Foscam P2P Quick Installation Manual

One Minute Quick Installation Guide
P2P HD IP Camera
ShenZhen Foscam Intelligent Technology Co.,Ltd
1
Connect the IP Camera to the Internet
You just need to choose either of the following two ways, quick connect
cameras and the internet.
Wired Connection
WPS Wi-Fi Protected Set-up Connection
FI9821E does not support WPS.
Wired Connection
Internet
Router
WPS
Mount the antenna and make it stand vertically(only for the device
with external antenna).
Connect the camera to the LAN network (router or switch) via network
cable.
Connect the power adapter to the camera.
WPS Connection
Before using the WPS connection,the matters need attention.
Please make sure that your router supports WPS function, and has
been connected to the network.
If the camera have connected the network cable, please disconnect it.
V4.3
Mount the antenna and make it stand vertically.
Connect the power adapter to the camera.
Press and hold the WPS button for two seconds.
Press the WPS button on your wireless router within 60 seconds.
The camera will automatically create a secure wireless connection to
your router in about 60 seconds.
Note:
If your router does not support WPS or WPS connection failed, please refer
to the IP Camera User Manual for manual wireless connection setup.
2
Access the IP Camera by Smart Phone
(Android or iOS operating system)
If you use android or iOS mobile device, you can access the IP camera by
ANT
AUDIO
Foscam APP. Mobile phone connecting the camera after the success,
SD
OUT IN
recommend that you modify the user name and password.
This document takes Android system as an example, the iOS and android
interface only subtle differences, you can still complete the operation in
accordance with this example.
Download and Install the Foscam APP
Search and install Foscam Viewer on APP Store or Google Play for
iOS or Android devices.
Click the Foscam Viewer on your phone to run the APP.
In the IPC management interface,click
QR code scanning mode.
Click here
When you finish the QR code scanning, the UID will be input
automatically, then input Device Name, Username(default is admin),
Password(blank by default),click OK.
Note:
If the QR code scanning is not successful, click
on the bottom of the camera manually. The procedure for inputting data
is as follows.Click OK.
. Your phone will go into the
So far, the camera has been added successfully. You can click it from
the list to check the live video.
If you scan a QR code on the bottom of the camera
successfully, the UID will be displayed automatically.
Default username is admin with no password.
Click OK.
, please input the UID
Select High Definition.
Select P2P UID.
Please input the UID on the bottom
of the camera manually.
Default username is admin with no
password.
