Pedestal Jar Assembly Parts - KitchenAid Pro Line 4KPCG100ER1 Parts List

PEDESTAL JAR ASSEMBLY PARTS

8212130
For Models: KPCG100__1, 4KPCG100__1
2
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
4176735 Use and Care Guide
8212130 Repair Parts List
2 4176717 Lid, Bean Jar
3 4176731 O−Ring, Lid
4 4176730 Jar, Bean
5 4176729 Seal, Bean Jar
6 4176723 Nozzle, Holder
7 4176715 Spring, Housing
8 4176721 Cover, Nozzle
9 4176728 Jar, Coffee Ground
10 4176722 Ring, Abrasion
11 4176703 Cover, Baseplate
12 4176760 Screw
13 4176701 Nameplate
14 4176713 Lockwasher
15 Base Assembly
(Incl Nameplate)
4176700 Pearl Metallic
8212152 Nickel Pearl
8212322 Empire Red
W10217658 Onyx Black
16 4176725 Foot, Rubber
