Installation and Operation Manual
ATEM Production Switchers
Mac OS X
™
Windows
™
September 2011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ATEM Television Studio and is the answer not in the manual?

Questions and answers

Related Manuals for Blackmagicdesign ATEM Television Studio

Summary of Contents for Blackmagicdesign ATEM Television Studio

  • Page 1 Installation and Operation Manual ATEM Production Switchers Mac OS X ™ Windows ™ September 2011...
  • Page 2 This instruction manual should contain all the information you’ll need for installing your ATEM Production Switcher. The ATEM switcher includes a software control panel which you can run on your computer or you can purchase a hardware based broadcast control panel separately. The computer and control panels...

  • Page 3: Table Of Contents

    Plugging in Multi View Monitoring Media Manager Plugging in a Control Panel Switcher Settings Installing Blackmagic ATEM Software on Mac OS X Installing Blackmagic ATEM Software on Windows 7 Using the Software Control Panel Plugging in your Computer Mix Effects...

  • Page 4: Atem Production Switchers

    Contents ATEM Production Switchers Using the ATEM 1 M/E Broadcast Panel Manual Transitions Preview Transition Control Panel Overview Keying on ATEM Switchers Using the Control Panel Understanding Keying Mix Effects Using Adobe Photoshop with ATEM Source Names Display Setting up Plug-in Switcher Location...

  • Page 5: Getting Started

    ATEM switcher! When you’re starting out with a switcher for the first time, the ATEM can look a little intimidating with all its buttons and knobs, however it's all very logically laid out so it's very simple to use! ATEM is a true high-end broadcast switcher that operates using the M/E workflow standards used in the broadcast industry.
  • Page 6 There are multiple types of transitions available, and they can be selected in the transition control. On the ATEM 1 M/E Broadcast Panel there are two transition type buttons. One is labeled dip/mix and the other is labeled DVE/wipe. Hitting these buttons selects mix and wipe transitions, however pressing shift and then selecting mix or wipe allows more types of transitions, dip and DVE.
  • Page 7 Getting Started Another great advantage of the ATEM M/E style of operation is you can tie keyers to the transition. This means when you do a mix transition, you can also fade on or off keyers at the same time. This allows you to build up a composition, and then bring the whole lot on air at the same time.

  • Page 8: Understanding The Atem Processor Chassis

    The ATEM chassis mounts in a standard 19" rack. The Television Studio is only 1 rack unit high while the 1 M/E is only 2 rack units and the 2 M/E is only 3 rack units high. The ATEM chassis is very thin and so is ideal for either fixed installation or portable use.

  • Page 9: Plugging In Multi View Monitoring

    A fantastic way to check that your ATEM is powered on and working correctly is to plug in a HDMI television into the Multi View output on the right side of the heat sink on the ATEM rear panel. You should see 8 video boxes at the bottom, and two larger boxes at the top, all bound by white borders.

  • Page 10: Plugging In A Control Panel

    Getting Started Plugging in a Control Panel If you have purchased an ATEM Broadcast Panel, then you won't want to wait to plug in your computer, as it's much more fun to plug in the hardware panel first! Plugging in the ATEM Broadcast Panel is simple, because it's already set to the correct network settings to plug into your ATEM processor chassis without any changes required.

  • Page 11: Installing Blackmagic Atem Software On Mac Os X

    Blackmagic Design capture products when installed on the same computer: On Mac OS X, all the files needed to run your ATEM switcher will be installed into a folder called Blackmagic ATEM Switchers in the Applications folder.

  • Page 12: Installing Blackmagic Atem Software On Windows 7

    Start > Programs > Blackmagic Design. In the ATEM Switchers folder, you will see the ATEM Software Control, which is the software control panel for your switcher, which also allows loading graphics into the switcher media pool and changing settings. The ATEM Setup Utility allows you to change the switcher IP address, or update the switcher and panel software via USB.

  • Page 13: Plugging In Your Computer

    Step 3. In the network settings on your computer, enable ethernet, and set the IP address setting to manual. Then enter the IP address 192. 168.10.1. Now when you run your ATEM Software Control you should see the buttons on the control tab light up and show the switcher state after a slight pause.

  • Page 14: Settings You Need To Check

    Settings You Need To Check! Now you have the software control working, you need to change some settings to use your ATEM switcher. The changes are made in the settings tab of the ATEM Software Control and the most critical settings are listed below: Check 1.

  • Page 15: Plugging In Cameras

    You don't need to worry about genlock for cameras, because each input of your ATEM switcher has a full frame re synchronizer. If the ATEM switcher detects at any time that a video source is out of sync, it will automatically enable the frame sync so the input is clean for use. The frame sync function also allows...

  • Page 16: Connecting To A Network

    IP address of the ATEM Production Switcher via USB using the ATEM Setup Utility. You will need to set the DHCP or fixed IP mode on the ATEM Broadcast Panel and if using a fixed IP address on the panel, set the IP address on the panel.

  • Page 17: Changing The Switcher Network Settings

    Step 4. To change the IP address or any other settings, simply edit the numbers and then select apply. Step 5. A dialog box will prompt you to please power cycle your ATEM switcher. Turn off and on the ATEM Setup Utility Connects via USB power on the switcher and then press OK.

  • Page 18: Setting The Broadcast Panel To Find The Switcher Ip Location

    Control Panel Not Connected processor to see if it's been set correctly. To change the IP address of the switcher, connect the switcher via USB to a computer and run the ATEM Setup Utility software as described previously in this manual.

  • Page 19: Changing The Broadcast Panel Network Settings

    If you’re connecting direct to a switcher without a network, then you won't have a DHCP server to assign an IP address automatically, so you will want to select fixed. ATEM Broadcast Panels are delivered with a fixed IP address set to 192.168.10.10, for a direct connection.

  • Page 20: Updating The Software

    To update your ATEM switcher with new software, you need to use the ATEM Setup Utility to connect to the ATEM processor chassis and panels via USB. This utility always checks the switcher software and lets you know if there is new software.

  • Page 21: Updating The Broadcast Control Panel Software

    USB cable. When upgrading software, make sure the broadcast panel is the only ATEM device connected via USB to the computer running the setup utility software. If more than one ATEM device is connected, the panel may not be recognized.

  • Page 22: Connecting Video Outputs

    Connecting Video Outputs There are multiple video outputs on your ATEM switcher, and they can be used to connect to a wide range of video equipment, in all kinds of locations. ATEM includes SDI, HDMI and analog component, plus SD SDI and composite video outputs, so you should be able to connect to equipment at any location.
  • Page 23 USB 3.0 Output The USB 3.0 output, available in the ATEM 1 M/E and ATEM 2 M/E Production Switcher can be used to capture video direct to a Windows PC for real time mastering to file or for waveform monitoring. When encoding software is used, you can also stream over the internet.

  • Page 24: Using Atem Software Control

    You can also use the ATEM Software Control to configure your switcher settings as well as upload graphics and manage the media pool.

  • Page 25: Media Manager

    ATEM models, and holds images with alpha channel that can be assigned to a media player for use in the production. The ATEM Television Studio holds 2 still graphics with alpha and the ATEM 1 M/E and 2 M/E hold 32 still graphics and 2 clips.

  • Page 26: Switcher Settings

    The switcher settings also let you customize your multi view. The multi view can change its orientation and, on the ATEM 1 M/E and 2 M/E production switchers, any of the 8 video views can be changed allowing you to view any source in the switcher. This lets you monitor cameras, internal sources, media players and even aux.

  • Page 27: Program Bus Source Select Buttons

    The AUTO button illuminates red for the duration of the transition and the RATE display updates to indicate the number of frames remaining as the transition progresses. If an ATEM broadcast panel is connected, the fader bar indicator on the panel updates to provide visual feedback on the progress of the transition.
  • Page 28 The AUTO button illuminates red for the duration of the transition and the RATE display updates to indicate the number of frames remaining as the transition progresses. If an ATEM broadcast panel is connected, the fader bar Indicator on the panel updates to provide visual feedback on the progress of the transition.

  • Page 29: Downstream Keyers

    It ensures all layers in the switcher are faded down together. A fade to black cannot be previewed. Processing Palettes The following processing palettes are available in the software control panel for the ATEM 1 M/E Production Switcher model. These change based on the model you’re connected to, and are an easy way to see what processing is available in the switcher.
  • Page 30 Because the ATEM 1 M/E Production Switcher and Television Studio models have only 1 M/E, these keyers are all labeled as being for M/E 1. On the ATEM 2 M/E Production Switcher model, the labels will show which M/E these keys are connected to.

  • Page 31: Using The Media Manager And Media Pool

    Browse Window have a location for audio. On the ATEM Television Studio only the first two still image windows in the media pool are active. On the 1 M/E and 2 M/E Production Switcher all of the windows in the media pool are active.
  • Page 32 2. On the ATEM 1 M/E and 2 M/E Production Switchers you can change the media player assignment from the media tab by using the copy to media buttons. First select the clip or still you want to copy to one of the ATEM Media Pool media players.

  • Page 33: Changing Switcher Settings

    Setting Video Inputs The video input settings are used to select the inputs and change labels. On some models of ATEM switcher, the video inputs can select between different video sources, such as HDMI or SDI, or HDMI and component video connections.
  • Page 34 The video setting is used to select the operating video standard of the ATEM switcher, and this must be set to the same video standard as the video sources you are plugging into the ATEM switcher. If they don't match, the inputs won't appear correctly, and will most likely remain black. A good way to work out the video standard you should use is to check your cameras, and then set the switcher video standard to the same format.
  • Page 35 Adjusting the Media Pool Clip Length On the ATEM 1 M/E and 2 M/E production switchers, the ATEM media pool has two clips that share the same pool of memory. The maximum capacity for the number of frames for both clips is set by the amount of physical memory in the switcher itself.

  • Page 36: Controlling Auxiliary Outputs

    Customizing the Multi View The multi view settings allow you to set the multi view orientation. On the ATEM 1 M/E and 2 M/E Production Switchers the larger program and preview windows have fixed routing, while the 8 smaller windows are fully routable so you can monitor any switcher source.

  • Page 37: Using The Atem 1 M/E Broadcast Panel

    If fast and critical live switching is being done, then the ATEM Broadcast Panel is an incredibly fast and robust control solution. There's nothing like pushing high quality buttons on a panel to ensure fast and...

  • Page 38: Preview Bus

    MASK MENU HOME Using the ATEM 1 M/E Broadcast Panel Preview Bus The preview bus is used to select a source on the preview output. This source is sent to program when the next transition occurs. The selected source is indicated by a button that is illuminated green. A blinking...
  • Page 39 Using the ATEM 1 M/E Broadcast Panel AUTO and Transition Rate The AUTO button will perform the selected transition at the rate specified in the transition rate window. The transition rate for each transition type is set in the system control, and is displayed in the transition rate window of the transition control block when the corresponding transition style button is selected.

  • Page 40: Downstream Keyers

    Using the ATEM 1 M/E Broadcast Panel Next Transition The BKGD, KEY 1, KEY 2, KEY 3, KEY 4 buttons are used to select the elements which will transition on air or off air with the next transition. Any combination of background and keys can be selected by pressing multiple buttons simultaneously.

  • Page 41: System Status

    The status lights provide feedback on the power supplies connected to the broadcast panel and the switcher. Not all ATEM switcher models have redundant power supplies so sometimes you will only see a single light illuminated for the power status of the switcher.

  • Page 42: Operating Your Atem Switcher

    Color Generators ATEM has two color sources that can be customized to generate any color matt for use in the production. Color sources can be used to add color borders for wipe transitions or as dip through colors for a dip transition such as dip through white.

  • Page 43: Media Players

    Operating Your ATEM Switcher Controlling media players on the software control panel Step 1. From the switcher tab, select the media player palette. Step 2. Use the select media drop down list to select a clip or still from the media pool. Clip and still locations which have media loaded will display a filename in the drop down list.

  • Page 44: Cut Transitions

    Operating Your ATEM Switcher Cut Transitions The cut is the most basic transition that can be performed on the switcher. In a cut transition the program output is immediately changed from one source to another. Program output for a cut transition.
  • Page 45 Operating Your ATEM Switcher CUT Button When a cut transition is performed using the CUT button, any upstream keys that were selected in the next transition and any downstream keys that were tied to the transition control will also change state. They will be cut on if they were off and cut off if they were on.

  • Page 46: Auto Transitions

    Operating Your ATEM Switcher Auto Transitions An auto transition allows you to automatically transition between program and preview sources at a predetermined rate. Any upstream keys that were selected in the next transition and any downstream keys that were tied to the transition control will also change state. Auto transitions are performed using the auto button in the transition control block.
  • Page 47 Operating Your ATEM Switcher To perform an auto transition on the software control panel using a keyboard Step 1. Ensure that <caps lock> is off. Step 2. Press the number key on the keyboard corresponding to the video source that you want on the program output.
  • Page 48 Operating Your ATEM Switcher To perform an auto transition on the broadcast panel Step 1. On the preview bus, select the video source that you want on the program output. Step 2. Select the transition type using the transition type buttons in the transition control block.
  • Page 49 Operating Your ATEM Switcher A production switcher provides multiple methods of transitioning from one shot to another. Generally, you use a simple cut transition to move from one background source to another. Mix, dip, wipe and DVE transitions allow you to transition between two background sources by gradually phasing out one and phasing in another.
  • Page 50 Operating Your ATEM Switcher To perform a mix transition on the broadcast panel Transition Step 1. On the preview bus, select the video source that you want on the program output. 1:00 1:00 1:00 Step 2. Press the MIX/DIP button to select the mix transition type. The system control automatically...
  • Page 51 Operating Your ATEM Switcher To perform a dip transition on the software control panel Step 1. On the preview bus, select the video source that you want on the program output. Step 2. Select the DIP transition style in the transition control block.

  • Page 52: Wipe Transitions

    Operating Your ATEM Switcher Wipe Transitions A wipe is a transition from one source to another and is achieved by replacing the current source by another source with a pattern that forms a shape. For example an expanding circle or diamond.

  • Page 53: Dve Transitions

    DVE Transitions The ATEM 1 M/E and 2 M/E Production Switchers include a powerful digital video effects processor for DVE transitions. A DVE transition displaces the image in various ways to transition from one picture to another.
  • Page 54 Operating Your ATEM Switcher To perform a DVE transition on the software control panel Step 1. On the preview bus, select the video source that you want on the program output. Step 2. Select the DVE transition style in the transition control block.
  • Page 55 Sharing DVE resources There is one DVE channel in the ATEM 1 M/E and 2 M/E Production Switchers which can be used to perform DVE transitions or it can be used in an upstream keyer. The ATEM Television Studio does not have any DVE channels available.
  • Page 56 Operating Your ATEM Switcher The graphic transition is a popular transition that uses the DVE and moves a graphic across the screen over a background transition. For example, the graphic wipe moves a graphic over a horizontal wipe, essentially replacing the wipe border. A graphic mix, spins the graphic across the screen over a mix transition. Graphic transitions are perfect for wiping the station logo or spinning a football across the screen revealing a new background.
  • Page 57 Operating Your ATEM Switcher To perform a graphic transition on the broadcast panel Step 1. Select DVE as the transition type by pressing the SHIFT and DVE/WIPE buttons simultaneously. The DVE is illuminated green indicating that the DVE transition type is selected.
  • Page 58 Operating Your ATEM Switcher Sharing DVE resources The one DVE channel available in the switcher can be used to perform DVE transitions or it can be used in an upstream keyer. When you select a DVE transition, if the DVE is used elsewhere in the system, the DVE transition type will not be available and, on the broadcast panel, a DVE unavailable message will be displayed.
  • Page 59 Operating Your ATEM Switcher On the ATEM 1 M/E and 2 M/E production switchers, the stinger transition uses a clip from the media player to perform a transition. The clip is normally a graphic animation that is keyed over the background. As the animation plays, when it is full screen, a cut or mix of the background is performed under the animation.
  • Page 60 Operating Your ATEM Switcher Software control panel stinger parameters Source The media player which will be used to play the clip for the animated transition. Pre Multiplied Key Identifies the key signal of the media player clip as a pre-multiplied key.
  • Page 61 Operating Your ATEM Switcher To perform a stinger transition on the broadcast panel Step 1. From the system control menu buttons, navigate to the media player menu by selecting MEDIA PLAYER from the home menu and select the media player you plan to use for the transition.

  • Page 62: Manual Transitions

    Operating Your ATEM Switcher Manual Transitions Manual transitions allow you to manually transition between program and preview sources using the fader bar in the transition control block. Mix, dip, wipe and DVE transitions can all be performed as a manual transition.

  • Page 63: Preview Transition

    Operating Your ATEM Switcher Preview Transition ATEM switchers have a powerful feature which allows you to review and adjust a transition on the preview output. The preview transition mode lets you verify a transition before actually performing it on air.

  • Page 64: Keying On Atem Switchers

    Operating Your ATEM Switcher Keying on ATEM Switchers Keyers are a powerful production tool allowing multiple layers of video and graphics to be stacked on top of the background. When a new layer of video is stacked on the background, the video or graphic needs to be cut out so that the background video can be seen.

  • Page 65: Linear Key

    Operating Your ATEM Switcher Luma Key A luma key or self key consists of one video source containing the video image that will be stacked on top of the background. All of the black areas defined by the luminance in the video signal will be removed or cut out so that the background can be revealed underneath.
  • Page 66 You also need to make sure you have created an alpha channel in your Photoshop document that the ATEM can use for blending the graphic over the live video. Then when saved as a Targa image file, or downloaded direct to the media pool, you can select pre-multiplied in the keyer to get a good key.
  • Page 67 Operating Your ATEM Switcher Performing an Upstream Luma/Linear Key Since luma and linear keys use the same parameters, they are set up on the software control panel and broadcast panel using a common menu, called the luma key menu. What defines the key as being either luma or linear is in the selection of fill and key sources.
  • Page 68 Operating Your ATEM Switcher Upstream key luma/linear key parameters: Mask Enables a rectangular mask that can then be adjusted using the top, bottom, left and right parameters. Pre-Mult Identifies the key signal as a pre-multiplied key. The clip level adjusts the threshold at which the key cuts its hole. Decreasing the Clip clip level reveals more of the background.
  • Page 69 Operating Your ATEM Switcher Performing a Downstream Luma/Linear Key To set up a luma/linear key on downstream keyer 1 on the software control panel: Step 1. Select the downstream key 1 palette. Step 2. Use the drop down controls labeled fill source and key source to specify the fill and key sources.

  • Page 70: Chroma Key

    A very common use for chroma keys for backgrounds is computer generated graphics. It’s simple to connect an external computer to your ATEM switcher using the HDMI output of the computer or a video card such as the Blackmagic Design DeckLink or Intensity range and then playback video clips to your ATEM switcher.
  • Page 71 Operating Your ATEM Switcher Step 1. To set up a chroma key on upstream keyer 1 on the broadcast panel: Step 2. Press the KEY 1 button to enable the keyer on the preview output. The system control will dynamically navigate to the KEY 1 menu. You can manually navigate to the KEY 1 menu by pressing HOME >...
  • Page 72 Operating Your ATEM Switcher Adjusting parameters with a vectorscope You may wish to set up a chroma key using color bars as the background source, and watching the result on a vector scope as you perform the following procedure. Step 1. Turn narrow off.
  • Page 73 Operating Your ATEM Switcher Performing an Upstream Pattern Key To set up a pattern key on upstream keyer 1 on the software control panel: Step 1. Expand the upstream key 1 M/E 1 palette and select pattern from the key types bar.
  • Page 74 DVE Key DVEs (digital video effects) are used to create picture-in-picture boxes with borders. The ATEM 1 M/E and 2 M/E Production Switchers have 1 channel of 2D DVE that allows scaling, rotation, 3D borders and offers a drop shadow.
  • Page 75 Operating Your ATEM Switcher To set up a DVE key on upstream keyer 1 on the broadcast panel: Step 1. Press the KEY 1 next transition button to enable the keyer on the preview output. The system control will dynamically navigate to the KEY 1 menu. You can manually navigate to the KEY 1 menu by pressing HOME >...
  • Page 76 Operating Your ATEM Switcher Adding DVE Borders DVE border styles The 3D borders used in the upstream keyers have four different style settings. The style settings adjust the overall look of the border. No bevel - 2d border where the border width, softness and color adjustments are Style 1 applicable.
  • Page 77 Operating Your ATEM Switcher Border menu parameters (hold shift button) In Width Adjusts the inside width of the border. In Soft Adjusts inside softness. This softness parameter adjusts the inside edge of the border, the edge that touches the video.
  • Page 78 Operating Your ATEM Switcher Key Masking Both upstream and downstream keyers have an adjustable rectangular mask that can be used to crop out harsh edges and other artifacts in the video signal. The mask consists of left, right, top and bottom crop controls.
  • Page 79 Operating Your ATEM Switcher Using Upstream Keyer Transitions In order to help you understand the various ways in which multiple keys can be taken on and off the program output, we have provided a few examples. In the examples below KEY 1 contains a live bug on the top left of the screen while KEY 2 contains a bug at the bottom right hand side of the screen.
  • Page 80 Operating Your ATEM Switcher Using Upstream Keyer Transitions Example 3: In this example, key 1 and key 2 are on-air, indicated by the illuminated ON buttons. The next transition has the background selected, indicated by the illuminated BKGD button, therefore the next transition will only transition the background leaving both key 1 and key 2 on-air.
  • Page 81 Operating Your ATEM Switcher There are multiple ways to transition a key to the program output. The key can be cut on or off, it can be mixed on or off, or it can be mixed along with a background transition. Upstream keys are transitioned to the program output using the next transition block.

  • Page 82: Using Adobe Photoshop With Atem

    For best results, you will want to use a Photoshop document resolution that matches the video standard you’re using with your ATEM switcher. For 1080i HD you should use documents that are 1920 x 1080 pixels in resolution. For 720p HD formats you should use 1280 x 720 pixels resolution. For PAL standard definition you should use 720 x 576 and for NTSC you should use 720 x 486 pixels resolution documents.

  • Page 83: Using Auxiliary Outputs

    Routing Auxiliary Outputs On the ATEM software control each aux. output has a menu for selecting the source to output on the aux. video output. Simply select the menu, and then scroll the list for the source you want to output. When selected, the output on the selected aux.
  • Page 84 Operating Your ATEM Switcher Media Player 1 Key This is the key output from media player 1, and is derived from the still or clips alpha content. After selecting the aux. you want to route to, simply hold shift and make the selection on the select bus.

  • Page 85: Using Usb 3.0 Connection

    Media Express lets you capture from the ATEM switcher using a compatible Windows PC with USB 3.0. In the current version of ATEM software USB 3.0 capture is not supported, however will be added in a free software update coming soon.

  • Page 86: Blackmagic Media Express

    Media Express, you'll notice the log and capture, playback and edit to tape views are color-coded so you will know at a glance which mode is being used. The edit to tape view is not used by ATEM Television Studio but may be used with other Blackmagic Design capture and playback products.

  • Page 87: Capturing Video And Audio Files

    "Continue playback when in the background". The final options are not used by ATEM Television Studio as they relate to tape decks with RS-422 deck control.
  • Page 88 Blackmagic Media Express Media List Timecode List, Thumbnail and Favorites view Search Field VTR / deck timecode Video Preview Project name, video format Clip Bins Mark In / Grab Still Logging Capture Transport Audio channel Audio Meters Remote and frame rate Mark Out Frame Information...
  • Page 89 Set whether audio channels 1 and 2 audio channels are to be captured and then click the “Capture” button to start recording. The Clip, Batch and Log buttons are not used to capture from ATEM Television Studio. They relate to capturing from tape decks with RS-422 deck control.
  • Page 90 Blackmagic Media Express Media List Timecode List, Thumbnail and Favorites view Search Field VTR / deck timecode Video Preview Project name, video format Clip Bins Mark In / Clip Grab Still Favorites Transport Audio channel Audio Meters Remote and frame rate Mark Out Information Frame...

  • Page 91: Playing Back Video And Audio Files

    If the files being imported do not match the frame rate and size of existing clips in the Media List, you will be prompted to create a new project and to save the current project. The Final Cut Pro XML import option is not used by ATEM Television Studio. This option relates to capturing from tape decks with RS-422 deck control.

  • Page 92: Browsing Media

    Blackmagic Media Express Browsing Media In the Media List, you can view your clips in Thumbnail view or Timecode List view by clicking on the desired view button at the top-right of the Media List. In the Media List, choose to view your clips in Timecode List view Thumbnail View or Thumbnail view.
  • Page 93 Blackmagic Media Express Clips marked as favorites will show a yellow star in their icon in Timecode List view and Thumbnail view. Once you have marked clips as favorites, click on the gray, Favorites, star button at the top of the Media list and it will turn yellow.

  • Page 94: Help

    • On Mac OS X, open ATEM Software Control from the Applications folder. Select About ATEM Software Control from the application menu to reveal the version number. • On Windows 7, open ATEM Software Control from your Start menu. Click on the Help menu and select About ATEM Software Control to reveal the version number.
  • Page 95 Warranty 12 Month Limited Warranty Blackmagic Design warrants that this product will be free from defects in materials and workmanship for a period of 12 months from the date of purchase. If a product proves to be defective during this warranty period, Blackmagic Design, at its option, either will repair the defective product without charge for parts and labor, or will provide a replacement in exchange for the defective product.
