Summary of Contents for Morgana DocuMaster Automatic SquareBack
- Page 1 Square Back System DOCUMENT SQUARE BACK BOOKLET OPERATING SYSTEM OPERATORS MANUAL Morgana Systems Limited United Kingdom Telephone: ( 01908 ) 608888 Facsimile: ( 01908 ) 692399 Website: www.morgana.co.uk November 2005 ISSUE 1 70-072...
-
Page 2: Table Of Contents
CONTENTS Introduction ......4 Installation Safety Information Getting Help About your Automatic Square Back System 5 How the Square Back System Works Adjustments and Settings Stacker... - Page 3 Square Back System CONVENTIONS The following conventions are used in this manual: Warning Warning messages alert you to a specific procedure or practice which, if not followed correctly, could cause serious personal injury. Caution Caution messages alert you to a specific procedure or practice which, if not followed correctly, could result in damage to equipment.
-
Page 4: Introduction
Your SBS should be located on a level floor. If your SBS is used online with other equipment, installation requires specialist knowledge and should therefore only be Carried out by a Morgana approved engineer. Caution This machine must only be plugged into an electrical supply line of the correct voltage and with a proven earth. -
Page 5: About Your Automatic Square Back System
Square Back System 2 About your Automatic Square Back System HOW THE The booklet is transported, spine first, into the SBS. The SQUARE BACK SYSTEM SquareBack spine is formed and the booklet is then WORKS delivered to the stacker on the top of the SBS. Outfeed SquareBack Booklets Stacker Support... - Page 6 Operating Mode Selection (see Fig 3.) Single Pass : The SBS will process the booklet a single time. This is the default setting, and is suitable for the vast majority of booklets. Double Pass : The SBS will process the booklet twice. This can be useful for thick, inflexible covers which are more resistant to re-forming.
-
Page 7: Stacker
Square Back System STACKER Booklets are stacked, spine uppermost, in the stacker. The stacker support automatically recedes to accommo- date the increasing stack. When the stacker is full, a sensor will automatically stop the SBS and the green Error/Reset light illuminates. Unload the booklets, slide the stacker support back up towards the outfeed and then restart the connected equipment. -
Page 8: Using Your Automatic Square Back System
3 Using your Automatic Square Back System ONLINE OPERATION The SBS can be used online to a variety of bookletmaking machines. It will automatically start and stop as required, controlled by the connected equipment. 1. First select the required Operating Mode and Book Thickness Adjustment (see Chapter 2, ’About your Automatic Square Back System’). -
Page 9: Hand Feeding
Square Back System 4. Adjust the operating speed of the connected equip- ment to approximately 1,000 booklets per hour. (Note: some connected equipment will automatically adjust to an appropriate speed for the SBS.) 5. Gradually increase the speed to about 1,400 book- lets per hour (single pass mode). -
Page 10: Error Conditions
4 Error Conditions BOOKLET JAMMED If a booklet jams in the SBS for any reason, switch the INSIDE SBS SBS off at the mains input and then switch it back on again. The machine will reset and the booklet should be ejected onto the stacker. -
Page 11: Small Booklets Do Not Stack Well
Caution If the booklet cannot be removed because it is jammed in the clamp mechanism, do not attempt to force the mechanism open. Contact your Morgana service Department. • Close the SBS lid by lifting it slightly, push the sup- port strut and then lower the lid. -
Page 12: Unevenly Formed Spine
230V machines: 730-016 Fuse, 1.25" (32mm) 5.0A HRC-Quick Acting F 115V machines: 730-020 Fuse, 1.25” (32mm) 10.0A HRC (Quick Acting, F) SEEKING If you require assistance with your SBS, please contact ASSISTANCE your local Morgana Service Department. Page 12 SQUARE BACK... -
Page 13: Maintenance
Square Back System 5 Maintenance SERVICE INTERVAL It is recommended that your SBS is serviced by an approved Morgana engineer at six to twelve month inter- vals (depending on usage). Please contact Morgana for further details. OPERATOR As with all machinery, your SBS will benefit from regular MAINTENANCE cleaning to prevent build up of dust and general dirt. - Page 14 Caution Do not attempt to use a cloth to clean the carriage roller. This may leave loose fibres or debris inside the machine. Page 14 SQUARE BACK...
-
Page 15: Specifications
Square Back System 6 Specifications This product is intended for the re-forming of booklet Intended Use spines, to flatten the booklet and give a square appear- ance to the spine, within the specifications below. up to 1400 per hour single pass Production from 80 x 120mm to 250 x 350mm Booklet Size... - Page 16 interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Page 16 SQUARE BACK...
-
Page 17: Declaration Of Conformity
Manufacturer's Address: Snowdon Drive Winterhill, Milton Keynes, Bucks. Mk6 1AP United Kingdom Declares that the product Morgana Square Back System Product Name: WA/ASM/0010 onwards Product Number: Conforms to the following Product Specifica- tions: 73/23/EEC & 98/37/EC Council Directive 'on the approx- Safety: imation of laws of Member States relating to machinery'. -
Page 18: Index
INDEX about your automatic Square Back System 5 lid 11 adjustments 5 book thickness 5 mains input 5 operating mode 6 mains on/off 5 assistance 12 maintenance 13 maintenance, operator 13 book thickness 5 book thickness adjustment 5 on/off switch 5 booklet control springs 12 online operation 8 booklet jam 10... - Page 19 Square Back System INDEX using your automatic Square Back System 8 wet ink 9 SYSTEM Page 19...
