17. After the installation is completed, select one of the options to restart the computer either
now or later, and then click [Finish].
Restart the computer to complete installation.
• To stop installation of the selected software, click [Cancel] before installation is complete.
• Auto Run may not work with certain operating system settings. In that case, launch "Setup.exe" on the
CD-ROM root directory.
• A message appears if there is a newer version of the printer driver already installed. If there is, you
cannot install the printer driver using Auto Run. If you still want to install the printer driver, use [Add
Printer]. See "Messages Displayed When Installing the Printer Driver", Trouble Shooting.

Using the WSD port

This section explains installation when using the WSD port.
• The WSD port can be used under Windows Vista or Windows Server 2008.
• To install under Windows Vista or Windows Server 2008, you must have an account that has Manage
Printers permission. Log on as an Administrator.
• You can connect to the printer only if both the printer and computer are on the same network segment,
or "Network discovery" is enabled. For details, see Windows Help.
Installing the PCL printer driver
1. Quit all applications currently running.
2. On the [Start] menu, click [Network].
The [Network] window appears, and the device search begins automatically.
3. Right-click the printer's icon, and then click [Install].
If the [User Account Control] dialog box appears, click [Continue].
The [Found New Hardware] dialog box appears.
4. Click [Locate and install driver software (Recommended)].
If the [User Account Control] dialog box appears, click [Continue].
5. Click [Don't search online].
6. Click [Browse my computer for driver software (advanced)].
7. Insert the provided CD-ROM into the computer's CD-ROM drive.
If the [AutoPlay] dialog box appears, click the [close] button and then proceed to step 8.
Installing the Printer Driver
