R&S
FSV-B30/-B31
®

DC Power Supply

Installation Guide

1310.9900.00 – 04

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R&S FSV-B30 and is the answer not in the manual?

Questions and answers

Summary of Contents for Rohde & Schwarz R&S FSV-B30

  • Page 1: Dc Power Supply

    R&S FSV-B30/-B31 ® DC Power Supply Installation Guide 1310.9900.00 – 04...
  • Page 2 ® The Installation Guide describes the following R&S FSV-B30/-B31 options: ® 1310.9897.02 (R&S FSV-B30) ® 1310.9874.02 (R&S FSV-B31) © 2012 Rohde & Schwarz GmbH & Co. KG Muehldorfstr. 15, 81671 Munich, Germany Phone: +49 89 41 29 - 0 Fax: +49 89 41 29 12 164 E-mail: info@rohde-schwarz.com Internet:...
  • Page 3: Basic Safety Instructions

    Basic Safety Instructions Always read through and comply with the following safety instructions! All plants and locations of the Rohde & Schwarz group of companies make every effort to keep the safety standards of our products up to date and to offer our customers the highest possible degree of safety. Our products and the auxiliary equipment they require are designed, built and tested in accordance with the safety standards that apply in each case.
  • Page 4 Basic Safety Instructions Symbol Meaning Symbol Meaning Warning! Hot surface Alternating current (AC) Protective conductor terminal Direct/alternating current (DC/AC) Ground Device fully protected by double (reinforced) insulation Ground terminal EU labeling for batteries and accumulators For additional information, see section "Waste disposal/Environmental protection", item 1.
  • Page 5 Basic Safety Instructions Operating states and operating positions The product may be operated only under the operating conditions and in the positions specified by the manufacturer, without the product's ventilation being obstructed. If the manufacturer's specifications are not observed, this can result in electric shock, fire and/or serious personal injury or death. Applicable local or national safety regulations and rules for the prevention of accidents must be observed in all work performed.
  • Page 6 Basic Safety Instructions 6. The product may be operated only from TN/TT supply networks fuse-protected with max. 16 A (higher fuse only after consulting with the Rohde & Schwarz group of companies). 7. Do not insert the plug into sockets that are dusty or dirty. Insert the plug firmly and all the way into the socket provided for this purpose.
  • Page 7 Basic Safety Instructions 2. Before you move or transport the product, read and observe the section titled "Transport". 3. As with all industrially manufactured goods, the use of substances that induce an allergic reaction (allergens) such as nickel cannot be generally excluded. If you develop an allergic reaction (such as a skin rash, frequent sneezing, red eyes or respiratory difficulties) when using a Rohde &...
  • Page 8 Basic Safety Instructions 2. Adjustments, replacement of parts, maintenance and repair may be performed only by electrical experts authorized by Rohde & Schwarz. Only original parts may be used for replacing parts relevant to safety (e.g. power switches, power transformers, fuses). A safety test must always be performed after parts relevant to safety have been replaced (visual inspection, protective conductor test, insulation resistance measurement, leakage current measurement, functional test).
  • Page 9 Instrucciones de seguridad elementales Waste disposal/Environmental protection 1. Specially marked equipment has a battery or accumulator that must not be disposed of with unsorted municipal waste, but must be collected separately. It may only be disposed of at a suitable collection point or via a Rohde &...
  • Page 10 Instrucciones de seguridad elementales Se parte del uso correcto del producto para los fines definidos si el producto es utilizado conforme a las indicaciones de la correspondiente documentación del producto y dentro del margen de rendimiento definido (ver hoja de datos, documentación, informaciones de seguridad que siguen). El uso del producto hace necesarios conocimientos técnicos y ciertos conocimientos del idioma inglés.
  • Page 11 Instrucciones de seguridad elementales Símbolo Significado Símbolo Significado Aviso: Cuidado en el manejo de dispositivos Distintivo de la UE para la eliminación por sensibles a la electrostática (ESD) separado de dispositivos eléctricos y electrónicos Más información en la sección "Eliminación/protección del medio ambiente", punto 2.
  • Page 12 Instrucciones de seguridad elementales 1. Si no se convino de otra manera, es para los productos Rohde & Schwarz válido lo que sigue: como posición de funcionamiento se define por principio la posición con el suelo de la caja para abajo, modo de protección IP 2X, uso solamente en estancias interiores, utilización hasta 2000 m sobre el nivel del mar, transporte hasta 4500 m sobre el nivel del mar.
  • Page 13 Instrucciones de seguridad elementales 6. Solamente está permitido el funcionamiento en redes de alimentación TN/TT aseguradas con fusibles de 16 A como máximo (utilización de fusibles de mayor amperaje solo previa consulta con el grupo de empresas Rohde & Schwarz). 7.
  • Page 14 Instrucciones de seguridad elementales Funcionamiento 1. El uso del producto requiere instrucciones especiales y una alta concentración durante el manejo. Debe asegurarse que las personas que manejen el producto estén a la altura de los requerimientos necesarios en cuanto a aptitudes físicas, psíquicas y emocionales, ya que de otra manera no se pueden excluir lesiones o daños de objetos.
  • Page 15 Instrucciones de seguridad elementales Reparación y mantenimiento 1. El producto solamente debe ser abierto por personal especializado con autorización para ello. Antes de manipular el producto o abrirlo, es obligatorio desconectarlo de la tensión de alimentación, para evitar toda posibilidad de choque eléctrico. 2.
  • Page 16 Instrucciones de seguridad elementales 2. Las asas instaladas en los productos sirven solamente de ayuda para el transporte del producto por personas. Por eso no está permitido utilizar las asas para la sujeción en o sobre medios de transporte como p. ej. grúas, carretillas elevadoras de horquilla, carros etc. Es responsabilidad suya fijar los productos de manera segura a los medios de transporte o elevación.
  • Page 17: Customer Support

    Customer Support Technical support – where and when you need it For quick, expert help with any Rohde & Schwarz equipment, contact one of our Customer Support Centers. A team of highly qualified engineers provides telephone support and will work with you to find a solution to your query on any aspect of the operation, programming or applications of Rohde &...
  • Page 18: Table Of Contents

    R&S FSV-B30/-B31 Table of Contents Table of Contents 1 DC Power Supply R&S FSV-B30............4 Installing the DC Power Supply..................4 Rear Panel View ......................5 Putting into Operation ....................5 1.3.1 Connecting the DC Power .....................6 1.3.2 Switching the Instrument On and Off................6 2 NiMH Battery Pack R&S FSV-B31............
  • Page 19: Dc Power Supply R&S Fsv-B30

    R&S FSV-B30/-B31 DC Power Supply R&S FSV-B30 1 DC Power Supply R&S FSV-B30 With the DC power supply FSV-B30, the R&S FSV can be operated by a DC voltage of 10 V to 15 V. 1.1 Installing the DC Power Supply The DC power supply is mounted to the rear panel of the R&S FSV.
  • Page 20: Rear Panel View

    R&S FSV-B30/-B31 DC Power Supply R&S FSV-B30 1.2 Rear Panel View Figure 1-2 shows the rear panel view of the R&S FSV. Figure 1-2: Rear panel view of the R&S FSV Figure 1-3: DC Power supply 1 = AC Power Supply Connection and Main Power Switch with fuse ON/OFF switch 2 = DC Power Supply ON/OFF switch 3 = Cigarette lighter plug with fuse 4 = Status LEDs...
  • Page 21: Putting Into Operation

    R&S FSV-B30/-B31 DC Power Supply R&S FSV-B30 1.3 Putting into Operation Shock hazard The used power supply (SELV) must fulfill the requirements for reinforced/double insulation for main supply circuits in accordance to DIN/EN/IEC 61010 (UL 61010B–1, CSA C22.2 No. 1010.1) or DIN/EN/IEC 60950 (UL 1950, CSA C22.2 No.
  • Page 22: Nimh Battery Pack R&S Fsv-B31

    R&S FSV-B30/-B31 NiMH Battery Pack R&S FSV-B31 2 NiMH Battery Pack R&S FSV-B31 With the optional battery pack FSV-B31 the R&S FSV3 or R&S FSV7 can be operated independently from an AC supply. 2.1 Installing the Battery Pack The battery pack is fixed to the instrument top. 1.
  • Page 23: Rear Panel View

    R&S FSV-B30/-B31 NiMH Battery Pack R&S FSV-B31 2.2 Rear panel view Figure 2-2 shows the rear panel view of the R&S FSV. Figure 2-2: Rear panel view of the R&S FSV 1 = Connector for AC adapter 2 = LED charging state 3 = DC output (cigarette lighter socket) 2.3 Putting into Operation Shock hazard...
  • Page 24 R&S FSV-B30/-B31 NiMH Battery Pack R&S FSV-B31 The battery pack is not charged in the factory. The battery pack must be charged before it is used the first time. A new battery pack or a battery pack which has not been used for a longer time attains full capacity after several charge/ discharge cycles.
  • Page 25: Connecting The Dc Power

    R&S FSV-B30/-B31 NiMH Battery Pack R&S FSV-B31 2.3.2 Connecting the DC Power Connect the R&S FSV DC supply to the battery pack using the cigarette lighter plug. 2.3.3 Switching the Instrument On and Off Switching the instrument on 1. Press the DC power switch at the DC power supply to position "I". A green LED indicates that the DC supply is ready for operation.
