Goodmans GDR10 Quick Start Manual

Model. GDR10
Quick-start guide for digital TV receiver
In the box
1 Digital TV receiver
Remote control
2
Two batteries
3
RF cable
4
Quick-start guide
5
User guide
6
Guide to remote-control TV codes
7
SCART cable
8
1
4
3
2
5
Model. GDR10
7
8
6
Model. GDR10
1a Connecting to a TV with a SCART socket
3 4
1
Make sure your TV and any other equipment you are connecting is switched off.
2
Unplug your TV from the wall socket.
Take the aerial out of your TV and connect it to the `RF IN' socket on the back panel of the digital receiver.
3
Connect the SCART cable that came with the receiver between the TV socket on the back panel of your
4
receiver and the SCART socket on your TV.
Switch on your receiver at the wall socket. The green light on the front panel will come on.
5
6 Switch on your TV.
1b Connecting to a TV without a SCART socket
3 4
Make sure your TV and any other equipment you are connecting is switched off.
1
Unplug your TV from the wall socket.
2
Take the aerial lead out of your TV and connect it to the RF IN socket on the back panel of the
3
receiver.
Connect the RF cable that came with your receiver between the `RF OUT' socket on the receiver and the
4
aerial socket on your TV.
Switch on your digital receiver at the wall socket. The green light on the front panel will come on.
5
Switch on your TV.
6
You will now need to tune a spare channel on your TV to the digital receiver. The digital receiver
7
automatically uses UHF channel 68. For more information on channel installation, please read the user
guide.
