Summary of Contents for DICE MediaBridge
- Page 1 HONDA vehicle specific integration solutions...
- Page 2 R3/R4 different between SAT-mode and CD-mode of Acura radio will support text? the DICE R3/R4 unit? The factory radio must have an XM or SAT button. Operating the iPod through the factory radio is nearly identical in both emulation modes.
- Page 3 The configuration switches located on the DICE module are used to set the operation of the interface by the installer. Incorrect dip switch settings may cause the DICE interface not to work properly or not to operate at all. Disconnect the...
- Page 4 Connection Diagram integration for iPod Factory XM tuner (if installed) radio location iPod Old Acura BUS system New Honda Bus system module MENU Honda R3 / R4 BUS connector vehicle specific docking cable receptacle connector cable (R4 only) Honda R2 BUS connector Note that in some vehicles the physical location of •...
- Page 5 If the radio does not have a SAT or XM button, then it will not support SAT emulation of Cannot find SAT mode. the DICE module. Have the DICE module configured for CDC emulation. Sound of factory installed satellite radio is The factory XM module must be disconnected.
- Page 6 XM) About Dip Switch Settings The configuration switches located on the DICE module are used t o set t he operation of t he i nterface b y t he i nstaller. Incorrect dip switch settings may cause the DICE interface not to work properly or not to operate at all.
- Page 7 Operation Overview SAT emulation Source selector 2 Use Presets to change modes. 3 Toggle between available text fields. Press to change track. Press to enable shuffle song. SAT emulation with navigation system Source selector & 6 Use Presets to change modes. Press to change track.
