Mitsubishi Electric FR-D700 Instruction Manual page 2

Compliance with the EU Machinery Directive – Functional Safety
Any misuse of safety function could lead to personal injury or death, property damage, or economic loss.
To ensure that the system complies fully with requirement of safety, make a system-level risk assessment.
Mitsubishi Electric Co. cannot assume responsibility for any system to comply with safety directive.
The information of this manual is merely a guide for proper installation.
Mitsubishi Electric Co. cannot assume responsibility for the compliance or the noncompliance to any code,
national, local or otherwise for the proper installation of this equipment.
A hazard of personal injury and/or equipment damage exists if codes are ignored during installation.
To avoid an electric shock hazard, verify that the voltage on the bus capacitors has discharged before
performing any work on the drive. Measure the DC bus voltage at the P(+) and N(-) terminals or test points
(refer to your drive's User Manual for locations and discharging time). The voltage must be zero.
The safety stop function do not isolate electrically between drive and motor. To avoid an electric shock
hazard, disconnect/isolate power to the drive and verify to ensure that the voltage is zero before
performing any work on the motor (refer to your drive's User Manual for discharging time).
If you are using a FR-D740-EC or FR-D740-CHT with serial number shown below, safety function does not
work according to safety standard. In such case please contact your sales person.
<Europe model : suffixed with '-EC'>
D740-012 to 080–EC : Axxxxx, Bxxxxx, Cxxxxx, Dxxxxx, Exxxx and Fxxxxx
D740-120 to 160–EC : Axxxxx, Bxxxxx, Cxxxxx and Dxxxxx
<China model : suffixed with '–CHT'>
D740-0.4K to 3.7K–CHT : Axxxxx, Bxxxxx, Cxxxxx, Dxxxxx,Exxxx and Fxxxxx
D740-5.5K to 7.5K–CHT : Axxxxx, Bxxxxx, Cxxxxx and Dxxxxx
Check the SERIAL number indicated on the inverter rating plate or package.
Rating plate example
Symbol Year Month
SERIAL (Serial No.)
The SERIAL consists of 1 version symbol, 2 numeric characters
or 1 numeric character and 1 alphabet letter indicating year and
month, and 6 numeric characters indicating control number.
Last digit of the production year is indicated as the Year, and the
Month is indicated by 1 to 9, X (October), Y (November), and Z
(December).
Control number
WARNING
CAUTION
WARNING
WARNING
CAUTION
