Appendix U

Graphics Display Icon Key

Display Size
Large Small
M
ENU
DPL
LINE
PL Z
RFID
SD
USB
HOST
STOP
!
*LED
Class Series 2 Programmer's Manual
Initialization, typically brief (but a damaged or invalid printhead
can delay the process).
Display large fonts; see Section 4.1.2.
Input Mode – DPL; see Section 4.2.4.
Input Mode – LINE; see Section 4.2.4.
Input Mode – PL-Z; see Section 4.2.4.
RFID detected.
SD memory card detected.
USB memory (or keyboard) detected.
Wired network detected.
Server inaccessible.
WLAN associated with Access Point.
WLAN not associated with Access Point.
WLAN ADHOC Mode.
*
Receiving data.
*
Paused.
*
Faulted, see Section 6.1.2.
Description
309
