SPECIFICATION
Monitor

Specifications

Picture Tube
Viewable Image Size:
Input Signal
Display Colors
Synchronization
Range
Resolutions Supported
Resolution based on horizontal and
vertical frequencies only
Active Display Area
(Factory Setting)
Active Display Area
(Full Scan)
Power Supply
Current Rating
Dimensions
Weight (Net)
Environmental Considerations
Operating Temperature:
Storage Temperature:
NOTE: Technical specifications are subject to change without notice.
N0701
Monitor
Diagonal: 43cm(17inch)
40.6cm(16.0inch)
Radius: 1210mm
Video: ANALOG 0.7Vp-p/75 Ohms
Sync: Separate sync. TTL Level
Horizontal sync. Positive/
Negative
Vertical sync. Positive/Negative
Analog input: Unlimited number of Colors
Horizontal: 31 kHz to 70 kHz
Vertical: 55 Hz to 120 Hz
640 × 480 @ 60 to 120 Hz
800 × 600 @ 55 to 110 Hz
832 × 624 @ 55 to 106 Hz
1024 × 768 @ 55 to 87 Hz ... ...
1152 × 870 @ 55 to 77 Hz
1280 × 1024 @ 55 to 66 Hz
Horizontal: 310mm
Vertical: 232mm
325mm
243mm
AC 100 - 240V, 50 - 60Hz
1.5A @ 100 - 240V
403(W ) × 420(H) × 418(D) mm
15.5 kg
0° C to + 35° C
Humidity: 30% to 80%
Altitude: 0 to 3000 m
-20° C to + 60° C
Humidity: 10% to 90%
Altitude: 0 to 13700 m
Notes
90° deflection, 0.28mm grille pitch, medium
short persistence phosphor, aperture grille CRT,
multi-layered, anti- static screen coating, dark
screen.
Depends on display card used.
Automatically
Automatically
Some systems may not support all modes listed.
NEC cites recommended resolution at 85 Hz for
optimal display performance.
Dependent upon signal timing used,
and does not include border area.
Dependent upon signal timing used,
and does not include border area.
3
