- Page 1 Mini-Z Manual Model: ZA-21 www.drzamps.com...
- Page 2 This symbol warns the user of dangerous voltage levels localized within the enclosure. This symbol advises the user to read all accompanying literature for safely operating the unit Important Safety Instructions 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions.
-
Page 3: General Information
General Information The Mini Z is back in action with a few tweaks. Now available as a head and a 1x10 combo…this is the same circuit and tone many have grown to love from the original Mini Z 1x8 combo. We have added a built in attenuator! You can turn it up to get maximum output tube distortion and dial it back to apartment dweller approved levels…tons of singing sustain that you can talk over. - Page 4 FRONT PANEL 1. Input: Input jack for your guitar. 2. Volume: Controls overall amp volume. As you turn the volume up more natural drive will occur along with an increase in level. 3. Attenuator: Attenuates signal between amp and speaker. You can dial in your tone with the volume knob and dial back the overall volume by turning attenuator clockwise.
- Page 5 MODEL: ___________________ SERIAL NUMBER: ___________ INPUT VOLTAGE: ____________ MADE IN USA...
