Page 1: User Manual
User Manual Rittal PMC UPS 6kVA Germany Rittal GmbH & Co. KG Auf dem Stützelberg D-35745 Herborn Tel.: ++49-27 72-5 05-0 Fax: ++49-27 72-5 05-23 19 Internet: www.rittal.de... -
Page 2: Table Of Contents
Safety Instructions..................30 Indicators and Operating Controls............... 33 Front Panel ....................33 Back Panel....................35 Installation and Start Up ................36 Permanently connected unit RITTAL PMC UPS 6KVA ....... 36 Battery extension..................40 Troubleshooting....................42 Maintenance....................45 Operation....................45 Storage...................... 45 Technical data.................... - Page 3 6kVA ......................40 Figure 6: Circuit diagram of relay interface ............. 49 Figure 7: Front and back view of RITTAL PMC UPS 6KVA ......... 51 Figure 8: Back view of battery extension for RITTAL PMC UPS 6KVA ......................52...
-
Page 4: Introduction
1. Introduction The Rittal PMC UPS 6kVA Series is an uninterruptible power supply incorporating double-converter technology. It provides perfect protection specifically for Novell, Windows NT and UNIX servers. The double-converter principle eliminates all mains power disturbances. A rectifier converts the alternating current from the socket outlet to direct current. -
Page 5: Safety Instructions
• Do not block off ventilation openings in the UPS system’s housing. Installation • Please note the special installation aspects for the permanently connected units Rittal PMC UPS 6kVA in Chapter 4 „Installation and Start Up“. • The building wiring socket outlet (shockproof socket outlet) must... - Page 6 • In order to fully disconnect the UPS system, first press the Standby switch then disconnect the mains lead or, on the permanently connected unit Rittal PMC UPS 6kVA, isolate the incoming feeder. • Ensure that no fluids or other foreign objects can enter the UPS system.
- Page 7 • Caution - risk of electric shock. Even after the unit is disconnected from the mains power supply (building wiring socket outlet), components inside the UPS system are still connected to the battery and are still electrically live and dangerous. Before carrying out any kind of servicing and/or maintenance, disconnect the batteries and verify that no current is present.
-
Page 8: Indicators And Operating Controls
3. Indicators and Operating Controls 3.1 Front Panel Figure 1: Operating and display panel Switch Function ON - Switch 1. Turn on UPS system: By pressing the ON-Switch „I“ the UPS system is turned on. 2. Deactivate acoustic alarm: By pressing this switch an acoustic alarm can be deactivated. - Page 9 Standby- The UPS system switches to Standby mode when the Standby button „ “ is pressed. It is then switched to Switch Bypass and the inverter is off. The output sockets are supplied with voltage via the bypass if the mains power supply is available.
-
Page 11: Back Panel
Load and 1. These LEDs signal the UPS system load if the battery mains power is available (normal operation): capacity 1st LED 1-35 % 2nd LED 35-55 % 3rd LED 55-75 % 4th LED 75-95 % 5th LED 95-100 %. 2. -
Page 12: Installation And Start Up
4. Installation and Start Up 4.1 Permanently connected unit RITTAL PMC UPS 6kVA The system may be installed and wired only by qualified electricians in accordance with applicable safety regulations! When installing the electrical wiring, please note the nominal amperage of your incoming feeder. UPS> 6000 VA are not suitable for 16 A sub-distribution boards! 1) Inspect the packaging carton and its contents for damage. -
Page 13: Figure 3: Attaching The Stabiliser To Rittal Pmc Ups 6Kva
Figure 3: Attaching the stabiliser to RITTAL PMC UPS 6KVA. The supports must be unscrewed adequately on both sides so that the castors are not contacting the ground! 3) Please ensure that the incoming feeder is isolated and secured to prevent it from being switched back on again. -
Page 14: Figure 4: Connection Diagram For Rittal Pmc Ups 6Kva
Figure 4: Connection diagram for RITTAL PMC UPS 6KVA 5) Connect your computer to the screw-type terminals of the UPS system as shown in the above diagram. Caution! Do not connect equipment which would overload the UPS system (e.g. laser printers). Do not connect domestic appliances to the UPS system. - Page 15 UPS system directly without charging it but the stored energy time may then be shorter than the nominal value specified. 8) Set the O/P switch on the back panel to position „ON“. 9) Press the On button „I“ on the front panel. Note: The INVERTER LED lights up after 10 seconds.
-
Page 16: Battery Extension
1. Disconnect the UPS system from the mains power supply and the load from the UPS system. 2. Connect the battery extensions to the UPS system with the included cables according to the following instructions: Figure 5: Connection of battery extensions to RITTAL PMC UPS 6KVA. - Page 17 3. The UPS system can now operate normally. Note: Operating the system with external battery extensions prolongs charging to 24 hours with one battery extension and to 48 hours with two battery extensions after total discharge.
-
Page 18: Troubleshooting
5. Troubleshooting If the UPS system does not operate correctly, please attempt to solve the problem using the table below. Problem Possible cause Remedy No indication, Check building wiring no warning tone No input voltage socket outlet, check input cable even though system Set the I/P switch to „ON“... - Page 19 INVERTER- Not necessary, battery LED lights up, operation; Mains power supply warning tone at warning tone at intervals has failed intervals (every of 1 second means battery 1 or 4 seconds) is almost empty INVERTER-LED lights up, warning Set the I/P switch to „ON“. tone in intervals (1 If the problem persists, to 4 seconds),...
- Page 20 Please have the following information at hand before calling the After-Sales Service Department: 1. Model number, serial number 2. Date on which the problem occurred 3. Detailed description of the problem...
-
Page 21: Maintenance
6. Maintenance 6.1 Operation The UPS system contains no user-serviceable parts. If the battery service life (3 - 5 years at 25 °C ambient temperature) has been exceeded, the batteries must be exchanged. In this case please contact your dealer. 6.2 Storage If the batteries are to be stored in temperate climatic zones, they should be charged every three months for 1-2 hours (see Chapter... -
Page 22: Technical Data
7. Technical data 7.1 Electrical specifications Model number 6kVA INPUT Voltage 230 VAC (160 – 276 VAC) ± 3% Frequency 50/60 Hz ± 5 % automatic detection Current 29,6 A (maximum) OUTPUT Power rating 6000VA 4200 W Voltage 220/230/240 VAC ± 0,5% (synchronized) 50/60 Hz ±... -
Page 23: Typical Stored Energy Time (Battery Mode)
7.2 Typical stored energy time (Battery mode) Typical values at 25°C in minutes: Model 100 % 50 % Load Load RITTAL PMC UPS 6KVA RITTAL PMC UPS 6KVA + 1 battery extension RITTAL PMC UPS 6KVA + 2 battery extensions Dimensions and weights Dimensions Gross... -
Page 24: Port Connectors
7.5 Port connectors A computer can be connected to the port connectors RS232 interface on the back panel of the UPS system.This allows • the UPS system to be monitored, • the mains system to be monitored, • data to be backed up, •... -
Page 25: Figure 6: Circuit Diagram Of Relay Interface
Figure 6: Circuit diagram of relay interface Description of the PIN assignment: Battery mode normally PIN 2 is shorted to PIN 4 open (ground) if the mains power supply fails or is out of tolerance. UPS shut-down 6, 7 If, in the case of battery in case of operation, a positive signal battery... - Page 26 an extent that the remaining emergency supply period at full load is less than 2 minutes. Normal mode normally PIN 3 is shorted to PIN 4 closed during normal operation and opened, if the mains power supply fails or is out of tolerance...
-
Page 27: Appendix
8. Appendix Figure 7: Front and back view of RITTAL PMC UPS 6KVA... - Page 28 Figure 8: Front and back view of RITTAL PMC UPS 6KVA BatteryPack...
