Video Converter, AVX-1920
MANUAL
V1.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the AVX-1920 and is the answer not in the manual?

Questions and answers

Summary of Contents for digitalview AVX-1920

  • Page 1 Video Converter, AVX-1920 MANUAL V1.0...

  • Page 2: Table Of Contents

    Table of Contents 1 Introduction ................1.1 AVX-1920 Key Features ......................1.2 Guide to the AVX-1920 ........................ 2 Setup ..................2.1 Basic Setup Notes ........................2.2 Operation & Control ........................Revision History Amendment Date Version August 2009 V1.0 © Digital View Ltd 2009 www.digitalview.com...

  • Page 3: Introduction

    Introduction The AVX-1920, a video converter and image processor, that turns a display or projector with a HDMI input into a powerful video display system with advanced features such as remote operation, flexible picture in picture, a wide range of color and image management functions as well as remote device control.

  • Page 4: Guide To The Avx-1920

    1.2 Guide to the AVX-1920 Diagram 1 – AVX-1920 Item Description Type / Use Composite Video input RCA jack (yellow) S-Video input Mini DIN 5-pin connector DVI input DVI-D connector HDMI input HDMI type A connector Component Video (YPbPr) input...

  • Page 5: Setup

    Display: There is a wide selection of displays in the marketplace that are  suitable for use with the AVX-1920. Users are however recommended to consider the following: As a general rule it is recommended to set the output resolution to the same resolution as the display to be used.

  • Page 6: Operation & Control

    Via the RS-232 port (detail setup and control command protocols in  appendix); or By network commands.  Buttons: The buttons on the AVX-1920 allow direct access to the On Screen Display (OSD) for the various functions and settings. Controls Buttons Menu...
  • Page 7 IR Remote Control: The Digital View IR remote control for the AVX-1920 offers an alternative way to access the On Screen Display (OSD) for the various functions and settings. IR control definition BUTTON FUNCTION SOFT POWER BUTTON Soft power ON/OFF button.
  • Page 8 In input source selection mode, pressing this button to select Composite source. FREEZE BUTTON Use this button to freeze and release the picture on your screen. OSD Functions: The following shows the various functions and settings available through the OSD. © Digital View Ltd 2009 www.digitalview.com Page 8 of 33...
  • Page 9 H Pan V Size V Pan * : DISPLAY IN VIDEO MODE ONLY ** : FUNCTION IN ARGB/ DVI / VIDEO NTSC MODE ONLY ## : FUNCTION IN ARGB MODE ONLY © Digital View Ltd 2009 www.digitalview.com Page 9 of 33...
  • Page 10 PIP Swap: Swap between the main window and PIP window PIP Auto Turn off: OFF / ON ON: When PIP is no signal input after 30 seconds, the PIP window will turn off automatically. OFF: PIP window keeps on © Digital View Ltd 2009 www.digitalview.com Page 10 of 33...
  • Page 11 Adjust the OSD menu timeout period in a step of 5 seconds (max 60 seconds) ON = Continuous to display OSD menu. © Digital View Ltd 2009 www.digitalview.com Page 11 of 33 60 = 60 seconds later will turn off the OSD menu. Screen Marker !
  • Page 12 Firmware : E0.17.X1 RS-232 Control: The AVX-1920 can be controlled through the RS-232 port using the commands as summarized in Appendix II below. This provides comprehensive access to the functions and settings as provided by the OSD commands. Network Control: The AVX-1920 provides two choices for control over a...
  • Page 13 Sync On Green 72Hz SV_72 800x600 50.000 48.077 72.188 Composite Sync 72Hz SV_75 800x600 49.500 46.875 75.000 Digital Separate Sync 75Hz SV_75 800x600 49.500 46.875 75.000 Sync On Green 75Hz © Digital View Ltd 2009 www.digitalview.com Page 13 of 33...
  • Page 14 1920x1200 193.2 74.5 Digital Separate Sync 60Hz WUX_60 1920x1200 193.2 74.5 Sync On Green 60Hz WUX_60 1920x1200 193.2 74.5 Composite Sync 60Hz COMPOSITE, S-VIDEO & COMPONENT VIDEO INPUT PORT : © Digital View Ltd 2009 www.digitalview.com Page 14 of 33...
  • Page 15 System Resolution Horizontal freq Vertical freq [KHz] [Hz] NTSC 720x480i 15.7 NTSC 4.43 720x480i 15.7 720x576i 15.6 PAL M 720x576i 15.6 SECAM 720x576i 15.6 © Digital View Ltd 2009 www.digitalview.com Page 15 of 33...
  • Page 16 The RS-232 program can be custom-made to fit for application or it can be used the serial control program, like Accessport, Telix or Serial Utility program developed by DigitalView. Please contact your local support for information. © Digital View Ltd 2009 www.digitalview.com...
  • Page 17 “B” | “C” | “D” | Reset “2” – fill to aspect ratio “r” | “R” | Query “9” – 4:3 “?” “A” – 16:9 “B” – 16:10 “C” – 2.35:1 “D” – 2:1 © Digital View Ltd 2009 www.digitalview.com Page 17 of 33...
  • Page 18 Query: Single, PIP, PBP, PBPT “0”- Single “r” | “R” | Reset, “1”- Picture in Picture (PIP) “?” Query “2”- Picture by Picture (PBP) “3”- Picture by Picture Tall (PBPT) © Digital View Ltd 2009 www.digitalview.com Page 18 of 33...
  • Page 19 “5” – input source. “7” – zoom “8” – freeze “9” – PIP “B” – No function “D” – PIP Swap “E” – Aspect Ratio “G” – Hue “I” – Auto Picture Setup © Digital View Ltd 2009 www.digitalview.com Page 19 of 33...
  • Page 20 | “+” | “-” | value/increment/decrement position. “r” | “R” | Reset “?” Query Default : 0x30 0x30 0x30 0x30 The min and max values will change depends on input resolution. © Digital View Ltd 2009 www.digitalview.com Page 20 of 33...
  • Page 21 | “+” | “-” | colour temp. = “r” | “R” | value/increment/decrement Range : “9””C”-“F””F” “?” Reset Default : “E””C” Query © Digital View Ltd 2009 www.digitalview.com Page 21 of 33...
  • Page 22 Red Offset for selected selected colour channel for the selected colour temperature. temperature nn | “+” | “-” | colour temp. = “r” | “R” | value/increment/decrement “?” Reset Query © Digital View Ltd 2009 www.digitalview.com Page 22 of 33...
  • Page 23 “0xee”, “0x44” Preliminary “0”- 4:3 “0” |”1” 4:3 /16:9 “1”- 16:9 Marker “0xee”, “0x45” Preliminary “0”- 0% Background “0” |”1” |”2” |”3” 0% /25%/50%/95% “1”- 25% Transparency “2”- 50% “3”- 95% © Digital View Ltd 2009 www.digitalview.com Page 23 of 33...
  • Page 24 “35”, “30”- 64% Custom Sizing 0xef, Custom sizing selection : “0” – Overscan “0” | “1” | “2” Overscan / Normal / Custom “1” – Custom/Underscan ”?” Query “2” – Normal © Digital View Ltd 2009 www.digitalview.com Page 24 of 33...
  • Page 25 Query BIOS 0xcb, “0” Read BIOS version BIOS version “VV.YY.ZZ” version VV = V0 or E0, V0 = Release version E0 = Engineering Sample YY= Version Number ZZ= Customer Number © Digital View Ltd 2009 www.digitalview.com Page 25 of 33...
  • Page 26 “35”, “39”- 79% “35”, “38”- 77% “35”, “37”- 76% “35”, “36”- 74% “35”, “35”- 72% “35”, “34”- 71% “35”, “33”- 69% “35”, “32”- 67% “35”, “31”- 66% “35”, “30”- 64% © Digital View Ltd 2009 www.digitalview.com Page 26 of 33...
  • Page 27 Return Code: “0xF0 0x56 0x30 0x31 0x30 0x31” Return Code: “0xF0 0x56 0x30 0x31 0x30 0x31” Return Code: “0xF0 0x56 0x30 0x31 0x30 0x31” Return Code: “0xF0 0x56 0x30 0x31 0x30 0x31” © Digital View Ltd 2009 www.digitalview.com Page 27 of 33...
  • Page 28 = 1-byte ascii-coded hex number, e.g., parameter value of 0x1 is represented by “1” (0x31). mn or nn = 2-byte ascii-coded hex number, e.g., parameter value of 0x1e is represented by “1”, “e” | “E” (0x31, 0x6e|0x4e). © Digital View Ltd 2009 www.digitalview.com Page 28 of 33...
  • Page 29 0x4C 0x6C 0x4D 0x6D 0x4E 0x6E 0x4F 0x6F 0x50 0x70 0x51 0x71 0x52 0x72 0x53 0x73 0x54 0x74 0x55 0x75 0x56 0x76 0x57 0x77 0x58 0x78 0x59 0x79 0x5A 0x7A © Digital View Ltd 2009 www.digitalview.com Page 29 of 33...
  • Page 30    Composite           S-Video   Component        HDMI     © Digital View Ltd 2009 www.digitalview.com Page 30 of 33...
  • Page 31 Reset Color Gain function can be used. This function will reset the stored RGB values to a set of approximate values. © Digital View Ltd 2009 www.digitalview.com Page 31 of 33...
  • Page 32 LICENSING REQUIREMENTS Depending on the features desired, customer/purchaser may be required to obtain a license with the relevant organizations. TRADEMARKS The following are trademarks of Digital View Ltd: VIEWSTREAM/REMOTE PLAYER © Digital View Ltd 2009 www.digitalview.com Page 32 of 33...
  • Page 33 Digital View Inc. 18440 Technology Drive Building 130 Morgan Hill, CA 95037 Tel: (1) 408-782 7773 Fax: (1) 408-782 7883 Sales: ussales@digitalview.com EUROPE: Digital View Ltd 6 Marylebone Passage London W1W 8EX Tel: (44) (0)20 7631 2150 Fax: (44) (0)20 7631 2156 Sales: uksales@digitalview.com...
