General Installation Manual
© Apr 2012, SANYO Electric Co., Ltd. All Rights Reserved
(a) Long frame and Short frame (Not J-Box side)
0.7"
0.4"
3'
(b) Short frame (J-Box side)
0.7"
0.4"
3'
Glass side of the module
Drill in this area
Glass side of the module
5"
Drill in this area
Figure 4.3
Acceptable area for drilling
8
3"
5"
3"
