TFT-LCD TV
W153D

USER MANUAL

READ CAREFULLY
BEFORE OPERATION
W153D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W153D and is the answer not in the manual?

Questions and answers

Related Manuals for Avtex W153D

Summary of Contents for Avtex W153D

  • Page 1: User Manual

    TFT-LCD TV W153D USER MANUAL READ CAREFULLY BEFORE OPERATION W153D...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS TO PREVENT ELECTRICAL SHOCK. CAUTION DO NOT REMOVE THIS COVER. NO USER- SERVICEABLE PARTS INSIDE. RISK OF ELECTRIC SHOCK. REFER SERVICING TO QUALIFIED DO NOT OPEN. SERVICE PERSONNEL. T h i s s y m b o l i n d i c a t e s This symbol indicates d a n g e r o u s v o l t a g e important instructions...
  • Page 3 IMPORTANT SAFETY INSTRUCTIONS Do not clean the front with keton-type materials (e.g.Acetone ),ethyl alcohol, toluene, ethy lacid, methyl, or chloride-these may damage the panel. Locate your DC adapter near an easily accessible AC outlet. If your LCD TV does not operate normally in particular, if there are any unusual sounds or smells coming from it unplug it immediately and contact an authorized dealer or service center.

  • Page 4: Table Of Contents

    CONTENT INSTALLATION Normal installation PANEL BUTTON FUNCTIONS Panel control Rear panel EXTERNAL EQUIPMENT Connecting diagram REMOTE CONTROL HANDSET Remote buttons Battery installation LET'S START Changing source operation TV MENU SETUP Sound Picture TV setup OSD setup Function TELETEXT FUNCTION Teletext function AV, SCART and YPBPR SETUP Video setting menu VGA SETUP...
  • Page 5 CONTENT DVD OPERATION VCD, SVCD menu playback PBC playback Direct play Memory Select track to play directly Select language/audio by number buttons Repeat playback of selected segment Repeat playback Fast playback Play from the desired position MPEG4 and JPEG file playing Zooming the displayed frame Headphone enjoying CARD READER AND USB OPERATION...

  • Page 6: Installation

    INSTALLATION NORMAL INSTALLATION Hook Ostium M4 10 Screw 1pcs Kickstand Rear viewing of LCD TV 1, Hook the tache (labeled A)of the kickstand onto the plate (labeled C). 2, Tighten the screws ( M4 10) through the ostium (labeled B). 3, Figure shows the finished installation.

  • Page 7: Panel Button Functions

    PANEL BUTTON FUNCTIONS PANEL CONTROL Front panel IR sensor window Indicator( Indicator is red when in standby mode, green when working normally. Left panel SETUP (Enter or exit setup menu) VOL+/-(Increase or decrease volume) CH+/- (Increase or decrease channel number) SOURCE (Enter to exit source menu) STANDBY (To switch between standby mode and power-on mode) Headphone jack...
  • Page 8 PANEL BUTTON FUNCTIONS REAR PANEL COAXIAL VIDEO SCART SCART input terminal YPbPr or YCbCr input terminal VGA input terminal Composite video/audio input PC audio input Coaxial digital audio output 12V DC input terminal R input terminal...

  • Page 9: External Equipment

    EXTERNAL EQUIPMENT CONNECTING DIAGRAM COAXIAL VIDEO SCART cable DVD or VCR player Power amplifier (with coaxial digital audio in) NOTE You should connect the interconnecting cables BEFORE plugging in the power cord.

  • Page 10: Remote Controller

    REMOTE CONTROLLER REMOTE BUTTONS EJECT Disc in/out in DVD. ] button To play normally or pause playing in DVD . ] button To fast-forwards DVD playback in DVD . ] button To select the next chapter or track in DVD. Number button To select program number.

  • Page 11: Tv Setup

    REMOTE CONTROLLER STANDBY To switch between standby mode and power- on mode. ] button To fast backward playback in DVD. ] button To select the previous chapter or track in DVD. ] button To stop playing in DVD . TWO-DIGIT NUMBER BUTTON To switch between one or two-digit program number.

  • Page 12: Power Supply

    REMOTE CONTROLLER BATTERY INSTALLATION Remove the battery cover. Insert two SUM-4(AAA) batteries matching the -/+ polarities of the battery to the -/+ marks inside the battery compartment, as in the following figure: BATTERY LIFE Generally speaking, the battery may be used for one year, but the battery life is also related to the usage times and remote controller operation.

  • Page 13: Change Source Operation

    LET'S START After this unit is well fixed on the desk or on the wall, and the cords are well connected for input and output, what you should do next is: Firstly, connect the adapter to the LCD TV, and turn on the power switch then the unit will go into standby mode, you can see the indicator turn red.
  • Page 14 TV MENU SETUP This product can store up to 100-channel programs (0 99). In TV, press [SETUP] button and the setup menu will show as follows: Pressing [ ] button on the remote control, you can select setup menu sections (setup PICTURE menu consists of "...
  • Page 15 TV MENU SETUP NOTE Select "BRIGHTNESS " to adjust it, the sub item will show as follows : press [ ] button to adjust the value of brightness. BRIGHTNESS " CONTRAST , TINT , SHARPNESS , SATURATION are as the same. "...
  • Page 16 TV MENU SETUP SOUND Select " "and menu will show as follows: SOUND SOUND MODE USER BALANCE BASS TREBLE NICAM MONO SELECT ENTER SETUP RETURN Press [ ] button to select different items and press [ ] button to adjust them. The following are the descriptions of the sound item.
  • Page 17 TV MENU SETUP T V S E T U P Select " " and TV setup menu will show as follows: TV SETUP CHANNEL COLOR SYSTEM AUTO SOUND SYSTEM AUTO FINE TUNING 40.00MHZ MANUAL SEARCH AUTO SEARCH CHANNEL EDIT SELECT ENTER SETUP RETURN...
  • Page 18 TV MENU SETUP Select "AUTO SEARCH " , the searching menu will show as follows: AUTO SEARCH VHF L 112.25MHZ PRESS SETUP TO EXIT The number of programs have been found. The current searching frequency. The current searching frequency Band, 3 Bands in total: "VHF L" ,"VHF H"," UHF". Select "CHANNEL EDIT "...
  • Page 19 TV MENU SETUP OSD SETUP You can adjust the relative parameters of OSD itself here. Select " " item and OSD SETUP menu will show as follows: OSD SETUP ENGLISH LANGUAGE OSD H-POSITION OSD V-POSITION OSD DURATION TRANSPARENCY SELECT ENTER RETURN SETUP Press [...

  • Page 20: Function

    TV MENU SETUP FUNCTION Select " " item and FUNCTION menu will show as follows: FUNCTION FULL ASPECT RATIO NOISE REDUCE SLEEP FM TRANSMIT TRANSMIT FREQ 93 MHz RESET SELECT ENTER SETUP RETURN Press [ ] button to select different items and press [ ] button to adjust them.

  • Page 21: Teletext Function

    TELETEXT FUNCTION Most TV stations provide cost-free teletext information, including the latest news, weather information, TV program list and stock information, etc. You just input the needed teletext page according to the teletext content. TELETEXT DISPLAY Select the channel with teletext signal; Press [TEXT] button;...

  • Page 22: Av, Scart And Ypbpr Setup

    AV ,SCART and YPBPR SETUP VIDEO SETTING MENU The menu setup of AV/SCART /YPBPR modes is much the same as that of TV mode, except the " " section is invalid and a bit difference in sound mode. It is not repeated here.

  • Page 23: Vga Setup

    VGA SETUP With the VGA mode supported up to 1024*768@75Hz, and speakers built in, you can use this unit as a multimedia PC monitor. When this unit works in VGA mode, the following setup can be done. Press [SETUP] button to enter main section. Press [ ] button to select sections and then press [ ] button or [OK] button to enter.
  • Page 24 VGA SETUP Here shows the color temperature sub menu. COLOR TEMPERATION MODE NORMAL GREEN BLUE Press [ ] button to select item and press [ ] button to adjust the value of the item. Item Description Select color temperature mode :"USER", "NORMAL", "WARM" MODE and "COOL".

  • Page 25: Monitor Setup

    VGA SETUP M O N I T O R S E T U P Press [ ] button to select " " and press [ /OK] button to enter. MONITOR SETUP H - POSITION V - POSITION FREQUENCY PHASE SELECT ENTER RETURN SETUP...
  • Page 26 VGA SETUP O S D S E T U P Press [ ] button to select " " and press [ /OK] button to enter. OSD SETUP ENGLISH LANGUAGE OSD H-POSITION OSD V-POSITION OSD DURATION TRANSPARENCY SELECT ENTER RETURN SETUP Press [ ] button to select different items and press [ ] button to adjust .

  • Page 27: Function

    VGA SETUP F U N C T I O N Press [ ] button to select " ", and press [ /OK] button to enter. FUNCTION FULL ASPECT RATIO NOISE REDUCE SLEEP FM TRANSMIT TRANSMIT FREQ 93 Mhz RESET SELECT ENTER SETUP RETURN...

  • Page 29: Dvd Operation

    DVD OPERATION Compatible Disc Types Types Sizes Recorded Contents 12cm CD-DA Digital audio VIDEO CD Compressed digital audio+compressed digital video 12cm (dynamic picture) DIGITAL VIDEO SVCD: Compressed digital audio+compressed digital video 12cm (dynamic picture) DVD: Compressed digital audio+compressed digital video 12cm (dynamic picture) NOTES...

  • Page 31: Dvd Operation

    DVD OPERATION PLAY/PAUSE PLAYBACK MPEG4 SVCD 1. Press [ ] button in playback status. Press [ ] button once to pause playback, display on TV screen: 2. To restore playback, press the [ ] button. PLAY NOTE When you set the screen save mode to ON(see Page 40 for details), the display on TV screen turns to screen saver status after the picture on TV screen keep still for about 2 minutes (in mode such as pause mode, stop mode, menu select, set up menu, no disc mode and so on).

  • Page 32: Vcd, Svcd Menu Playback

    DVD OPERATION 1. Press [MENU] button to display menu on TV screen for selection, operate according to the hint of menu and press number buttons to select. PLAY ROOT MENU 1..2..3..Number 2. Press cursor button to select track you desired, then press [ ] button or [OK] button.

  • Page 33: Pbc Playback

    DVD OPERATION PBC PLAYBACK SVCD Enjoy PBC alternate function when playing Super VCD, VCD2.0 disc with PBC function, For example:playVCD2.0 disc. 1. Main menu displays on TV screen A: 1..2..Press number button to select. For example: select main menu 1. The TV screen as show in B: 1.

  • Page 34: Select Track To Play Directly By Number Buttons

    DVD OPERATION MEMORY 1. This player can save the currently played time point automatically when you leave the current DVD disc playback (switch from DVD signal source to other signal source, enter standby state in DVD mode). 2. When switching to DVD playback state again, this player can automatically search the time point saved last time to continue playing.

  • Page 35: Repeat Playback

    DVD OPERATION DVD disc: Audio Chinese Audio French As for VCD, SVCD or CD disc with multiple channels, you may select audio output from left or right channel or select stereo audio output. For VCD disc, left channel records dubbing and right channel records singing, and you may select left channel for dubbing.

  • Page 36: Repeat Playback Of Selected Segment

    DVD OPERATION REPEAT PLAYBACK OF SELECTED SEGMENT MPEG4 SVCD When playing disc, you may press [A-B] button to play your desired segment content repeatedly. 1. In normal playback, press [A-B] button at the beginning point (point A) of the segment that you desire to play repeatedly.

  • Page 37: Play From The Desired Position

    DVD OPERATION PLAY FROM THE DESIRED POSITION MPEG4 SVCD Play DVD disc Inputting a certain time, title number or chapter number directly may search in the disc fast and then play forward from this position. 1. Search title and chapter. For instance, search the 2nd chapter in title 6. Press [GOTO] button and TV screen displays: Title 03/30 Chapter Press [...

  • Page 38: Zooming The Displayed Frame

    DVD OPERATION 3. Select the track Press [GOTO] button until TV screen displays the following figure. Press number buttons to input track. Select Track -- /15 GOTO ZOOMING THE DISPLAYED FRAME MPEG4 SVCD Zoom in/out the player frame. 1. When playing a disc, press the [ZOOM] button can open the zoom in/out function, and the TV screen displays( take X2 mode as an example): The frame is magnified to 2 times of the normal size.
  • Page 39 DVD OPERATION State window Scroll bar window Display the current Indicate the current file's position. 00:00 00:00 004/369 state information. \PIC\ DIR window Preview window Display the current JPEG image preview. Du000 Du001 path. Du002 File window Information window Display the current Display the current operation path's file.
  • Page 40 DVD OPERATION Other basic operation methods 1. Press [ ] button may turn to the next or last page. Other functions of JPEG file 1. When playing JPEG file, pressing [ ] button will achieve preview playback function. At the same time, all JPEG files are displayed on TV screen. One page can display up to 12 pictures at most.

  • Page 41: Card Reader And Usb Operation

    CARD READER AND USB OPERATION USAGE OF USB DEVICE AND 3 -IN-1 CARD READER USB refers to Universal Serial Bus. Most of USB devices on the market are USB1.1 or USB2.0. Here are some common types of USB 1.1 devices: Monitors, Communication devices, Audio Human Input Device(HID), Mass storage drives etc.
  • Page 42 CARD READER AND USB OPERATION NOTES This player can play USB devices and MPEG4 and JPEG files in SD, MMC and MS cards. When reading MPEG files with large size in USB device or media card, pause may appear. If there is no files in USB devices or media card , on-screen appears "Empty Device". If USB devices or media card have a problem, or the operation is incorrect, the screen displays "Device Error".

  • Page 43: Dvd Function Setup

    DVD FUNCTION SETUP Turn on this TV, press [SOURCE] button to change source to DVD, press [SETUP] button, then press [ ] button to choose DVD item, the DVD setup menu will be displayed as follow: GENERAL SETUP General Setup Page TV Display Wide OSD Lang...
  • Page 44 DVD FUNCTION SETUP SPDIF Setup Page SPDIF Output SPDIF/RAW SPDIF/PCM LPCM Out Setup SPDIF SPDIF output: This item is used to set the bit stream type of the digital output. Optional settings: SPDIF/RAW, SPDIF/ PCM; Default: SPDIF/RAW LPCM output: This item is used to set the output frequency of LPCM audio data to fit for different power amplifiers.

  • Page 45: Video Setup

    DVD FUNCTION SETUP VIDEO SETUP Video Quality Setup Sharpness Brightness Contrast Gamma None Saturation Go To Video Setup Page 1. Sharpness: This item is used to set the sharpness of video outputs. Optional settings: High, Medium, Low; Default: Med. 2. Brightness: This item is used to set the brightness of video outputs. 3.

  • Page 46: Password Setup

    DVD FUNCTION SETUP NOTE Audio, subtitle and disc menu language are only effective in DVD mode. If the disc is not recorded with the language you appointed, the unit will apply the language that the disc appointed to play. Select other languages: press [ ] button to move cursor to "OTHER"...

  • Page 47: Advanced Setting

    DTV MENU OPERATION Press the [DTV SETUP] button, then the Main Menu will be displayed, you can set your preferences in that, such as search channels, edit the channel list or your favorite list , view Programme Guide Information. It is easy to see that the Main Menu is composed Main Menu of six parts: General Setting, Channel Install, General Setting...
  • Page 48 DTV MENU OPERATION Channel Search You can set the search mode as new or add . Channell Search Then press [ OK ] button to confirm it. Installation type Note: If the mode is new, will delete the old channel the current frequency. If the mode is add, do not delete the old channel the current frequency.

  • Page 49: Channel Manage

    DTV MENU OPERATION CHANNEL MANAGE Channel Manage Create a favourite list The Favorite lists menu allows you to create, Modeify a favourite list modify and delete your own favorite lists but not Delete a favourite list the two default service lists (TV, Radio). Four TV favorite lists and four radio favorite lists can be created.
  • Page 50 DTV MENU OPERATION Default TV/Radio lists On these lists, only the Lock/unlock option is available: a press on the [RED] button will " " lock the highlighted channel if unlock and vice-versa (toggle behavior). TV/Radio favourite lists For all these lists, a few actions are available: Add/Skip: Toggle behavior on the [GREEN] button, in front of the channel list a color icon indicates the status (white for skipped, blue for added).
  • Page 51 DTV MENU OPERATION ADVANCED SETTING The parental control item allows you to enable or disable the locking management. Advanced Setting Parental control Disabled Channel lock Maturity level PIN change SETUP EXIT Parental Control If the parental control item is disabled then all the locking are deactivated, If it is enabled then all the locking are applied according to your choice.

  • Page 52: System Info

    DTV MENU OPERATION ELECTRONIC PROGRAM GUIDE (EPG) By pressing the Guide button, an Electronic Program Guide is displayed. The EPG supplies information, such as program lists, start and end times of all available channels. In addition, In addition, the detailed information about the program is often available in he EPG. (The availability and the amount of program details will vary depending on the broadcaster.) A press on the [ ] buttons allows you to consult all event pages for the days, a press on...

  • Page 53: Program Information

    DTV MENU OPERATION Factory Settings This acknowledge pop-up allows you to erase all the custom parameters. If it is confirmed, all All private settings and other user data services lists and user preferences are deleted will bu erased. and the DTV restarts as for a First Time "...
  • Page 54 DTV MENU OPERATION and changes the selected channel accordingly. Zapping can also be done by entering channel number using digit keys. The channel list is displayed and is automatically removed from the screen after few seconds. BBC ONE Wales BBC 2W The screen bellow corresponds to the TV list.

  • Page 55: Sound And Tv Troubleshooting

    TROUBLESHOOTING Please check for causes of problems in accordance with the following chart before contacting maintenance personnel. DISPLAY TROUBLESHOOTING Causes and Correction Symptom Check whether the power cord is well connected, and whether this unit is powered on Black screen, power indicator light off Check whether the signal cord of input device is well connected...
  • Page 56 TROUBLESHOOTING DVD TROUBLESHOOTING Symptom Causes Correction 1. Condensation on laser head 1. Switch on power and wait for 1 to 2 hours 2. Disc not properly loaded 2. Make sure label side of the disc facing up Not play 3. Disc not compatible with the unit 3.
  • Page 57 SCART YPBPR Power Normal Standby mode Less than Input connector IEC-Type, IEC 169-2, Female Frequency range (VHF/UHF) 174MHz 858MHz Channel range(VHF/UHF) 7 & 8 Mhz W H D Because of disc quality and format differences we cannot assure the unit will read all. Some functions cannot utilized on some discs, but this is not a fault with the machine.
  • Page 58 DISPLAY MODE SUPPORTED PC INPUT MODE Hor scanning frequency Ver scanning frequency Pixel frequency Format Resolution (KHz) (Hz ) (MHz) 640 350 31.5 70.0 25.17 31.5 70.0 720 400 28.32 31.5 60.0 640 480 25.18 37.9 72.0 640 480 31.50 VESA 37.5 75.0...
  • Page 59 DISPLAY MODE SUPPORTED VIDEO INPUT MODE Hor scanning frequency Ver scanning frequency Vert scan type Format ( KHZ) (HZ) 720X480 31.5 480P 720X480 15.6 480i 720X576 31.2 576P 720X576 15.6 576i NOTE Specifications and designs are subject to change without notice.
  • Page 60 ACCESSORIES Please check the following accessories. Remote control and battery User manual Power adapter Kickstand Kit AV cord Wall Mount Holder Kit (optional) Automotive Power socket adapter 5196136 V0.0...
