www.smartwitness.com
CVR500
High Resolution Camcorder Pen
BE F OR E Y O U BEG IN
Please unpack the box carefully and identify that all the parts are present.
The camera is suitable for indoor use only.
Make sure you charge the camera batteries using the recommended charger. Damage
caused to the camera by incorrect voltage is not covered by the warranty.
Do not attempt to open the casing to access the camera. Damage caused to the camera by
tampering with the camera casing is not covered by the warranty.
CVR500 v2.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CVR500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SmartWitness CVR500

Summary of Contents for SmartWitness CVR500

  • Page 1 Do not attempt to open the casing to access the camera. Damage caused to the camera by tampering with the camera casing is not covered by the warranty. CVR500 v2.0...

  • Page 2: Product Description

    P RODU CT D ESCRIP T ION The CVR500 is a high quality and fully portable colour camera and recording unit encased inside a working pen. The built in pinhole camera enables Manual and Continous recording, allowing images to be stored to the internal Flash memory.
  • Page 3 CONT E NT S Pen Camcorder USB 2.0 lead Mains Charger Spare Refill...

  • Page 4: Reset Button

    I D E N TI F Y I N G T H E P A R T S NOTE: To access the USB 2.0 Connection, detach the pen by unscrewing it from this point. 1. Camera 2. Microphone 3. USB 2.0 Connection To connect computer or charger.

  • Page 5: Led Indicator

    U S I N G TH E D I F F E R E N T M O D E S Pho to F u n ct i o n Action Description LED indicator Blue = ON Press the ON/OFF button for 1 second. Turn unit ON (Unit will go into picture-standby mode) Red = OFF...
  • Page 6 U S I N G T H E D IF F E R E N T M O DE S ( co n t i n ued) V id e o F u n c t i o n Action Description LED indicator Blue = ON...

  • Page 7: Ba C K U P & Pla Y Ba Ck

    U S I N G TH E DI F F ER E NT M ODE S ( continued) Tur n i n g t h e u n it OF F In any status, press the button for 4 seconds and the Pen Camcorder will automatically save the current file and shutdown.
  • Page 8 C H A R G I N G TH E B A T T E R Y The Pen Camcorder will turn itself OFF when the battery has been used up. It will save any files being recorded before automatically shutting down. To charge the battery you can either: 1.
  • Page 9 S E T TI N G TH E T I M E & D A T E The time and date settings can be set using a PC or Mac. The time and date will be saved in the recorded files, and will be shown when playing back. Once set, the time and date will be saved forever until the time and date are re-set or if the Pen Camcorder is formatted/reset.

  • Page 10: Troubleshooting

    C H A N GI N G T H E R E F I L L C A R T R I D G E A refill cartridge is supplied with the Pen Camcorder. To replace the cartridge: 1. Twist and pull the lower half of the pen casing to reveal the current cartridge head.

  • Page 11: Specifications

    SPECIFICATIONS Model: CVR500 Picture Type: Colour Image Sensor: Digital CMOS Video Compression: MJPEG Video Resolution/Format: 640x480 @ 25 fps / AVI Image Resolution 8 Megapixels / JPEG Video File size: Approx. 500kB per minute Memory: 2.0GB (Internal Flash memory) Lens Viewing Angle: 92°...

  • Page 12: Technical Support

    W A R R A NT Y TECHNICAL SUPPORT For Technical Support please contact your local distributor. LIMITED WARRANTY This product is supplied with a 1 Year warranty. The Warranty excludes products that have been misused (including accidental damage) and damage caused by normal wear and tear.
