Installation Instructions for Dryers Original Instructions Keep These Instructions for Future Reference. (If this machine changes ownership, this manual must accompany machine.) Part No. 510963R7 www.alliancelaundry.com November 2014... -
Page 3: Front Matter
A "T-Handle" type gas shut-off valve must be installed in the gas supply line to this appliance. • This appliance must not be installed in a bedroom or bath- room. © Part No. 510963R7 Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT... -
Page 4: Table Of Contents
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher. © Part No. 510963R7 Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT... -
Page 5: Dimensions
28 in. [711 mm] 23.5 in. [597 mm] NOTE: Exhaust openings are 4 inch [102 mm] metal * With leveling legs turned into base. ducting. © Part No. 510963R7 Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT... - Page 6 28 in. [711 mm] 23.5 in. [597 mm] NOTE: Exhaust openings are 4 inch [102 mm] metal * With leveling legs turned into base. ducting. © Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT Part No. 510963R7...
-
Page 7: Installation
Position and Level the Dryer 1. Install dryer before washer. This allows room for attaching exhaust duct. 2. Select a location with a solid floor. Dryers installed in resi- dential garages must be elevated 18 inches [457 mm] above the floor. - Page 8 Front View (Closet Door) 2 (G) DRY2637N_SVG 1. Closet Door 2. Centered Air Openings (G) (2 Openings minimum) 3. Outer Wall of Enclosure Figure 3 © Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT Part No. 510963R7...
-
Page 9: Connect Dryer Exhaust System
W115 W045 © Part No. 510963R7 Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT... -
Page 10: Exhaust Direction
Exhaust Direction Figure 4 The dryer can be exhausted to the outdoors through the back, left, right or bottom of the dryer. EXCEPTION: Gas dryers cannot be • DO NOT use plastic, thin foil or type B ducting. Rigid metal vented out the left side because of the burner housing. - Page 11 NOTE: The maximum length of a 4 in. [102 mm] diame- ter flexible metal duct must not exceed 7.87 ft. [2.4 m], as required to meet UL2158, clause 7.3.2.A. © Part No. 510963R7 Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT...
-
Page 12: Gas Dryers - Connect Gas Supply Pipe
For proper operation at altitudes above 3000 feet [915 m] the nat- ural gas valve spud orifice size must be reduced to ensure com- plete combustion. Refer to Table 3 . © Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT Part No. 510963R7... -
Page 13: Connect Electrical Plug (Electric Dryer Only)
60 Hertz, single phase circuit, AC (alternating current) circuit, fused at 30 Amperes (the circuit must be fused on both sides of the line). Electrical service for the dryer should be © Part No. 510963R7 Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT... -
Page 14: Connecting Power Cord With Three-Wire Plug
The power cord connection between wall receptacle and dryer terminal block IS NOT supplied with dryer. Type of power cord and gauge of wire must conform to local codes. © Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT Part No. 510963R7... - Page 15 15. Direct Connection 16. Power Cord Connection Figure 6 1. Disconnect power to dryer. 2. Remove access cover from rear of dryer. D695I_SVG Figure 7 © Part No. 510963R7 Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT...
-
Page 16: Connecting Power Cord With Four-Wire Plug
Connecting Power Cord with Four-Wire Plug NOTE: Four-wire cord is required for new branch-cir- cuit installations, mobile homes or where codes do not permit grounding through neutral. © Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT Part No. 510963R7... -
Page 17: Reverse Door, If Desired
10. Reinstall access cover and screw. Reverse Door, if Desired The door on this dryer is completely reversible. To reverse door proceed as follows: 1. Remove four hinge attaching screws. © Part No. 510963R7 Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT... - Page 18 4. Rotate door panel 180 degrees as shown. 8. Using screwdriver, remove two door plugs, and reinstall on opposite side of door opening. D273P_SVG Figure 19 © Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT Part No. 510963R7...
-
Page 19: Wipe Out Inside Of Dryer
Connect the dryer to an electrical power source. Refer to Electric Dryer Only - Connect Electrical Plug for information on con- necting power cord. © Part No. 510963R7 Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT... -
Page 20: Grounding Information
2. After the dryer has operated for three minutes, the exhaust air W037 or exhaust pipe should be warm. Gas Dryers 1. To view the burner flame, remove the lower front panel of the dryer. © Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT Part No. 510963R7... - Page 21 1. Air Shutter Lockscrew 2. Appliance Main Gas Valve 3. Air Shutter 4. 1/8 in. [3.1 mm] Pipe Plug (For checking manifold pres- sure) Figure 28 © Part No. 510963R7 Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT...
-
Page 22: Installer Checklist
Check Heat Source • Connect Electrical Cord. D702I_SVG1 CHECK CHECK D699I_SVG1 Reverse Door, if De- sired. CHECK D675I_SVG1 Refer to the manual for more detailed information © Part No. 510963R7 Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT...
