- Page 1 LSX Low Smoke Convertor Operations Manual V. 04.25.07 lemaitrefx.com...
-
Page 2: Table Of Contents
Table of Contents Page 1 Introduction Page 2 Warning Page 3 Technical Specifications Page 4 Operating Procedure Page 5 Control Panel Operations Page 5 Before Requesting Service Page 6 Recommended Fluids Page 7 Warranty Page 8 Safety Precautions Please Read Carefully Before Operating lemaitrefx.com... -
Page 3: Introduction
Congratulations on your purchase of a Le Maitre LSX MKII Low Smoke Convertor. With basic care, your LSX will provide years of trouble-free preformance. The LSX is a product of many years of research and development resulting in a machine with many fine features and excep- tional reliability. -
Page 4: Warning
Warning Important Safety Instructions: Do not remove the outer case until power has been disconnected from the machine. Important Safety Instructions: Persons suffering from asthma or allergenic sensitivity may experience irritation, discomfort, or allergic symptoms when exposed to fog effects. Important Safety Instructions: Ensure that this unit is grounded at all times. -
Page 5: Technical Specifications
Technical Specifications Model: CLP 2930 LSX Low Smoke Convertor CLP 2915 LSX Low Smoke Convertor 220 Volt Length: 59” 150cm Width: 29.5” 75cm Height: 28” 71cm Net Weight: 150lbs 68kg Rating: 12 amps @ 110 volts @ 60 hz LSX Low Smoke Convertor 28”... -
Page 6: Operating Procedure
This unit requires a 15 amp circuit to run properly. The use of any extension cords or shared circuit is strongly not recommended. It is essential that Le Maitre’s Genuine LSX Molecular Fluid is used in the Fog Machine to achieve optimum effect. -
Page 7: Control Panel Operations
Control Panel Operations Fan Knob: this controls the speed of the lower fan. Turning clockwise reduces the speed. Off is at the counter clockwise end. Note: It is not recommended to leave the control left in the ‘Off’ position or in a very low setting, the low pressure switch may activate turning off the compres- sor. -
Page 8: Recommended Fluids
We have decided that there are many other applications for this fluid. When using this in the LSX or LSG, you will find it works very well if you are having problems with the smoke rising too quickly. It has also been used for quick burst-of-steam effects, nitrogen bursts, etc. -
Page 9: Warranty
Any product not returned within 30 days is considered purchased. Warning: Le Maitre Special Effects Inc. considers all it's product to be safe for use in the application it was intended. Le Maitre Special Effects takes no responsibility for misuse or incorrect use. Always refer to equip- ment owners manual for proper use. -
Page 10: Safety Precautions
2. Do not modify the machine or use a machine which has been damaged in any way. 3. Allow sufficient air circulation around the machine at all times. 4. Protect the LSX from direct weather effects and wet locations. 5. Only use fluids recommended by the Le Maitre Special Effects.
