- Page 1 INSTALLATION MANUAL CTARM-2SV Residential Digital Agile Modulator With S-Video Inputs...
-
Page 2: Product Description
TV channel for each video device, combines the new channels with cable or broadcast TV channels, and routes the output to all TVs in home via existing cable outlets. The CTARM-2SV features S-Video input to allow for a better quality video input from the audio video source. - Page 3 INSTALLATION AND OPERATION 1. UNPACKING and HANDLING Each unit is shipped with all equipment assembled, and factory tested. Ensure that all accessories are removed from the container before discarding packing material 2. MECHANICAL INSPECTION Inspect the front and rear of the equipment for shipping damage. Make sure the equipment is clean, and no connectors are broken, damaged, or loose.
- Page 4 Connect an RCA cable from the audio source to the red/white RCA Input jacks on the CTARM-2SV. Use red and white jacks for dual input, or either one for single input. c. If you want to combine your signal with an Off-Air or CATV signal, connect the coaxial cable from the Off-Air antenna or CATV to the Antenna Input.
