  • Page 1 Welcome to the Iceberg Relion 4724 Motherboard Manual...
  • Page 2 X8DT6 X8DTE X8DT6-F X8DTE-F USER’S MANUAL Revision 1.0...
  • Page 3 The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes no responsibility for any inaccuracies that may be contained in this document, makes no commitment to update or to keep current the information in this manual, or to notify any person or organization of the updates.

  • Page 4: Preface

    Path Interconnect (QPI) Technology, providing the next generation point-to-point system interface to replace the current Front Side Bus. With the 5500 Series Pro- cessor platform built in, the X8DT6/X8DT6-F/X8DTE/X8DTE-F offers substantial enhancement in system performance with increased bandwidth and unprecedented scalability optimized for high-end servers, High Performance Computing (HPC) sys- tems and intensive applications.
  • Page 5 X8DT6/X8DT6-F/X8DTE/X8DTE-F User's Manual Warning: Important information given to ensure proper system installation or to prevent damage to the components. Note: Additional Information given to differentiate various models or to ensure correct system setup.

  • Page 6: Contacting Supermicro

    Contacting Supermicro Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML 's-Hertogenbosch, The Netherlands Tel:...

  • Page 7: Table Of Contents

    Slow Blinking LED for Suspend-State Indicator ..........1-11 Main Switch Override Mechanism ..............1-11 Wake-On-LAN (WOL) ..................1-11 Power Supply ....................1-12 Super I/O ....................... 1-12 Overview of the Winbond WPCM450 Controller (For X8DT6-F/X8DTE-F Only) ........................1-13 Chapter 2 Installation Static-Sensitive Devices .................. 2-1 Precautions ..................... 2-1 Unpacking .......................
  • Page 8 Internal Speaker ..................2-22 Power LED/Speaker ................. 2-22 Wake-On-LAN ..................2-23 Overheat LED/Fan Fail (JOH1) ..............2-23 T-SGPIO Headers ..................2-24 RAIDKey Header (Optional for X8DT6/X8DT6-F only) ......2-24 Power SMB (I C) Connector ..............2-25 IPMB I C SMB ..................2-25 Jumper Settings ....................
  • Page 9 X8DT6/X8DT6-F/X8DTE/X8DTE-F User's Manual Serial ATA Ports..................2-33 SAS Ports (X8DT6/X8DT6-F only) ............2-33 Chapter 3 Troubleshooting Troubleshooting Procedures ................3-1 Before Power On .................... 3-1 No Power ......................3-1 No Video ......................3-2 Losing the System’s Setup Confi guration ............3-2 Memory Errors ....................

  • Page 10: Chapter 1 Introduction

    • Four (4) Serial ATA cables (CBL-0044L) (For X8DT6/X8DT6-F) • Six (6) Serial ATA cables (CBL-0044L) (For X8DTE/X8DTE-F) • Two (2) SAS cables for SATA/SAS Backplane (CBL-0097L-02) (For X8DT6/ X8DT6-F) • One (1) I/O backpanel shield (MCP-260-00027-0N) • One (1) Supermicro CD containing drivers and utilities •...
  • Page 11 X8DT6/X8DT6-F/X8DTE/X8DTE-F User's Manual X8DT6/X8DT6-F Image Note: The drawings and pictures shown in this manual were based on the latest PCB Revision available at the time of publishing of the manual. The motherboard you’ve received may or may not look exactly the same as...
  • Page 12 IPMI Dedicated LAN is for X8DT6-F/X8DTE-F only. SAS connectors, jumpers, and the LSI 2008 SATA 2 chip are available on the X8DT6/X8DT6-F only. For SAS RAID confi guration, refer to the LSI User Guide posted on our website @ http://www.supermicro.com/support/manuals/ IPMI 2.0 and the Dedicated LAN (w/KVM support) are available on the...
  • Page 13 X8DT6/X8DT6-F/X8DTE/X8DTE-F User's Manual Motherboard Layout FAN5 P1-DIMM3A JPI2C1 JPW2 JPW3 JPW1 P1-DIMM3B FAN1 FAN6 P1-DIMM2A P1-DIMM2B P1-DIMM1A FAN7 P1-DIMM1B CPU2 CPU1 Fan CPU1 FAN2 P2-DIMM1B P2-DIMM1A P2-DIMM2B P2-DIMM2A P2-DIMM3B FAN8/ CPU2 Fan P2-DIMM3A SLOT7 PCI-E 2.0 X8 FAN3 X8DT6/E Series Rev.

  • Page 14: X8Dt6/E-F Quick Reference

    System/CPU Fan Headers (Fans 7~8: CPU Fans) Floppy Floppy Disk Drive Connector JIBTN1 RAIDKey for RAID 5 SAS support (optional for X8DT6/X8DT6-F) IPMB I C Header (for an IPMI card) (X8DTE-F/X8DT6-F) PWR LED/Speaker Header (Pins 4~7: Speaker) Front Panel Connector...

  • Page 15: Motherboard Features

    Intel 5520 chipset, including: the 5520 (IOH-36D) and the ICH10R (South Bridge). Expansion Slots • Three PCI-E 2.0 x8 slots (Slots 5~7) (X8DT6/X8DT6-F) • Four PCI-E 2.0 x8 slots (Slots 4~7) (X8DTE/X8DTE-F) • One PCI-E 2.0 x4 slot (Slot 3) •...
  • Page 16 Up to eight USB 2.0 (Universal Serial Bus) (2 Backpanel USB Ports, 2 Front USB Headers, and 2 Type A Headers) • Super I/O: Winbond W83627HG • IPMI 2.0 with full KVM support (X8DT6-F/X8DTE-F only) (Note 3) Other • Wake-on-LAN (WOL) •...
  • Page 17 X8DT6/X8DT6-F/X8DTE/X8DTE-F User's Manual #0-6 #1-6 #1-5 #0-5 #1-4 #0-4 #1-3 #0-3 #1-2 #0-2 #1-1 #0-1 Processor #2 Processor #1 PCI-E X8 Ports #7-8 Intel 5520 PCI-E X8 Ports #5-6 IOH-36D PCI-E X4 Ports #1-2 Ports PCI-E X8 #3-4 Ports PCI-E X8...

  • Page 18: Chipset Overview

    Chapter 1: Introduction Chipset Overview Built upon the capability of the Intel 5520 platform, the X8DT6/X8DT6-F/X8DTE/ X8DTE-F motherboard provides the performance and feature set required for dual- processor-based high-end servers optimized for High Performance Computing (HPC), Clustering, and intensive applications. The 5520 platform consists of the 5500 Series (LGA 1366) processor, the 5520 (IO Hub), and the ICH10R (South Bridge).

  • Page 19: Special Features

    To avoid possible system overheating, please be sure to provide adequate airfl ow to your system. System Resource Alert This feature is available when used with Supero Doctor III in the Windows OS 1-10...

  • Page 20: Acpi Features

    Chapter 1: Introduction environment or used with Supero Doctor II in Linux. Supero Doctor is used to notify the user of certain system events. You can also confi gure Supero Doctor to provide you with warnings when the system/CPU temperatures, voltages and fan speeds go beyond a pre-defi...

  • Page 21: Power Supply

    It is even more important for processors that have high CPU clock rates. The X8DT6/X8DT6-F/X8DTE/X8DTE-F can accommodate 24-pin ATX power sup- plies. Although most power supplies generally meet the specifi cations required by the CPU, some are inadequate. In addition, the two 12V 8-pin power connections are also required to ensure adequate power supply to the system.

  • Page 22: Overview Of The Winbond Wpcm450 Controller (For X8Dt6-F/X8Dte-F Only)

    SMI or SCI function pin. It also features auto power management to reduce power consumption. Overview of the Winbond WPCM450 Controller (For X8DT6-F/X8DTE-F Only) The Winbond WPCM450 Controller is a Baseboard Management Controller (BMC) that supports the 2D/VGA-compatible Graphics Core with the PCI interface, Virtual Media, and Keyboard/Video/Mouse Redirection (KVMR) modules.
  • Page 23 X8DT6/X8DT6-F/X8DTE/X8DTE-F User's Manual Notes 1-14...

  • Page 24: Chapter 2 Installation

    Chapter 2: Installation Chapter 2 Installation Static-Sensitive Devices Electrostatic Discharge (ESD) can damage electronic com ponents. To prevent dam- age to your system board, it is important to handle it very carefully. The following measures are generally suffi cient to protect your equipment from ESD. Precautions •...

  • Page 25: Motherboard Installation

    X8DT6/X8DT6-F/X8DTE/X8DTE-F User's Manual Motherboard Installation All motherboards have standard mounting holes to fi t different types of chassis. Make sure that the locations of all the mounting holes for both motherboard and chassis match. Although a chassis may have both plastic and metal mounting fasteners, metal ones are highly recommended because they ground the mother- board to the chassis.

  • Page 26: Processor And Heatsink Installation

    Chapter 2: Installation Processor and Heatsink Installation When handling the processor package, avoid placing direct pressure on the label area of the fan. Notes: Always connect the power cord last and always remove it before adding, re- moving or changing any hardware components. Make sure that you install the processor into the CPU socket before you install the CPU heatsink.
  • Page 27 X8DT6/X8DT6-F/X8DTE/X8DTE-F User's Manual After removing the plastic cap, using your thumb and the index fi nger, hold the CPU at the north and south center edges. Align the CPU key, the semi- circle cutout, against the socket key, the notch below the gold color dot on the side of the socket.

  • Page 28: Installing A Cpu Heatsink

    Chapter 2: Installation Installing a CPU Heatsink Do not apply any thermal grease to the heatsink or the CPU die because the required amount has already been ap- plied. Screw#1 Screw#2 Place the heatsink on top of the CPU so that the four mounting holes are aligned with those on the retention mechanism.
  • Page 29 X8DT6/X8DT6-F/X8DTE/X8DTE-F User's Manual Removing the Heatsink Warning: We do not recommend that the CPU or the heatsink be re- moved. However, if you do need to remove the heatsink, please follow the instructions below to uninstall the heatsink and prevent damage to the CPU or other components.

  • Page 30: Memory Installation

    Release Note: Notch Release should align with the receptive point X8DT6/E Series Rev. 1.0 on the slot To Install: Insert module vertically and press down until it snaps into place. Pay attention to the alignment notch at To Remove: the bottom.

  • Page 31: Memory Support

    DIMMs Memory Support The X8DT6/X8DT6-F/X8DTE/X8DTE-F supports up to 96 GB of Registered ECC or up to 24 GB of Unbuffered ECC/Non ECC DDR3 1333 MHz/1066 MHz/800 MHz in 12 DIMMs. Please note that Memory Speed support is also depending on the type of CPU used in the motherboard.
  • Page 32 Chapter 2: Installation 4 GB of RAM is used. The reduction in memory availability is dispropor- tional. (See the following Memory Availability Table.) Possible System Memory Allocation & Availability System Device Size Physical Memory Remaining (-Available) (4 GB Total System Memory) Firmware Hub fl...

  • Page 33: Control Panel Connectors/Io Ports

    X8DT6/X8DT6-F/X8DTE/X8DTE-F User's Manual Control Panel Connectors/IO Ports The I/O ports are color coded in conformance with the PC 99 specifi cation. See the picture below for the colors and locations of the various I/O ports. 1. Back Panel Connectors/IO Ports X8DT6/E Series Rev.
  • Page 34 See the table at Ground Ground right for pin defi nitions. Mouse/KB VCC Mouse/KB VCC (+5V) (+5V) KB Clock Mouse Clock No Connection No Connection VCC: with 1.5A PTC (current limit) 1. Keyboard (Purple) 2. Mouse (Green) X8DT6/E Series Rev. 1.0 2-11...

  • Page 35: Universal Serial Bus (Usb)

    X8DT6/X8DT6-F/X8DTE/X8DTE-F User's Manual Universal Serial Bus (USB) Back Panel USB Front Panel USB (USB 0/1) (USB 2/3) Two Universal Serial Bus ports (USB Pin# Defi nitions Pin# Defi nition 0 and USB 1) are located on the I/O back panel. Additionally, six USB con-...

  • Page 36: Serial Ports

    A Video (VGA) connector is located next to COM Port1 on the IO back- plane. This connector is used to provide video display. Refer to the board layout below for the location. 1. COM1 2. COM2 3. VGA X8DT6/E Series Rev. 1.0 2-13...

  • Page 37: Ethernet Ports

    IO backplane. In ad- P2V5SB SGND dition, an IPMI_dedicated_LAN is also TD0+ Act LED located on the X8DT6-F/X8DTE-F to TD0- P3V3SB provide KVM support for IPMI 2.0. All TD1+ Link 100 LED these ports accept RJ45 type cables.

  • Page 38: Front Control Panel

    Supermicro server chassis. See the fi gure below for the descriptions of the various control panel buttons and LED indicators. Refer to the following section for descriptions and pin defi nitions. JF1 Header Pins X8DT6/E Series Rev. 1.0 Ground Power LED...

  • Page 39: Front Control Panel Pin Defi Nitions

    X8DT6/X8DT6-F/X8DTE/X8DTE-F User's Manual 3. Front Control Panel Pin Defi nitions NMI Button NMI Button The non-maskable interrupt button Pin Defi nitions (JF1) header is located on pins 19 and 20 Pin# Defi nition of JF1. Refer to the table on the right Control for pin defi...

  • Page 40: Hdd Led

    Refer to the table on the right for pin defi nitions. A. HDD LED B. NIC1 LED C. NIC2 LED Ground Power LED HDD LED NIC1 LED NIC2 LED X8DT6/E Series Rev. 1.0 OH/Fan Fail LED PWR Fail LED Reset Reset Button Ground Power Button Ground 2-17...

  • Page 41: Overheat (Oh)/Fan Fail Led

    X8DT6/X8DT6-F/X8DTE/X8DTE-F User's Manual Overheat (OH)/Fan Fail LED OH/Fan Fail LED Pin Defi nitions (JF1) Connect an LED Cable to the OH/ Pin# Defi nition Fan Fail connection on pins 7 and 8 of JF1 to provide advanced warnings Ground of chassis overheating or fan failure.

  • Page 42: Reset Button

    Refer to the table on the right for pin defi nitions. A. Reset Button B. PWR Button Ground Power LED HDD LED NIC1 LED NIC2 LED X8DT6/E Series Rev. 1.0 OH/Fan Fail LED PWR Fail LED Reset Reset Button Ground Power Button Ground...

  • Page 43: Connecting Cables

    X8DT6/X8DT6-F/X8DTE/X8DTE-F User's Manual Connecting Cables ATX Power 24-pin Connector Pin Defi nitions Pin# Defi nition Pin # Defi nition Power Connectors +3.3V +3.3V -12V +3.3V A 24-pin main power supply connector(JPW1) and two 8-pin CPU PWR connectors (JPW2/ PS_ON JPW3) are located on the motherboard.

  • Page 44: Fan Headers

    H. Fan 8 (CPU2 Fan) P2-DIMM2A P2-DIMM3B FAN8/ I. Chassis Intrusion CPU2 Fan P2-DIMM3A SLOT7 PCI-E 2.0 X8 FAN3 X8DT6/E Series Rev. 1.0 SLOT6 PCI-E 2.0 X8 SLOT5 PCI-E 2.0 X8 SLOT4 PCI-E 2.0 X8 LED1 SAS0~3 SLOT3 PCI-E 2.0 X4 SAS4~7...

  • Page 45: Internal Speaker

    X8DT6/X8DT6-F/X8DTE/X8DTE-F User's Manual Internal Speaker Internal Buzzer (SP1) Pin Defi nition The Internal Speaker, located at SP1, Pin# Defi nitions can be used to provide audible indica- Pin 1 Pos. (+) Beep In tions for various beep codes. See the Pin 2 Neg.

  • Page 46: Wake-On-Lan

    FAN2 P2-DIMM1B P2-DIMM1A P2-DIMM2B P2-DIMM2A P2-DIMM3B FAN8/ CPU2 Fan P2-DIMM3A SLOT7 PCI-E 2.0 X8 FAN3 X8DT6/E Series Rev. 1.0 SLOT6 PCI-E 2.0 X8 SLOT5 PCI-E 2.0 X8 SLOT4 PCI-E 2.0 X8 LED1 SAS0~3 SLOT3 PCI-E 2.0 X4 SAS4~7 JIBTN1 T-SGPIO1...

  • Page 47: T-Sgpio Headers

    X8DT6/X8DT6-F/X8DTE/X8DTE-F User's Manual T-SGPIO Headers T-SGPIO Two SGPIO (Serial-Link General Pin Defi nitions Purpose Input/Output) headers Pin# Defi nition Defi nition (T-SGPIO-1/T-SGPIO-2) are located the motherboard. These headers Ground Data support serial link interfaces for the Load Ground onboard SATA and SAS connectors.

  • Page 48: Power Smb (I C) Connector

    FAN2 P2-DIMM1B P2-DIMM1A P2-DIMM2B P2-DIMM2A P2-DIMM3B FAN8/ CPU2 Fan P2-DIMM3A SLOT7 PCI-E 2.0 X8 FAN3 X8DT6/E Series Rev. 1.0 SLOT6 PCI-E 2.0 X8 SLOT5 PCI-E 2.0 X8 SLOT4 PCI-E 2.0 X8 LED1 SAS0~3 SLOT3 PCI-E 2.0 X4 SAS4~7 JIBTN1 T-SGPIO1...

  • Page 49: Jumper Settings

    Note: For information on LSI SAS RAID confi guration, please refer to the LSI MegaRAID User's Guide @ http://www.supermicro.com/support/ manuals/. FAN5 P1-DIMM3A JPI2C1 JPW2 JPW1 JPW3 P1-DIMM3B FAN1 FAN6 P1-DIMM2A P1-DIMM2B A. SAS Enable (X8DT6/ P1-DIMM1A FAN7 P1-DIMM1B X8DT6-F CPU2 CPU1 Fan CPU1 FAN2 P2-DIMM1B P2-DIMM1A P2-DIMM2B P2-DIMM2A P2-DIMM3B...

  • Page 50: Cmos Clear

    FAN2 P2-DIMM1B P2-DIMM1A P2-DIMM2B P2-DIMM2A P2-DIMM3B FAN8/ CPU2 Fan P2-DIMM3A SLOT7 PCI-E 2.0 X8 FAN3 X8DT6/E Series Rev. 1.0 SLOT6 PCI-E 2.0 X8 SLOT5 PCI-E 2.0 X8 SLOT4 PCI-E 2.0 X8 LED1 SAS0~3 SLOT3 PCI-E 2.0 X4 SAS4~7 JIBTN1 T-SGPIO1...

  • Page 51: I 2 C Bus To Pci-Exp. Slots

    X8DT6/X8DT6-F/X8DTE/X8DTE-F User's Manual C Bus to PCI-Exp. Slots C to PCI-Exp Jumpers JI C1 and JI C2 allow you to Jumper Settings connect the System Management Bus Jumper Setting Defi nition C) to PCI-Express slots. The default Enabled setting is Open to disable the connec- Disabled (Default) tion.

  • Page 52: Onboard Led Indicators

    In addition to LAN 1/LAN 2, an IPMI Dedi- cated LAN is also located on the IO Back- IPMI LAN Link LED (Left) & Activity LED (Right) plane of the X8DT6-F/X8DTE-F. The amber Color Status Defi nition LED on the right indicates activity, while the...

  • Page 53: Sas Heartbeat Led Indicator

    X8DT6/X8DT6-F/X8DTE/X8DTE-F User's Manual SAS Heartbeat LED Indicator Onboard Heartbeat SAS LED (LED1) Settings An Onboard SAS LED is located on the LED Color Defi nition motherboard. LED1 is SAS Heartbeat LED1 Blinking: SAS: Normal LED. When LED1 is blinking, SAS con- nections function normally.

  • Page 54: Onboard Power Led

    FAN2 P2-DIMM1B P2-DIMM1A P2-DIMM2B P2-DIMM2A P2-DIMM3B FAN8/ CPU2 Fan P2-DIMM3A SLOT7 PCI-E 2.0 X8 FAN3 X8DT6/E Series Rev. 1.0 SLOT6 PCI-E 2.0 X8 SLOT5 PCI-E 2.0 X8 SLOT4 PCI-E 2.0 X8 LED1 SAS0~3 SLOT3 PCI-E 2.0 X4 SAS4~7 JIBTN1 T-SGPIO1...

  • Page 55: Floppy Drive, Serial Ata And Sas Connections

    X8DT6/X8DT6-F/X8DTE/X8DTE-F User's Manual Floppy Drive, Serial ATA and SAS Connections Note the following when connecting the fl oppy and hard disk drive cables: • The fl oppy disk drive cable has seven twisted wires. • A red mark on a wire typically designates the location of pin 1.

  • Page 56: Serial Ata Ports

    See the table on the right for pin RX_N defi nitions. RX_P Ground SAS Ports (X8DT6/X8DT6-F only) SAS Ports 0~3, 4~7, located at JSM1/ JSM2, provide Serial-Attached SCSI connections on the X8DT6/X8DT6-F. See the layout below for SAS port locations.
  • Page 57 X8DT6/X8DT6-F/X8DTE/X8DTE-F User's Manual Notes 2-34...

  • Page 58: Chapter 3 Troubleshooting

    Chapter 3: Troubleshooting Chapter 3 Troubleshooting Troubleshooting Procedures Use the following procedures to troubleshoot your system. If you have followed all of the procedures below and still need assistance, refer to the ‘Technical Support Procedures’ and/or ‘Returning Merchandise for Service’ section(s) in this chapter. Note: Always disconnect the power cord before adding, changing or installing any hardware components.

  • Page 59: No Video

    X8DT6/X8DT6-F/X8DTE/X8DTE-F User's Manual No Video If the power is on but you have no video, remove all the add-on cards and cables. Use the speaker to determine if any beep codes exist. Refer to Appendix A for details on beep codes.

  • Page 60: Technical Support Procedures

    Question: What are the various types of memory that my motherboard can support? Answer: The X8DT6/X8DT6-F/X8DTE/X8DTE-F has 12 240-pin DIMM slots that support up to 96 GB of DDR3 Registered ECC or up to 24 GB of Unbuffered ECC/ Non ECC 1333 MHz/1066 MHz/800 MHz SDRAM modules. It is strongly recom- mended that you do not mix memory modules of different speeds and sizes.

  • Page 61: Returning Merchandise For Service

    X8DT6/X8DT6-F/X8DTE/X8DTE-F User's Manual Question: How do I update my BIOS? Answer: It is recommended that you do not upgrade your BIOS if you are not experiencing any problems with your system. Updated BIOS fi les are located on our web site at http://www.supermicro.com/support/bios/. Please check our BIOS warning message and the information on how to update your BIOS on our web site.

  • Page 62: Chapter 4 Bios

    BIOS Introduction This chapter describes the AMI BIOS Setup Utility for the X8DT6/X8DT6-F/X8DTE/ X8DTE-F. The AMI ROM BIOS is stored in a Flash EEPROM and can be easily updated. This chapter describes the basic navigation of the AMI BIOS Setup Utility setup screens.

  • Page 63: Starting The Setup Utility

    X8DT6/X8DT6-F/X8DTE/X8DTE-F User’s Manual Starting the Setup Utility Normally, the only visible Power-On Self-Test (POST) routine is the memory test. As the memory is being tested, press the <Delete> key to enter the main menu of the AMI BIOS Setup Utility. From the main menu, you can access the other setup screens.
  • Page 64 Chapter 4: AMI BIOS Supermicro X8DT6/X8DTE BIOS Build Version: This item displays the BIOS revision used in your system. BIOS Build Date: This item displays the date when this BIOS was completed. AMI BIOS Core Version: This item displays the revision number of the AMI BIOS Core upon which your BIOS was built.

  • Page 65: Advanced Setup Confi Gurations

    X8DT6/X8DT6-F/X8DTE/X8DTE-F User’s Manual Advanced Setup Confi gurations Use the arrow keys to select Boot Setup and hit <Enter> to access the submenu items: Boot Features Quick Boot If Enabled, this option will skip certain tests during POST to reduce the time needed for system boot.

  • Page 66: Processor And Clock Options

    Chapter 4: AMI BIOS Hit 'Del' Message Display This feature displays "Press DEL to run Setup" during POST. The options are Enabled and Disabled. Interrupt 19 Capture Interrupt 19 is the software interrupt that handles the boot disk function. When this item is set to Enabled, the ROM BIOS of the host adaptors will "capture"...
  • Page 67 X8DT6/X8DT6-F/X8DTE/X8DTE-F User’s Manual C1E Support Select Enabled to enable Enhanced Halt State support. C1E signifi cantly reduces the CPU's power consumption by reducing the CPU's clock cycle and voltage during a "Halt State." The options are Disabled and Enabled. Hardware Prefetcher (Available when supported by the CPU)

  • Page 68: Advanced Chipset Control

    Chapter 4: AMI BIOS Active Processor Cores Set to Enabled to use a processor's Second Core and beyond. (Please refer to Intel's web site for more information.) The options are All, 1 and 2. Intel® Speed_Step™ Technology EIST (Enhanced Intel SpeedStep Technology) allows the system to automatically adjust processor voltage and core frequency in an effort to reduce power consump- tion and heat dissipation.
  • Page 69 X8DT6/X8DT6-F/X8DTE/X8DTE-F User’s Manual CPU Bridge Confi guration QPI (Quick_Path Interface) Links Speed This feature selects QPI's data transfer speed. The options are Slow-mode, and Full Speed. QPI Frequency This selects the desired QPI frequency. The options are Auto, 4.800 GT, 5.866GT, 6.400 GT.
  • Page 70 Chapter 4: AMI BIOS Hysteresis Temperature (Closed Loop Only) Temperature Hysteresis is the temperature lag (in degrees Celsius) after the preset DIMM temperature threshold is reached before Closed Loop Throt- tling begins. The options are Disabled, 1.5 C, 3.0 C, and 6.0 Guardband Temperature (Closed Loop Only) This is the temperature applied to the DIMM temperature threshold.
  • Page 71 X8DT6/X8DT6-F/X8DTE/X8DTE-F User’s Manual Crystal Beach/DCA (Direct Cache Access) This feature works in conjunction with the Intel I/O AT (Acceleration Technology) to accelerate the performance of the TOE device. When this feature set to Enabled, it will enhance overall system performance by providing direct cache access for data transferring.
  • Page 72 Chapter 4: AMI BIOS Hand-Off support. When enabled, the EHCI Interface will be changed from the BIOS- controlled to the OS-controlled. The options are Disabled and Enabled.  IDE/SATA Confi guration When this submenu is selected, the AMI BIOS automatically detects the presence of the IDE devices and displays the following items: SATA#1 Confi...
  • Page 73 X8DT6/X8DT6-F/X8DTE/X8DTE-F User’s Manual Block (Multi-Sector Transfer) Block Mode boosts the IDE drive performance by increasing the amount of data transferred. Only 512 bytes of data can be transferred per interrupt if Block Mode is not used. Block Mode allows transfers of up to 64 KB per interrupt. Select Disabled to allow data to be transferred from and to the device one sector at a time.
  • Page 74 Chapter 4: AMI BIOS Select MWDMA2 to allow the BIOS to use Multi-Word DMA mode 2. It has a data transfer rate of 16.6 MBs. Select UDMA0 to allow the BIOS to use Ultra DMA mode 0. It has a data transfer rate of 16.6 MBs.
  • Page 75 X8DT6/X8DT6-F/X8DTE/X8DTE-F User’s Manual Plug & Play OS Selecting Yes allows the OS to confi gure Plug & Play devices. (This is not required for system boot if your system has an OS that supports Plug & Play.) Select No to allow the AMI BIOS to confi...
  • Page 76 Chapter 4: AMI BIOS Port1 are Disabled, 3F8/IRQ4, 3E8/IRQ4, 2E8/IRQ3. The options for Serial Port2 are Disabled, 2F8/IRQ3, 3E8/IRQ4, and 2E8/IRQ3. Serial Port 2 Mode Use this feature to confi gure Serial Port 2 mode. The options are Normal, IrDA and ASK IR.

  • Page 77: System Health Monitor

    X8DT6/X8DT6-F/X8DTE/X8DTE-F User’s Manual Terminal Type This feature allows the user to select the target terminal type for Console Redi- rection. The options are ANSI, VT100, and VT-UTF8. VT-UTF8 Combo Key Support A terminal keyboard defi nition that provides a way to send commands from a remote console.
  • Page 78 Chapter 4: AMI BIOS CPU Temperature/System Temperature This feature displays current temperature readings for the CPU and the System. The following items will be displayed for your reference only: CPU Temperature The CPU thermal technology that reports absolute temperatures (Celsius/Fahr- enheit) has been upgraded to a more advanced feature by Intel in its newer processors.
  • Page 79 X8DT6/X8DT6-F/X8DTE/X8DTE-F User’s Manual 2. The information provided above is for your reference only. For more information on thermal management, please refer to Intel’s Web site at www.Intel.com. System Temperature: The system temperature will be displayed (in degrees in Celsius and Fahrenheit) as it is detected by the BIOS.

  • Page 80: View Bmc System Event Log

    Chapter 4: AMI BIOS Headless Mode When this feature is enabled, the system will function without a keyboard, monitor or mouse attached The options are Enabled and Disabled. High Performance Event Timer Select Enabled to activate the High Performance Event Timer (HPET) that produces periodic interrupts at a much higher frequency than a Real-time Clock (RTC) does in synchronizing multimedia streams, providing smooth playback and reducing the de- pendency on other timestamp calculation devices, such as an x86 RDTSC Instruc-...
  • Page 81 X8DT6/X8DT6-F/X8DTE/X8DTE-F User’s Manual • Event Sensor Type • Event Sensor Number, • Event Dir Type • Event Data. Clear BMC System Event Log Select OK and press the <Enter> key to clear the BMC system log. Select Cancel to keep the BMC System log. The options are OK and Cancel.
  • Page 82 Chapter 4: AMI BIOS administrator). Only clients with an IP Address within the pre-determined range of addresses will be allowed access to the network. A static IP Address that is assigned to a device is retained until it is manually re-assigned a different address, or re-confi...

  • Page 83: Security Settings

    X8DT6/X8DT6-F/X8DTE/X8DTE-F User’s Manual  Gateway Address Confi guration This option allows to user to enter the gateway address for this machine. This should be in decimal and in dotted quad form (i.e., 192.168.10.253). The value of each three-digit number separated by dots should not exceed 255.
  • Page 84 Chapter 4: AMI BIOS Supervisor Password This item indicates if a Supervisor password has been entered for the system. "Not Installed" means a Supervisor password has not been used. User Password This item indicates if a user password has been entered for the system. "Not In- stalled"...

  • Page 85: Boot Confi Guration

    X8DT6/X8DT6-F/X8DTE/X8DTE-F User’s Manual Password Check This item allows you to check a password after it has been entered. The options are Setup and Always. Boot Sector Virus Protection When Enabled, the AMI BIOS displays a warning when any program (or virus) is- sues a Disk Format command or attempts to write to the boot sector of the hard disk drive.

  • Page 86: Removable Drives

    Chapter 4: AMI BIOS Removable Drives This feature allows the user to specify the boot sequence from available Removable Drives. The settings are 1st boot device, 2nd boot device, and Disabled. • 1st Drive - 1st Floppy Drive • 2nd Drive - [USB: XXXXXXXXX] CD/DVD Drives This feature allows the user to specify the boot sequence from available CD/DVD Drives (i.e., 1st Drive, 2nd Drive, etc).

  • Page 87: Exit Options

    X8DT6/X8DT6-F/X8DTE/X8DTE-F User’s Manual Exit Options Select the Exit tab from the AMI BIOS Setup Utility screen to enter the Exit BIOS Setup screen. Save Changes and Exit After you have completed system confi guration changes, select this option and press <Enter> to reboot the compute so that the new system confi guration settings can take effect.

  • Page 88: Bios Recovery

    Chapter 4: AMI BIOS BIOS Recovery Warning! Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update.

  • Page 89: Boot Sector Recovery From An Ide Cd-Rom

    X8DT6/X8DT6-F/X8DTE/X8DTE-F User’s Manual 4.7.2 Boot Sector Recovery from an IDE CD-ROM This process is almost identical to the process of Boot Sector Recovery from a USB device, except that the BIOS image fi le is loaded from a CD-ROM. Use a CD-R or CD-RW drive to burn a CD with the BIOS image fi...
  • Page 90 Chapter 4: AMI BIOS 4. Power on your system and click the <Connect> button in the Hyper Terminal. The terminal screen will display the following messages. Press <SpaceBar> to update BIOS. Confirm update BIOS? (y/n) y Begin remote BIOS flash? (y/n) y Starting remote flash.
  • Page 91 X8DT6/X8DT6-F/X8DTE/X8DTE-F User’s Manual Once the ROM fi le extraction is completed, the message: "New BIOS re- ceived OK" will display. 8. Once remote BIOS fl ash is completed, the system will reboot. Note: AMIBIOS Serial Flash will work with any terminal communications program that supports VT-100 and XModem protocols, including protocols designed for GNU/LINUX &...

  • Page 92: Appendix A Bios Error Beep Codes

    Appendix A: BIOS POST Error Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process.
  • Page 93 X8DT6/X8DT6-F/X8DTE/X8DTE-F User's Manual Notes...

  • Page 94: Appendix B Installing The Windows Os

    Appendix B: Installing the Windows OS Appendix B Installing the Windows OS After all hardware components have been installed, you must fi rst confi gure Intel South Bridge RAID Settings before you install the Windows OS and other software drivers. To confi gure RAID settings, please refer to RAID Confi guration User Guides posted on our web site at www.supermicro.com/support/manuals.

  • Page 95: Installing The Windows Os For A Non-Raid System

    X8DT6/X8DT6-F/X8DTE/X8DTE-F User's Manual B-2 Installing the Windows OS for a Non-RAID System Insert Microsoft's Windows OS Setup CD in the CD Driver, and the system will start booting up from CD. Continue with the OS installation. The Windows OS Setup screen will display.

  • Page 96: Appendix C Software Installation Instructions

    Appendix C: Software Installation Instructions Appendix C Software Installation Instructions C-1 Installing Software Programs After you've installed the Windows Operating System, a screen as shown below will appear. You are ready to install software programs and drivers that have not yet been installed.

  • Page 97: C-2 Confi Guring Supero Doctor Iii

    The Supero Doctor III program is a Web-base management tool that supports remote management capability. It includes Remote and Local Management tools. The local management is called the SD III Client. The Supero Doctor III program included on the CDROM that came with your motherboard allows you to monitor the environment and operations of your system.
  • Page 98 Appendix C: Software Installation Instructions Supero Doctor III Interface Display Screen-II (Remote Control) Note: SD III Software Revision 1.0 can be downloaded from our Web site at: ftp://ftp.supermicro.com/utility/Supero_Doctor_III/. You can also download SDIII User's Guide at: http://www.supermicro.com/PRODUCT/ Manuals/SDIII/UserGuide.pdf. For Linux, we will still recommend that you...
  • Page 99 X8DT6/X8DT6-F/X8DTE/X8DTE-F User's Manual Notes...
  • Page 100 (Disclaimer Continued) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to perform be reasonably expected to result in signifi cant injury or loss of life or catastrophic property damage.
