12. SYSTEM CONFIGURATION on the floor
-10°
-10°
For floor applications you can set up a maximum of 3 speakers each K-feet4
For flying applications you can append a maximum of 4 KH4 each K-fly4

13. VARIABLE VERTICAL COVERAGE

The KH4 is equipped with 2 driver slides. So that you can set up the preferred vertical coverage of the speaker.
USER'S MANUAL
DS 10
KH4
DS 10
-10°
KS4
-10°
KS4
7°
DS 10
KH4
DS 5
-10°
KS4
-10°
KS4
KS4
KS4
KS4
37°
