Cabinet Parts - KitchenAid KBLS19KTSS00 Parts List

For Models: KBRS19KTWH00, KBRS19KTBL00, KBRS19KTSS00, KBLS19KTSS00
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10136388 Owners Manual
W10138304 Energy Tag
67006716 Tech Sheet
2 Cabinet (Not a
Servicable Part)
3 Plug, Button (3)
67001130 White
67001131 Black
5 67002227 Roller Assembly
6 12627302 Clip, Grille
7 67006642 Pin, Center Hinge
8 67006611 Bolt, Adjusting
(Rear)
9 67006521 Screw
10 12456801 Bracket, Roller

CABINET PARTS

(White) (Black)
Illus. Part
No. No. DESCRIPTION
11 67006380 Screw
12 67005822 Screw
13 A3076901 Plug, Button
14 67006303 Screw
15 Hinge, Center
67006960 White
67007043 Black
16 67003868 Foot Brake
17 Cover, Corner
67003484 White
67003485 Black
18 12566604ED Hinge, Top
19 67007174 Bracket, Foot
20 67006425 Screw
21 Cover, Hinge
67001014 White
67001012 Black
22 Grille Assembly
(Includes Clips)
67006905 White
67006886 Black
2
(Stainless Steel−RH) (Stainless Steel−LH)
Illus.
No.
25 67006425 Screw
27 67001173 Cover, Water Valve
28 12575101ED Cover, Unit
29 W10137695 Power Cord
30 67003796 Insulation, Sound
31 67001066 Tube, Drain
32 67001067 Clip, Drain Tube
33 M0286708 Nut, Speed
34 67005127 Roller
35 M1205302 Pin
36 12479901 Plate, Cover
37 10093320 Bolt, Adjusting
40 B5759649 Gasket
44 67005064 Label, Water Line
Part
No. DESCRIPTION
(Rear)
W10144703
