Kunz AcrEase C60K, H60T, H60B, E60B Owner's Manual

60” finish cut
Hide thumbs Also See for AcrEase C60K, H60T, H60B, E60B:
Table of Contents

Advertisement

Quick Links

60" FINISH CUT
C60K
H60H
H60H
OWNER'S MANUAL
For Models: C60K, H60T, H60H & E60B
KUNZ ENGINEERING, INC.
With Assembly Instructions
/
MENDOTA, IL 61342
H60T
60T
E60B
E60B
/
PH (815) 539-6954
12/04

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AcrEase C60K, H60T, H60B, E60B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kunz AcrEase C60K, H60T, H60B, E60B

Summary of Contents for Kunz AcrEase C60K, H60T, H60B, E60B

  • Page 1 60” FINISH CUT C60K H60H H60H OWNER’S MANUAL With Assembly Instructions For Models: C60K, H60T, H60H & E60B KUNZ ENGINEERING, INC. H60T MENDOTA, IL 61342 E60B E60B PH (815) 539-6954 12/04...

  • Page 2: Assembly Instructions

    READ THE COMPLETE ASSEMBLY INSTRUCTIONS BEFORE STARTING THE ASSEMBLY. You should have: one mower deck assembly two caster assemblies two rear axle assemblies one tongue assembly (Lawn & Garden Hitching or ATV Tongue) one tow vehicle hitch assembly (only included on Lawn & Garden Hitching) Optional hitches: one tongue extension one rear hitch assembly...
  • Page 3 Note: Tighten the four wheel assembly pivot bolts so that the wheel assemblies will not flop down when the deck is raised off the ground. Caster Support Caster Support Stop B. INSTALLATION OF LAWN & GARDEN HITCHING (refer to the Operation and Adjustment Section for recommended hitching)(if the ATV Tongue was purchased refer to section C.
  • Page 4 5. The telescoping hitch can either be installed to the left or right and should clear the back of the tire by about 2”. 6. If one mower is pulled on both the left and right side of the tow vehicle, then one telescoping hitch can be mounted to the left and one to the right.

  • Page 5: Operations And Adjustments

    C. INSTALLATION OF ATV TONGUE ASSEMBLY (if the lawn and garden hitching was purchased refer to Section B. Installation of Lawn & Garden Hitching) 1. The tongue can be installed either on the left or right caster assembly depending on how the wing mower will be towed.
  • Page 6 A. HITCH CONFIGURATIONS (Refer to Figure 6) Shut off the engine and allow the mower blades to come to a complete stop before adjusting the spreader hitch on the tow vehicle. 1 & 2 combined or 5 1 & 2 combined or 5 Listed above are all of the possible configurations of the wing mowers.
  • Page 7 The hitching system is designed so that the wing mower can be pulled directly behind a tow vehicle without a mower deck or as a left or right wing mower when towed behind a tow vehicle with or without a mower deck. If more than one wing mower is towed, they can be pulled in tandem or one on the left and one on the right or a combination of the above conditions until the desired cutting width is obtained.

  • Page 8: Adjusting Cutting Height

    C. ADJUSTING CUTTING HEIGHT Shut off all engines and allow the mower blades to come to a complete stop on the wing mowers and on the tow vehicle before adjusting the cutting height. The cutting height can be adjusted in a range from 1.0" to 4.0". This is accomplished by adjusting the height adjusting bolts on each of the four corners of the wing mower.

  • Page 9: Starting Engine

    4. Adjust the cutting he ight on the wing mower so that it cuts at the sam vehicle mower. Adjust each corner of the wing mower so that the distance form the smoo surface to the bottom edge of the deck is equal to the cutting height minus 5/16”. The mower blade cutting edge is 5/16”...
  • Page 10 Start engine and move throttle toward slow position to disengage choke. The mower blades clutch will engage as the engine comes up to speed. The mower blades clutch engages at 1850 RPM. Slow engine speed to idle to allow engine to warm up. This will probably allow the mower blade clutch to fully disengage.

  • Page 11: Mower Operation

    For Model H60H: Set the throttle to slow so the mower blades clutch will disengage. Allow engine to cool down for a short time before moving the throttle control to the stop position. For Model E60B: Slow the engine speed down and disengage the clutch handle. Allow engine to cool down for a short time before moving the throttle control to the stop position.
  • Page 12 Look down, to the sides, and behind before and while backing to avoid backing over something or someone. Care should also be taken while backing so that the wing mower or mowers do not jackknife and damage hitches. Backing up with one wing mower is easy. Backing becomes a greater challenge as additional wing mowers are towed.
  • Page 13 G. DRIVE BELT REMOVAL AND TENSION Shut off engine and allow mower blades to stop turning before making any adjustments or repairs. Remove the safety shields. Loosen the nuts on the spring-loaded idler; adjust the nut until the belt can be slipped off the idler and drive sheaves.
  • Page 14 Figure 9: Belt Pattern and Spring Adjustment (Model C60K) For Model E60B: - See Figure 10. With the clutch engaged, adjust the nuts on the spring loaded idler adjuster bolt until the length of the spring is between 2-1/4” and 2-3/8”. This model comes with a belt brake when the clutch is disengaged.
  • Page 15 The Models E60B, H60T and H60H use the Kunz Engineering Part # (202134) blade bolt. This particular hex head bolt is a 3/8” – 24NF x 7/8” long, grade 5 and it’s proper torque is 35 ft-lbs.

  • Page 16: Tire Pressure

    I. LUBRICATION There are up to ten lubrication points on the wing mower -- one spring-loaded idler pivot, two caster wheel pivots, four wheels (on models that apply), and three blade spindles (on models that apply). Lubricate at approximately 10 hr. intervals or more often as required in dusty conditions. Lubricate the blade spindles 2-5 pumps every 50 hours.
  • Page 17 WING MOWER SPECIFICATIONS ENGINE: Engine Make Engine Model Cylinders Cycles Crankshaft Engine HP Bore Stroke Displacement Oil Capacity Crankshaft Dia. Key Slot Crankshaft Length Threaded Hole in End of Crankshaft Engine Mounting Bolts Starter Choke MOWER: Fuel Tank Effective Cutting Width Deck Construction Cutting Height Height Adjustment...
  • Page 18 WING MOWER SPECIFICATIONS ENGINE: Engine Make Engine Model Cylinders Cycles Crankshaft Engine HP Bore Stroke Displacement Oil Capacity Crankshaft Dia. Key Slot Crankshaft Length Threaded Hole in End of Crankshaft Engine Mounting Bolts Starter Choke MOWER: Fuel Tank Effective Cutting Width Deck Construction Cutting Height Height Adjustment...
  • Page 19 ACREASE WING MOWER PARTS MODEL C60K Item Part # Description 202135 Hex Head Bolt, 3/8" x 3" Fully Threaded 204000 Shoulder Bolt, 1/2" x 1-5/8" Shoulder Length 222005 Worm Drive Hose Clamp (7-7/8" to 9-1/8" Clamping Dia. 225000 Compression Spring, 1-1/2"L x 1-3/32" O.D. x .135" Wire dia. 226000 Plastic Wheel, 3"...
  • Page 20 MODEL C60K...
  • Page 21 ACREASE WING MOWER PARTS MODEL H60T Item Part # Description 202135 Hex Head Bolt, 3/8" x 3" Fully Threaded 204000 Shoulder Bolt, 1/2" x 1-5/8" Shoulder Length 222005 Worm Drive Hose Clamp (7-7/8" to 9-1/8" Clamping Dia. 225000 Compression Spring, 1-1/2"L x 1-3/32" O.D. x .135" Wire dia. 226000 Plastic Wheel, 3"...
  • Page 22 MODEL H60T...
  • Page 23 ACREASE WING MOWER PARTS MODEL E60B Item Part # Description 202135 Hex Head Bolt, 3/8" x 3" Fully Threaded 204000 Shoulder Bolt, 1/2" x 1-5/8" Shoulder Length 225003 Compression Spring, 3"L x 1-3/32" O.D. x .055" Wire dia. 226000 Plastic Wheel, 3" O.D. x 1/2" I.D. x 1-1/4" Wide 226001 Offset Wheel Assy., 13/500 x 6, 2 Ply Turf 226002...
  • Page 24 MODEL E60B...
  • Page 25 ACREASE WING MOWER PARTS MODEL H60H Item Part # Description 202135 Hex Head Bolt, 3/8" x 3" Fully Threaded 204000 Shoulder Bolt, 1/2" x 1-5/8" Shoulder Length 222005 Worm Drive Hose Clamp (7-7/8" to 9-1/8" Clamping Dia. 225000 Compression Spring, 1-1/2"L x 1-3/32" O.D. x .135" Wire dia. 226000 Plastic Wheel, 3"...
  • Page 26 MODEL H60H...

  • Page 27: Parts List

    LAWN & GARDEN HITCH PARTS Item Part # Description 202135 Hex Head Bolt, 3/8" x 3" Fully Threaded 216002 Wire Lock Pin, 5/16" x 2-1/4" Opening 216006 Wire Lock Pin, 3/8" x 2-1/4" Opening 600001 Spacer 600002 Tongue Pivot Angle 600006 Hitch Flat (5/16"...
  • Page 28 Item Part # Description 216002 Wire Lock Pin .31" X 2.50" 216009 Screw Pin Shackle Clevis 900057 Hitch Pivot 900082 Tongue OPTIONAL HITCH PARTS Item Part # Description 600006 Hitch Flat (5/16" Mounting Hole) 600020 Rear Hitch Tube 900000 Long Tongue Extension ATV TONGUE PARTS PARTS LIST PARTS LIST...
  • Page 29 Clean or Replace Any Safety Signs That Are not Readable or Damaged Replacement decals can be purchased from your local dealer or 275003 – Danger Decal, Cut Hand & Foot Serial # & Model # Decal Kunz Engineering Inc. Mendota, IL 61342 (815) 539-6954 www.kunzeng.com 275007 – Warning Decal,...

  • Page 30: Optional Equipment

    OPTIONAL FLOATATION KIT This optional floatation kit features an extra front and back tire that can be bolted in the center section of the mower deck. This is a great anti-scalp feature that helps to carry the center section of the mower deck and works well in the following applications: •...
