as experience of this type of equipment. -
Page 6: Equipment Safety Data
EqUIPMENT SAFETY DATA Safety Data R407C Toxicity In contact with skin Liquid splashes or sprays may cause freeze burns. Unlikely to be hazardous by skin absorption. However, R407C may be slightly irritant and, if liquid, it has a strong degreasing effect. Flush contaminated skin areas with running water. -
Page 7: Inspection And Storage
INSPECTION AND STORAGE At the time of receiving the equipment carefully cross check all the elements against the shipping documents in order to ensure that all the crates and boxes have been received. Inspect all the units for any visible or hidden damage. -
Page 8: Contents Of Package
CONTENTS OF PACKAGE X 1100 / X 1900 1 indoor unit 1 wiring diagram 1 diagram key 1 set of grommets UC 34 / UC 54 1 outdoor unit DIMENSIONS 1100 1540 1900 1735 1000 NET WEIGHT X ARv X AO 1100 1900... -
Page 9: Technical Specifications
3 ~230 v* - 50 Hz 3N ~400 v - 50 Hz 3 ~230 v* - 50 Hz 3N ~400 v - 50 Hz models X AR X AO X AR X AO X ARv X AO X ARv X AO •... -
Page 10: Description
DESCRIPTION 1. Control cable - case of three-phase 400v. power supply without neutral. 2. Cable for remote control (accessory). 3. Interconnections to UC. 4. power cable. 5. condensate drain hose Ø0200x025. 6. Refrigerant lines to UC or cooling water inlet and outlet with hoses (length 1m - connection on female union nut Ø... -
Page 11: Unit Location
UNIT LOCATION The unit base shall be arranged as indicated in the manual. There could be a risk of personal injury or damage to property in the event of the unit being incorrectly supported. The unit must be installed on a firm level foundation, of adequate strength to support its full operating weight. 1. -
Page 12: Air Discharge And Intake
AIR DISCHARGE AND INTAKE 1. Direct air intake through the removable front panel A and the filter D (factory mounted). 2. Total rear air intake with duct: Duct E to be mounted on the rear of the unit connection elements (remove the panel J). ²... -
Page 13: Installation Of The Outdoor Unit
INSTALLATION OF THE OUTDOOR UNIT place the AIR COOLED condenser outdoors in a location not accessible to the public and without air pollution (smoke, acid, etc...). CLEARANCES. Respect the minimum dimension indicated for correct operation and to avoid air recycling, even partially between air intake and air discharge. INSTALLATION. -
Page 14: Pipes To Be Made On Site
REFRIGERANT LINES ² Supplied precharged in factory: MAXIMUM LENGTH 25M. ² Realized on the site by the installer: MAXIMUM LENGTH 45M. REFRIGERANT linking pipes up to 25m: ² GAS line: gas precharge (pipe Ø 1/2") ² LIqUID line (above to 2m): 55 g/m (pipe Ø... -
Page 15: Tightening Torque For Refrigerant Valves
TIGHTENING TORqUE FOR REFRIGERANT VALVES ² LIqUID: ² SUCTION: (small valve) 15Nm (large valve) 55Nm 1 Newton-meter = 0,1 meter-kilo FOLLOW THE CONNECTION INSTRUCTIONS FOR THE VALVES WITH NON-REMOVABLE MEMBRANES ² Line up the 2 half couplings. ² Remove the protective plugs on each coupling. ²... -
Page 16: Electrical Connections
ELECTRICAL CONNECTIONS The terminal box is located behind the lower front panel. The electrical connections are made on the terminal strip situated in the box according to the instructions "ELECTRICAL CONNECTIONS". CAUTION In the case of a casing heater it must be started according to the compressor is located: 2 hours before starting of the unit for a temperature of 10°C and 4 hours before starting for a temperature of 0°C. -
Page 17: Interconnections
INTERCONNECTIONS ~230 V - 50 Hz INTERCONNECTIONS WITH REMOTE CONTROL 1100 1900 COOLING + FAN (vS Nominal current maximum current Starting current Cable size mm² 4 x 1.5 4 x 1.5 HEATING + FAN (vS) Nominal current maximum current Starting current Cable size mm²... -
Page 18: Control Panel
CONTROL PANEL 1. ventilation On/Off switch 0 Off 1 On with warning light 2. Cooling selection NOTE: 0 Off With the automatic neutral zone cooling/ 1 Cooling operation heating thermostat supplied with the incorporated electric heating battery, 3. Heating selection automatic operation is obtained by setting 0 Off the two selectors 2 and 3 on position 1. - Page 19 Y que se han aplicado los siguientes apartados de las normas armonizadas. EN 378 EN 61 000-6-1 EN 61 000-6-3 EN 60 335-1 EN 60 335-2-40 EN 61 000-3-11 EN 61 000-3-12 A Tillières sur Avre 27570 - FRANCE Le: 25/09/2013 Sébastien Blard quality manager AIRWELL Industrie France...
- Page 20 AIRWELL I ndustrIe rance Route de Verneuil 27570 Tillières-sur-Avre FRANCE : +33 (0)2 32 60 61 00 & : +33 (0)2 32 32 55 13 As part of our ongoing product improvement programme, our products are subject to change without prior notice. Non contractual photos.
