Encore E-6 Quick Start User Manual

CAR LOCATOR

Under armed mode, press the button to active car locator function. The siren will chirp 6
times. The parking light will flash 12 times, for you to easily locate your car.

PANIC FUNCTION:

The transmitter can be used as a remote panic switch to manually trigger the alarm in
case of emergency.
Press and hold the button for 3 second. The alarm will immediately sound.
To stop the alarm, press the trunk button on the remote control.
If the button is not pressed, the alarm will automatically stop after 30 seconds.

TRIGGER THE SYSTEM

When armed, your vehicle is protected as follows:
Light impact will trigger the warn-away signal.
Heavy impacts / Doors open /(if installed) Hood open / (if installed) Trunk open / Turning
on the ignition key will trigger the programmed sequence.
The starter disable relay (if installed) prevents the vehicle's starter from cranking. The
siren, horn, parking lights, and dome light will turn on alerting of an intrusion for 30
seconds. Then it will stop and automatic reset and re-arm. If the any one of the sensors or
detectors is still active, the alarm system will sound a maximum of 3 times of 30
seconds cycles.
NOISE ABATEMENT CIRCUIT: Your system has a "Noise Abatement Circuit". It prevents
annoying repetitive trigger sequences due to faulty door pin switches or environmental
conditions such as thunder, jackhammers, airport noise, etc.
Here's how "Noise Abatement Circuit" works: The shock sensor triggers five times, the
"Noise Abatement Circuit" will interpret this pattern of triggers as a false alarm. After the 5
trigger, the "Noise Abatement Circuit" ignores, or bypasses, that sensor or switch until a
different sensor or switch is triggered.
TRUNK RELEASE: Press and hold button on the transmitter for two seconds to
remotely control the trunk release.

ANTI CAR- JACKING (Programmable)

Warning: If you don't need the carjacking function in this alarm system, be sure to set
carjacking feature "OFF". This systems default setting is "OFF" for all carjacking modes.

ACTIVE ANTI CAR JACKING:

1. Ignition ON, press and hold the and buttons at the same time for 2 seconds.
The parking lights will turn on for 1.5 seconds to indicate the system has entered the
anti car-jacking mode.
2. Once the system in anti car-jacking mode, the system will be triggered when any
door is opened and closed while the ignition is "ON".
PASSIVE ANTI CAR- JACKING: (Programmable)
It will operate as noted below:
1. Turn the ignition switch to the "ON" position and the system will arm.
2. Once the system is armed, if you are forced from the vehicle, the system will trigger
when the door is opened and closed while the ignition is "ON".

TRIGGERING THE ANTI CAR -JACKING MODE:

A). 50 seconds after the system has been triggered. The siren will start chirping for 15
seconds.
B). During this 15 second period of chirping, you will be alerted to push the valet switch once
to turn off the car-jacking feature. If not, it will enter a second timer for carjacking.
C). 65 seconds after the system has been triggered, the siren will start sounding and the
parking lights will start flashing.
D). 90 seconds after the system has been triggered,
1. The siren will sound and the parking lights will flash, and
2. The starter disable will activate to prevent the vehicle from starting.
3. It will remain active until the vehicle's battery power is exhausted.

OVERRIDE THE SYSTEM TO TURN OFF ANTI CAR- JACKING:

Turn the ignition switch from OFF to ON, and within 10 seconds push valet switch, the
siren will stop and the system disarmed

Remote Start Operation:

WARNINGS:
As with any product that performs automatic functions, there are certain safety precautions that
you must practice and be aware of.
1. Keep the transmitter out of children's reach.
2. Do not leave anyone in the vehicle while running on remote control.
3. Alert servicing personnel that the vehicle can be started automatically.
4. Do not start the vehicle by remote while it's in an enclosed area or garage.
5. Always apply the parking brake and lock the vehicle as you exit the vehicle.
6. The vehicle windows must be rolled up.
7. Should the unit malfunction, disconnect the fuse until the problem is corrected.
8. The use and operations of this system is the sole responsibility of the operator.
9. Some areas may have local ordinances that prohibit leaving a vehicle running on public
streets.
10.It is not safe to remote start the vehicle if the vehicle is parked on a steep incline.

TO REMOTE START THE VEHICLE:

When you want to start your vehicle,
1. Press button once on the transmitter.
2. The parking light will activate to indicate the remote start received the signal.
3. The engine will start in approximately 5 seconds.
4. Once the engine is running, after couple seconds the parking lights will turn on and the
climate controls will activate and adjust the vehicle's interior temperature to your preset setting.
(While the vehicle is running, the "minutes" digit on the LCD screen will flash and the will indicate
th
countdown timer based on the 5, 10, 20 or 30 minute run time set up by your installation center.)
5. The vehicle will run for a programmable 5 to 30 minute cycle before shutting down. (When
the unit shuts off the countdown timer will turn off and the transmitter will play a melody.)
NOTE: The Remote Start Unit will not start the vehicle if any one of the following
conditions exists:
1. The hood is opened.
2. The brake pedal is pressed.
3. The optional remote start enable toggle is switched to the "OFF" position. (If installed)
4. The gear selector is in any gear other then "PARK" or "NEUTRAL".
SAFE START (Child safety mode)
Factory default is set to press the button once on the transmitter to start the vehicle. You can
program this feature to eliminate an accidental remote start:
1. The user presses the transmitter buttons twice within 3 seconds to start the vehicle.
NOTE: Contact your installing dealer to activate this feature.
OPERATE THE VEHICLE WHILE RUNNING FROM THE REMOTE START:
To operate the vehicle while the engine is running from the remote start,
Insert the ignition key and turn it to "ON" (not the start) position.
Press the brake pedal.
Note: If the brake pedal is pressed before the key is in the ON position, the engine will shut down.

TEMPORARY STOP FEATURE:

This feature allows the vehicle to remain running after the key has been removed from the ignition.
This feature is useful for occasions when you wish to exit and lock the vehicle for short periods of
time, but would like to leave the motor running and the climate control on.
1. Before turning off the engine, press the
indicator will flash 3 times to confirm enter.
2. Turn the ignition key to OFF position. (The engine will stay running.)
3. The engine will run until the pre-programmed time elapsed or shutdown input is received.
E
ncore Automotive Systems, LLC.
All rights reserved
For Warranty information, Please go to www.encoreautomotivesystems.com
the complete user's manual. For customer service, please call us toll free @ (855) GO-
ENCORE 855.463.6267. 8:00-5:00 PST Thanks for your purchase!

TO TURN OFF THE REMOTE START:

When the engine is running (by remote start), if you want to stop it,
Press
Press this button twice if the unit is programmed to child safety start.
Press the brake pedal
The vehicle will shut down and turn off the parking light to indicate the engine has
stopped.
SHUT-DOWN INPUT FOR REMOTE STARTER:
If any of the following conditions exist while the system is operating, the engine will
not start or will shut down immediately:
1. The hood is opened.
2. The brake pedal is pressed.
3. The parking (hand) brake is released (For Turbo Timer Mode)
4. Engine is over-revved. {"Tachometer checking type" only}
5. The pre-programmed run time (5 /10 / 20 / 30 minutes) has elapsed.
6. Press
7. The system triggers.
8. The vehicle refused to start running after {3} unsuccessful attempts.
1.
2.
3.
4.
5.
button once on the transmitter and the LED
6.
7.
8.
.
and download
**IMPORTANT NOTE: Any damages resulting from an installation performed by anyone other than a
professional installation technician authorized by Encore will void the product's Limited Lifetime
Warranty.
button once on the remote transmitter under the remote start mode.
button on the remote transmitter under remote start mode.
ENCORE LIMITED LIFETIME WARRANTY PROVISIONS
( U.S. ,Continental U.S. and Canada Only)
Encore Automotive Systems LLC. WARRANTS that this new unit has been thoroughly inspected and
tested at the factory prior to delivery. Your Encore equipment is guaranteed for "life" to the original
purchaser/user of the equipment and the original vehicle in which it was installed by an authorized
installer under the following conditions: If the product proves defective (according to Encore's
testing) within the first year, the defective unit may be exchanged or repaired free of charge. "Proof
of Purchase" (dated sales receipt) must accompany all warranty returns; otherwise, your return will
be rejected and sent back. After one (1) year, the purchaser should ship the unit prepaid to Encore
with a money order in the amount of $30.00 to cover shipping and handling charges. Note: The
product needs to be registered online at time of installation. To register this product go to,
www.encoresautomotivesystems.com .
Exclusion to the Limited Lifetime Warranty Provision: All two‐way LCD and two‐way OLED remote
transceivers are excluded from the Limited Lifetime Warranty noted in paragraph no.1. All two‐way
LCD and two‐way OLED remote transceivers are guaranteed to the original purchaser for a period of
one year from date of purchase. If the product proves to be defective within the first year, the
defective unit may be exchanged or repaired free of charge. All other provisions stated on this card
apply.
This WARRANTY will be considered void if the equipment has been misused, neglected, improperly
serviced or installed, altered, dropped or damaged by water, contrary to the Encore OPERATIONS
MANUAL. Or, if used with accessories not approved by Encore, which may have contributed to the
defect. See note below regarding product installation**.
The purchaser's remedies under this WARRANTY shall be limited to the repair or replacement of
electronic components only. THE FOLLOWING IS NOT COVERED: Damages or deterioration to cases,
batteries, covers and cabinets; the cost of repairs, replacement and labor of which shall be borne by
the purchaser even if occurring during the WARRANTY period.
Any equipment or parts which are claimed to be defective under this WARRANTY must be sent to
the Encore Service center with "proof of purchase" at the purchaser's expense prior to such return,
a Return Authorization Number needs to be obtained. Encore will return the equipment, charges
prepaid. Warranty Service can be provided through the dealer where the equipment is originally
purchased.
Any unexpired WARRANTY shall be applicable to equipment and parts in the possession of the
original purchaser only.
THIS WARRANTY IS IN LIEU OF ANY AND ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED,
INCLUDING BUT NOT LIMITED TO ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE.
Encore shall not be liable, under the foregoing WARRANTIES or otherwise, for: Any personal injury or
property damage of any kind to the purchaser or property, its employees or agents or anyone else
whomsoever resulting directly or indirectly from the use or presence of the equipment or parts;
Consequential damages of any kind; any inability of the purchaser to use the equipment.
